Crankshaft Impulse Sensor, Motronic 7.6.1 Opel Astra H

Engine and Engine Aggregates 2 illustrations

Objective:

Check operation of the impulse sensor on the crankshaft.

Measurement:

Plot of voltage at the signal output for the impulse sensor on the crankshaft.

Preparation:

Switch off the engine and ignition.

Connections:

INPUT ACOM/TRIGGERINPUT B
Connect the red measurement lead to pin 2 of the plug connector for the impulse sensor on the crankshaft. Connect the ground lead to pin 1.

Procedure Tech 31:

  1. 1. Download Reference curve.
  2. 2. Start the engine and allow it to idle.

Reference Curve:

Procedure Tech 32:

  1. 1. Download Setup File (the Tech 32 uses only Setup files, no reference curves).
  2. 2. Start the engine and allow it to idle.

Setup File:

Reference Curve:
