Outside Rearview Mirror - Passenger (D48)
| Connector Part Information OEM: E-5965-003 Service: 88988356 Description: 3-Way M 1.5 Series, Sealed (BK) |
|---|
| Terminal Part Information Pins: 1 Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit Pins: 2, 3 Terminal/Tray: 7114-4102-08/9 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094430/J-35616-3 (GY) |
Outside Rearview Mirror (Passenger) Connector Part Information (D48)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | GY | 90 | Passenger Mirror Motor Left Control |
| 2 | TN/WH | 330 | Passenger Mirror Motor Supply Voltage |
| 3 | BN/WH | 1498 | Passenger Mirror Motor Up Control |
Outside Rearview Mirror (Passenger) Connector Terminal Identification (D48)
Scheme 10
| Connector Part Information OEM: 12064769 Service: 12101762 Description: 10-Way F Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Pins: B, C, D, E, F, G, H, J, K Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-2A (GY) |
Outside Rearview Mirror Switch Connector Part Information (D48)
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A | Not Used | ||
| B | BK | 550 | Ground |
| C | TN | 329 | Driver Mirror Motor Supply Voltage |
| D | GY | 90 | Passenger Mirror Motor Left Control |
| E | GY | 8 | Instrument Panel Lamp Supply Voltage |
| F | BN/WH | 1498 | Passenger Mirror Motor Up Control |
| G | RD/WH | 440 | Battery Positive Voltage |
| H | TN/WH | 330 | Passenger Mirror |
| J | L-BU | 82 | Left Mirror Motor Left Control |
| K | YE | 88 | Left Mirror Motor Up Control |
Outside Rearview Mirror Switch Connector Terminal Identification (D48)
Intermittent
Thoroughly inspect the wiring and connectors. An incomplete inspection of the wiring and connectors may result in misdiagnosis causing part replacement with the reappearance of the malfunction. If an intermittent malfunction exists, refer to Testing for Intermittent Conditions and Poor Connections .
Repair Procedures
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Power Mirror Switch Replacement»(ref-267927-S35146190322007101700000)
- «Mirror Replacement»(ref-267927-S38682358082007101700000)
Scheme 11
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure: Remove the door panel. Refer to Door Trim Panel Replacement . | |
| 1 | Switch Assembly, Power Mirror |
Power Mirror Switch Replacement
Scheme 12
| Callout | Component Name |
|---|---|
| NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedure Remove the door trim panel. Refer to Door Trim Panel Replacement . Fully lower the door window before removing the trim panel. | |
| 1 | Nut, Mirror Outside Rearview (Qty: 3) Tip: Disconnect the mirror electrical connector. Tighten: 10 N.m (89 lb in) |
| 2 | Mirror Assembly, Outside Rearview |
| NOTE |
|---|
| Refer to Fastener Notice . |
Mirror Replacement
Scheme 13
| Callout | Component Name |
|---|---|
| Preliminary Procedures Remove the door trim panel. Refer to Door Trim Panel Replacement . Remove the door mirror face. Refer to Mirror Face Replacement . | |
| 1 | Front Door Mirror Motor Screw NOTE: Refer to Fastener Notice . Tighten: 2 N.m (18 lb in) |
| 2 | Front Door Mirror Motor Tip: Disconnect the electrical connector from the mirror motor. |
| NOTE |
|---|
| Refer to Fastener Notice . |
Outside Rearview Mirror Motor Replacement
Scheme 14
| Callout | Component Name |
|---|---|
| CAUTION: Refer to Glass and Sheet Metal Handling Caution . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| 1 | Mirror Face, Outside Rearview Tip: Release the mirror face backing from the mirror housing by pulling outward. |
| CAUTION |
|---|
| Refer to Glass and Sheet Metal Handling Caution . |
Mirror Face Replacement
Outside Rearview Mirror Controls
The outside rearview mirrors are controlled by the outside rearview mirror switch located on the driver door. The outside rearview mirror switch contains a mirror select switch and a 4 position mirror direction switch. The mirror select switch is a 2 position switch (L, R), used to select the mirror to be adjusted. The mirror direction switch is used to control the mirror in the up, down, left, and right directions.
