Microphone - Telephone System - Replace (Upgrade Kit) Opel Corsa D

Remove

1. 1. Remove A-pillar panelling (2) • Undo 2x clip (1) • Remove A-pillar panelling from guide

2. 2. Remove lower foot well panelling, passenger side (3). • Undo clip (1) • Unscrew bolt (2) • Remove from the guide

3. 3. Remove glove compartment • Unscrew 4 screws (1) and (2) • Disconnect the wiring harness plug, glove compartment lighting

4. 4. Remove microphone • Disconnect wiring harness connector (3) • Remove wiring harness (2) along A-pillar • Draw wiring harness through instrument panel padding • Remove wiring harness behind headlining • Unclip and remove microphone (1)

Install

5. 5. Install handsfree system microphone • Clip microphone to headlining in area of rear view mirror • Push wiring harness under headlining using plastic wedge • Lay microphone wiring harness to behind glove compartment • Fix wiring harness plug
6. 6. Attach glove compartment • Fix wiring harness plug • Tighten 4x bolts
7. 7. Attach lower right footwell panelling • Clip panelling in position • Tighten bolt
8. 8. Attach right A-pillar panelling • Insert A-pillar panelling in guide • Clip in 2x clips

Note. Ensure correct seating of door rubber seal.
