The instrument panel electrical centre (IPBEC) is installed in the left footwell, behind the A-pillar inner panelling. It contains relays and fuses.
The body control module is connected in the instrument panel electrical centre. The body control module is connected to the vehicle electrical system via wiring harness plugs.
| 1 | Body control module |
|---|---|
| 2 | Wiring harness plug, body control module |
| 3 | Wiring harness plug, connection to the body wiring harness |
| 4 | Installation position of relays |
| 5 | Installation position of fuses |
