Replace Radio Installation Frame Opel Corsa D

Remove

1. 1. Disconnect battery

2. 2. Remove radio • Unlock radio using KM-6097 (1) • Release compact plug (2) and disconnect • Disconnect antenna cable (3)

3. 3. Remove radio installation frame • Bend open 5 retaining lugs (1) • Remove radio installation frame

Install

4. 4. Install radio installation frame • Press in 5 retaining lugs

Note. Ensure correct seat of radio installation frame.

5. 5. Install radio • Connect and lock compact plug • Connect aerial cable • Push radio in to the stop

Note. Radio must audibly latch.

6. 6. Connect battery
7. 7. Program volatile memories
