Coolant Circuit
Design of Coolant Circuit
The components of the coolant circuit (illus. G 3114):
| 1 | Coolant pump with |
|---|---|
| 1.1 | integrated housing cover for temperature sensor and |
| 1.2 | integrated thermostat housing |
| 1.3 | Coolant drain bolt |
| 2 | EGR housing with integrated heating feed |
| 2.1 | Coolant temperature sensor, instrument |
| 2.2 | EGR valve |
| 2.3 | Coolant hose connection port |
| 3 | Coolant cutoff valve (with air conditioning) |
