OPERATION PROCEDURE
- Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
- Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
- Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
- Perform the necessary repair operation.
- When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
- Perform a self-diagnosis check of all control units using CONSULT-III.
System Description
BCM (body control module) controls the operation of various electrical units installed on the vehicle.
CAN Communication System Description
Refer to " SYSTEM DESCRIPTION ".
Scheme 116
Scheme 117
Scheme 118
DESCRIPTION
CONFIGURATION has three functions as follows
- READ CONFIGURATION is the function to read (extract) vehicle configuration of current BCM.
- WRITE CONFIGURATION-Manual selection is the function to select and write vehicle configuration on BCM manually.
- WRITE CONFIGURATION-Config file is the function to write vehicle configuration with the data extracted from current BCM.
- For READ CONFIGURATION and WRITE CONFIGURATION-Config file, refer to CONSULT-III Operation Service Information.
- For WRITE CONFIGURATION-Manual selection using the following flow chart, identify the correct model and configuration list. Confirm and/or change setting value for each item according to the configuration list. Depending on CONSULT-III software version being used, some or all of the write configuration items shown in the following configuration lists may be displayed. If an item does not appear on the CONSULT-III WRITE CONFIGURATION-Manual selection screen(s), then it is an auto setting item and it cannot be manually set or changed. NOTE: Confirm vehicle model on IDENTIFICATION PLATE. Refer to " «MODEL VARIATION»(ref-367300-S09776825872010072700000) ". ITEM SPECIFICATIONS ITEM SET VAL KEYLESS ENTRY WITH <--> WITHOUT I-KEY WITH <--> WITHOUT DTRL WITH <--> WITHOUT THEFT ALARM WITH <--> WITHOUT TIRE PRESSURE (1) 230kPa or 240kPa AUTO DOOR UNLOCK TIMING MODE (1) Refer to " «CONSULT-III FUNCTION (BCM)»(ref-367315-S06309428672010072700000) ". CAUTION: When replacing BCM, you must perform WRITE CONFIGURATION with CONSULT-III. Complete the procedure of WRITE CONFIGURATION in order. If you set incorrect WRITE CONFIGURATION, incidents will occur. Configuration is different for each vehicle model. Confirm configuration of each vehicle model.
