Terminal Assignment
Terminal Assignment Control Unit Vectra�b
| Terminal Assignment, occupied connections only: |
|---|
| |
| I | Aerial Cable (Signal lead) |
| II | Aerial Cable (Shielding) |
| |
| 1 | S67 Switch�Remote Control, Radio |
| 2 | S1 Switch�Starter (Terminal W) |
| 3 | U25 Multitimer (Terminal 58D) |
| 4 | Ground (Terminal 31) |
| 5 | Odometer Signal |
| 6 | H54 Phone (Mute Control) |
| 7 | Aerial (Voltage Supply) |
| 8 | F22 Fuse (Terminal 30) |
| 9 | H40/H58 Loudspeaker�rear, right/Tweeterrear, right (Ground) |
| 10 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Ground) |
| 11 | H37/H52 Loudspeaker�front, left/Tweeterfront left (Ground) |
| 12 | H39/H57 Loudspeaker�rear, left/Tweeterrear, left (Ground) |
| 13 | H40/H58 Loudspeaker�rear, right/Tweeterrear, right (Signal Lead) |
|---|
| 14 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Signal Lead) |
| 15 | H37/H52 Loudspeaker�front, left/Tweeterrear, left (Signal Lead) |
| 16 | H39/H57 Loudspeaker�rear, left/Tweeterrear, left (Signal Lead) |
| 17 | SCL, Serial Clock Line |
| 18 | MRQ, Master Request Line |
| 19 | X13 Diagnostic Link 16P |
| 20 | H54 Phone (Ground) |
| (Audio IN) |
| 22 | SDA, Serial Data Line |
| 23 | H54 Phone (Signal Lead) |
| (Audio IN) |
Terminal Assignment Control Unit Omega�b
| Terminal Assignment, occupied connections only: |
|---|
| I | Aerial cable (Signal lead) |
| II | Aerial cable (Shielding) |
| |
| 2 | S1 Switch�Starter (Terminal W) |
| 3 | S2 Switch ASM�Light (Terminal 58D) |
| 4 | Ground (Terminal 31) |
| 5 | Odometer Signal |
| 6 | H54 Phone (Mute Control) |
| 7 | Aerial (Voltage Supply) |
| 8 | F12 Fuse (Terminal 30) |
| 9 | H40/H58 Loudspeaker�rear, right/Tweeterrear, right (Ground) |
| 10 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Ground) |
| 11 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Ground) |
| 12 | H39/H57 Loudspeaker�rear, left/Tweeterrear, left (Ground) |
| 13 | H40/H58 Loudspeaker�rear, right/Tweeterrear, right (Signal Lead) |
| 14 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Signal Lead) |
|---|
| 15 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Signal Lead) |
| 16 | H39/H57 Loudspeaker�rear, left/Tweeterrear, left (Signal Lead) |
| 17 | SCL, Serial Clock Line |
| 18 | MRQ, Master Request Line |
| 19 | XD Diagnostic Link 16P |
| 20 | H54 Phone (Ground) |
| (Audio IN) |
| 22 | SDA, Serial Data Line |
| 23 | H54 Phone (Signal Lead) |
| (Audio IN) |
Terminal Assignment Control Unit Astra�f
| Terminal Assignment, occupied connections only: |
|---|
| I | Aerial cable (Signal lead) |
| II | Aerial cable (Shielding) |
| |
| 2 | S1 Switch�Starter (Terminal W) |
| 3 | F9 Fuse (Terminal 58K) |
| 4 | Ground (Terminal 31) |
| 5 | Odometer Signal |
| 6 | H54 Phone (Mute Control) |
| 7 | Aerial (Voltage Supply) |
| 8 | F24 Fuse (Terminal 30) |
| 9 | H40 Loudspeaker�rear, right (Ground) |
| 10 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Ground) |
| 11 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Ground) |
| 12 | H39 Loudspeaker�rear, left (Ground) |
| 13 | H40 Loudspeaker�rear, right (Signal Lead) |
| 14 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Signal Lead) |
|---|
| 15 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Signal Lead) |
| 16 | H39/ Loudspeaker�rear, left (Signal Lead) |
| 17 | SCL, Serial Clock Line |
| 18 | MRQ, Master Request Line |
| 19 | XD Diagnostic Link 16P |
| 20 | H54 Phone (Ground) |
| (Audio IN) |
| 22 | SDA, Serial Data Line |
| 23 | H54 Phone (Signal Lead) |
| (Audio IN) |
Terminal Assignment Control Unit Corsa�b, Tigra
| Terminal Assignment, occupied connections only: |
|---|
| I | Aerial cable (Signal lead) |
| II | Aerial cable (Shielding) |
| |
| 2 | S1 Switch�Starter (Terminal W) |
| 3 | F19 Fuse (Terminal 58K) |
| 4 | Ground (Terminal 31) |
| 5 | Odometer Signal |
| 6 | H54 Phone (Mute Control) |
| 7 | Aerial (Voltage Supply) |
| 8 | F24 Fuse (Terminal 30) |
| 9 | H40 Loudspeaker�rear, right (Ground) |
| 10 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Ground) |
| 11 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Ground) |
| 12 | H39 Loudspeaker�rear, left (Ground) |
| 13 | H40 Loudspeaker�rear, right (Signal Lead) |
| 14 | H38/H53 Loudspeaker�front, right/Tweeterfront, right (Signal Lead) |
|---|
| 15 | H37/H52 Loudspeaker�front, left/Tweeterfront, left (Signal Lead) |
| 16 | H39/ Loudspeaker�rear, left (Signal Lead) |
| 17 | SCL, Serial Clock Line |
| 18 | MRQ, Master Request Line |
| 19 | X13 Diagnostic Link 16P |
| 20 | H54 Phone (Ground) |
| (Audio IN) |
| 22 | SDA, Serial Data Line |
| 23 | H54 Phone (Signal Lead) |
| (Audio IN) |
