Mirror System: Removal & Installation Pontiac Solstice I

Removal Procedure

1. Remove the wiring harness cover.
2. Loosen the screw in the base of the mirror.
3. Remove the mirror from the mounting pad.
4. Disconnect the rearview mirror wiring harness, if applicable.

Installation Procedure

1. Install the mirror to the mounting pad.
2. Tighten the screw that retains the mirror base to the mounting pad. Tighten: Tighten the mirror set screw to 2 N.m (18 lb in).
3. Install the rearview mirror wiring harness.
4. Install the wiring harness cover.
5. Refer to «Control Module References»(ref-267925-S30181830442007101700000) for programming and setup information.

Rearview Mirror Support Installation

Tools Required

1. Inside Mirror Adhesive Kit GM P/N 1052369 (Canadian P/N 993362) or equivalent
2. Safety Razor or Utility Knife

Scheme 9

1. Determine the location of the mirror mounting base by marking the outside of the windshield with a marking pencil where the base was previously located. If it is not clear where the base was mounted, use the following steps to determine where the base should be installed: Using a measuring tape, measure the distance between the windshield pillars from the base of the shade line . Using a marking pencil, halfway between the windshield pillars, draw a centerline (1) on the windshield from the roof panel to the windshield base. Draw a perpendicular line intersecting the centerline (2) at that location. The top center of the mirror mounting base will be at the intersection of these lines.
2. Scrape the inside windshield thoroughly with a safety razor or utility knife in order to remove all old adhesive.
3. If reinstalling the original mounting base, place the mirror mounting base in a suitable holding device, such as a vice.
4. Scrape the mirror mounting base thoroughly with a safety razor or utility knife in order to remove all old adhesive.
5. Clean the inside windshield and the mounting surface of the mirror mounting base thoroughly with a clean cloth saturated with naphtha or a 50/50 mixture (by volume) of clean water and isopropyl alcohol.
6. Use Inside Mirror Adhesive Kit GM P/N 1052369 (Canadian P/N 993362) or equivalent to apply a small amount of activator to the mounting surface of the mirror mounting base.
7. Apply a small amount of activator to the windshield where the mounting base is to be installed.
8. Allow the activator to dry 5 minutes.
9. Apply 1 drop of adhesive to the center of the mirror mounting base.
10. Immediately apply the mounting base to the windshield, ensuring that the mounting base aligns correctly to the marks made on the outside of the windshield.
11. Hold the mounting base firmly in place for 1 minute.
12. Allow the adhesive to set for 15 minutes.
13. Install the mirror to the mirror mounting base and fasten, if necessary.
14. Connect the electrical connector and install the wire cover, if equipped.

The power outside rearview mirror system consists of the following components

1. Mirror direction switch-Controls the left, right, up, and down movements of the driver and passenger outside mirrors
2. Mirror select switch-Used to select the mirror to be adjusted
3. Driver outside rearview mirror-Contains the horizontal and vertical mirror motors
4. Passenger outside rearview mirror-Contains the horizontal and vertical mirror motors
5. MIRRORS 5 A fuse-Located in the underhood fuse block
