Duct Sensor Replace Opel Antara I

Duct Sensor Replace

(Left-Hand Drive Shown, Right-Hand Drive Similar)

Remove

1. Disconnect the negative battery cable.
2. Remove the glove box lower panel cover. Refer to Instrument Compartment Replace .
3. Turn the sensor to release it from the aircon module.
4. Disconnect the electrical connector.

Install

1. Install the coolant temperature sensor into the aircon module and turn the sensor to lock it.
2. Connect the electrical connector.
3. Install the glove box lower panel cover. Refer to Instrument Compartment Replace .
4. Connect the negative battery cable.
