Charging Air System Replace

Remove

1. Disconnect the negative battery cable.
2. Remove the beauty cover. Refer to Beauty Cover Replace .

3. Disconnect the MAF (Mass Air Flow) sensor connector.
4. Remove the air cleaner assembly bolts.
5. Remove the turbocharger inlet duct bolt and clamp.
6. Remove the air cleaner assembly and turbocharger duct.
7. Remove the charge air cooler inlet pipe bolts.
8. Remove the charge air cooler inlet pipe.

9. Disconnect the PCV hose and clamp from the turbocharger inlet elbow.
10. Remove the turbocharger inlet elbow.
11. Remove the turbocharger outlet duct.
12. Remove the charge air cooler inlet/outlet clamps and ETC (Electric Throttle Control) side clamp.
13. Remove the charge air cooler inlet/outlet hoses.

Install

1. Install the charge air cooler inlet/outlet hoses.
2. Install the turbocharger inlet elbow and outlet duct.

3. Install the charge air cooler inlet pipe.

Tighten

Tighten the charge air cooler inlet pipe bolts to 8 N•m (70.8 lb-in).

4. Install the air cleaner assembly and the turbocharger inlet duct.

Tighten

Tighten the air cleaner assembly bolts to 6 N•m (53 lb-in).

Tighten the turbocharger inlet duct bolt to 3 N•m (26.6 lb-in).
