Driver Information System: Removal & Installation Nissan Sentra B16 рестайлинг

INSTALLATION

Installation is in the reverse order of removal.

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. CHECK OIL PRESSURE WARNING LAMP OPERATION Activate IPDM E/R auto active test. Refer to " «AUTO ACTIVE TEST»(ref-367304-S30640850052010072700000) ". Does oil pressure warning lamp blink? YES: GO TO 2. NO: GO TO 5 .
2. CHECK IPDM E/R INPUT SIGNAL Turn ignition switch ON. Check voltage between IPDM E/R harness connector and ground. CONNECTOR TERMINAL VOLTAGE CHART Terminals Condition Voltage (Approx.) (+) (-) IPDM E/R connector Terminal E46 37 Ground Engine stopped 0V OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-367304-S39248582342010072700000) ". NG: GO TO 3.
3. CHECK OIL PRESSURE CIRCUIT Disconnect IPDM E/R connector and oil pressure switch connector (with MR20DE) or double meter connector (with QR25DE). Check continuity between IPDM E/R harness connector E46 (A) terminal 37 and oil pressure switch harness connector F32 (B) terminal 1 (with MR20DE) or double meter connector M89 (C) terminal 6 (with QR25DE). With MR20DE 37 - 1 : Continuity should exist With QR25DE 37 - 6 : Continuity should exist OK or NG OK: With MR20DE, GO TO 4. With QR25DE, refer to " «OIL PRESSURE SENSOR INSPECTION»(ref-367330-S40225067062010072700000) ". NG: Repair harness or connector.
4. CHECK OIL PRESSURE SWITCH Check oil pressure switch. Refer to " «COMPONENT INSPECTION»(ref-367330-S24835119912010072700000) ". OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-367304-S39248582342010072700000) ". NG: Replace oil pressure switch.
5. CHECK CAN COMMUNICATION Select "METER/M&A" on CONSULT-III, and perform self-diagnosis of combination meter. Self-diagnostic results content No malfunction detected: GO TO 6. Malfunction detected: Check applicable parts, and repair or replace as necessary.
6. CHECK COMBINATION METER INPUT SIGNAL Select "METER/M&A" on CONSULT-III. Operate ignition switch with "OIL W/L" of "DATA MONITOR" and check operation status. "OIL W/L" When ignition switch is in ON position (Engine stopped.) : ON When engine running : OFF OK or NG OK: Replace combination meter. Refer to " «REMOVAL AND INSTALLATION»(ref-367337-S36199832012010072700000) ". NG: GO TO 7.
7. CHECK BCM INPUT SIGNAL Select "BCM" on CONSULT-III. Then select "SIGNAL BUFFER". Operate ignition switch with "OIL PRESS SW" of "DATA MONITOR" and check operation status. "OIL PRESS SW" When ignition switch is in ON position (Engine stopped.) : ON When engine running : OFF OK or NG OK: Replace BCM. Refer to " «REMOVAL AND INSTALLATION OF BCM»(ref-367342-S30853949592010072700000) ". NG: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-367304-S39248582342010072700000) ".
