Sheet Metal Specifications
Front End
| Component | Sheet Metal Type | Tensile Strength (MPa) | |
|---|---|---|---|
| 1 | Headlamp brace, right side | Double sided galvanized steel | — |
| 2 | Headlamp panel, right side | Double sided galvanized steel | — |
| 3 | Upper front crossmember | Double sided galvanized steel | — |
| 4 | Headlamp panel, left side | Double sided galvanized steel | — |
| 5 | Headlamp brace, left side | Double sided galvanized steel | — |
| 6 | Radiator support crossmember | Double sided galvanized steel | — |
| 7 | Upper front impact absorber | High strength steel and double sided galvanized steel | 590 |
| 8 | Lower front impact absorber | High strength steel and double sided galvanized steel | 590 |
| 9 | Bonnet lock brace | Double sided galvanized steel | — |
Body Front
| Component | Sheet Metal Type | Tensile Strength (MPa) | |
|---|---|---|---|
| 1 | Front wheelhouse panel, right side | High strength steel and double sided galvanized steel | 440 |
| 2 | Front wheelhouse panel, left side | High strength steel and double sided galvanized steel | 440 |
| 3 | Front wheelhouse inner extension bracket, right side | Double sided galvanized steel | — |
| 4 | Front wheelhouse inner extension bracket, left side | Double sided galvanized steel | — |
| 5 | Hydraulic modulator mounting bracket | Double sided galvanized steel | — |
| 6 | Suspension upper mounting bracket, right side | Double sided galvanized steel | — |
| 7 | Suspension upper mounting bracket, left side | Double sided galvanized steel | — |
| 8 | Front wheelhouse inner extension panel, right side | Double sided galvanized steel | — |
| 9 | Front wheelhouse inner extension panel, left side | Double sided galvanized steel | — |
| 10 | Headlamp panel bracket, right side | Double sided galvanized steel | — |
| 11 | Headlamp panel bracket, left side | Double sided galvanized steel | — |
| 12 | Brake pressure hose bracket | Double sided galvanized steel | — |
| 13 | Front sidemember outer closing panel, right side | High strength steel and double sided galvanized steel | 440 |
| 14 | Front sidemember outer closing panel, left side | High strength steel and double sided galvanized steel | 440 |
| 15 | Wing bracket, front sidemember, right side | Double sided galvanized steel | — |
| 16 | Wing bracket, front sidemember, left side | Double sided galvanized steel | — |
| 17 | Front sidemember, right side | High strength steel and double sided galvanized steel | 590 |
| 18 | Front sidemember, front section, right side | High strength steel and double sided galvanized steel | 440 |
| 19 | Front sidemember, front bracket, right side | High strength steel and double sided galvanized steel | 340 |
| 20 | Front sidemember, left side | High strength steel and double sided galvanized steel | 590 |
| 21 | Front sidemember, front section, left side | High strength steel and double sided galvanized steel | 440 |
| 22 | Front sidemember, front bracket, left side | High strength steel and double sided galvanized steel | 340 |
| 23 | Battery tray bracket, front sidemember | Double sided galvanized steel | — |
| 24 | Bulkhead panel | Double sided galvanized steel | — |
| 25 | Bulkhead panel upper crossmember | Double sided galvanized steel | — |
| 26 | A-pillar reinforcement panel, right side | High strength steel and double sided galvanized steel | 590 |
| 27 | A-pillar reinforcement panel, left side | High strength steel and double sided galvanized steel | 590 |
| 28 | Front wheelhouse outer panel, right side | High strength steel and double sided galvanized steel | 440 |
| 29 | Front wheelhouse outer panel, left side | High strength steel and double sided galvanized steel | 440 |
| 30 | A-pillar upper brace, right side | High strength steel and double sided galvanized steel | 590 |
| 31 | A-pillar upper brace, left side | High strength steel and double sided galvanized steel | 590 |
| 32 | Instrument panel bracket | Double sided galvanized steel | — |
| 33 | Upper cowl panel | Double sided galvanized steel | — |
| 34 | Cowl ventilator sealing panel | Double sided galvanized steel | — |
| 35 | Cowl side panel, right side | High strength steel and double sided galvanized steel | 440 |
| 36 | Cowl side panel, left side | High strength steel and double sided galvanized steel | 440 |
| 37 | Front wing bracket, right side | Double sided galvanized steel | — |
| 38 | Front wing bracket, left side | Double sided galvanized steel | — |
| 39 | Cowl panel upper extension panel, right side | Double sided galvanized steel | — |
| 40 | Cowl panel upper extension panel, left side | Double sided galvanized steel | — |
| 41 | Cowl panel outer sidemember, right side | High strength steel and double sided galvanized steel | 440 |
| 42 | Cowl panel outer sidemember, left side | High strength steel and double sided galvanized steel | 440 |
| 43 | Bonnet hinge panel, right side | Double sided galvanized steel | — |
| 44 | Bonnet hinge panel, left side | Double sided galvanized steel | — |
| 45 | Upper cowl panel | Double sided galvanized steel | — |
| 46 | Upper cowl side panel, right side | High strength steel and double sided galvanized steel | 590 |
| 47 | Upper cowl side panel, left side | High strength steel and double sided galvanized steel | 590 |
Floor
| Component | Sheet Metal Type | Tensile Strength (MPa) | |
|---|---|---|---|
| 1 | Front floor panel, right side | Double sided galvanized steel | — |
| 2 | Front floor panel, left side | Double sided galvanized steel | — |
| 3 | Front floor reinforcement panel, right side | High strength steel | 590 |
| 4 | Front floor reinforcement panel, left side | High strength steel | 590 |
| 5 | Front seat rear outer bracket, right side | High strength steel | 440 |
| 6 | Front seat rear outer bracket, left side | High strength steel | 440 |
| 7 | Floor panel upper crossmember, right side | High strength steel | 590 |
| 8 | Floor panel upper crossmember, left side | High strength steel | 590 |
| 9 | Front floor tunnel | High strength steel and double sided galvanized steel | 440 |
| 10 | Park brake lever reinforcement panel | Double sided galvanized steel | — |
| 11 | Park brake cable reinforcement panel | Double sided galvanized steel | — |
| 12 | Front floor tunnel brace | Double sided galvanized steel | — |
| 13 | Front floor tunnel reinforcement panel | High strength steel and double sided galvanized steel | 440 |
| 14 | Front floor sidemember, right side | High strength steel and double sided galvanized steel | 590 |
| 15 | Front floor sidemember, left side | High strength steel and double sided galvanized steel | 590 |
| 16 | Front floor lower crossmember, right side | High strength steel and double sided galvanized steel | 590 |
| 17 | Front floor lower crossmember, left side | High strength steel and double sided galvanized steel | 590 |
| 18 | Inner sill panel, right side | High strength steel and double sided galvanized steel | 590 |
| 19 | Inner sill panel, left side | High strength steel and double sided galvanized steel | 590 |
| 20 | Rear floor front panel | Double sided galvanized steel | — |
| 21 | Rear floor rear panel | Double sided galvanized steel | — |
| 22 | Rear towing hook | Double sided galvanized steel | — |
| 23 | Rear floor sidemember, right side | High strength steel and double sided galvanized steel | 590 |
| 24 | Rear floor sidemember, rear section, right side | High strength steel and double sided galvanized steel | 590 |
| 25 | Rear floor sidemember reinforcement, right side | Double sided galvanized steel | — |
| 26 | Rear floor sidemember, left side | High strength steel and double sided galvanized steel | 590 |
| 27 | Rear floor sidemember, rear section, left side | High strength steel and double sided galvanized steel | 590 |
| 28 | Rear floor sidemember reinforcement, left side | Double sided galvanized steel | — |
| 29 | Rear floor side compartment, right side | High strength steel and double sided galvanized steel | 440 |
| 30 | Rear floor side compartment, left side | High strength steel and double sided galvanized steel | 440 |
| 31 | Rear floor front crossmember | High strength steel and double sided galvanized steel | 440 |
| 32 | Rear floor centre crossmember | High strength steel and double sided galvanized steel | 440 |
| 33 | Rear end panel | Double sided galvanized steel | — |
| 34 | Rear panelling support crossmember | Double sided galvanized steel | — |
Body Side
| Component | Sheet Metal Type | Tensile Strength (MPa) | |
|---|---|---|---|
| 1 | Roof side inner panel | High strength steel | 590 |
| 2 | Lower A-pillar outer panel | High strength steel and double sided galvanized steel | 590 |
| 3 | A-pillar lower brace | High strength steel and double sided galvanized steel | 590 |
| 4 | Front door hinge upper retainer | Double sided galvanized steel | — |
| 5 | B-pillar inner panel | High strength steel | 440 |
| 6 | Sill panel reinforcement | High strength steel and double sided galvanized steel | 590 |
| 7 | B-pillar reinforcement | High strength steel and double sided galvanized steel | 590 |
| 8 | Rear seat belt reinforcement | High strength steel | 440 |
| 9 | Rear wheelhouse inner panel | Double sided galvanized steel | — |
| 10 | Rear wheelhouse outer panel | Double sided galvanized steel | — |
| 11 | Rear wheelhouse outer panel extension | Double sided galvanized steel | — |
| 12 | A-pillar outer panel | Double sided galvanized steel | — |
| 13 | B-pillar outer panel | Double sided galvanized steel | — |
| 14 | Rear quarter panel | Double sided galvanized steel | — |
| 15 | Inner sill panel | Double sided galvanized steel | — |
| 16 | Roof side outer panel | Double sided galvanized steel | — |
| 17 | Rear quarter panel upper extension | Double sided galvanized steel | — |
| 18 | Rear quarter panel lower extension | Double sided galvanized steel | — |
| 19 | Fuel tank filler flap | Double sided galvanized steel | — |
Bonnet, Wings, Doors and Roof
| Component | Sheet Metal Type | Tensile Strength (MPa) | |
|---|---|---|---|
| 1 | Bonnet | High strength steel and double sided galvanized steel | 340 |
| 2 | Roof bow | High strength steel | 590 |
| 3 | Roof panel | Double sided galvanized steel | — |
| 4 | Tailgate shell | Double sided galvanized steel | — |
| 5 | Rear door shell | High strength steel and double sided galvanized steel | 340 |
| 6 | Front door shell | High strength steel and double sided galvanized steel | 340 |
| 7 | Front wing | High strength steel and double sided galvanized steel | 340 |
| 8 | Bonnet hinge | Double sided galvanized steel | — |
