OPERATION PROCEDURE
- Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
- Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
- Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
- Perform the necessary repair operation.
- When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
- Perform a self-diagnosis check of all control units using CONSULT-III.
CAN COMMUNICATION SYSTEM DESCRIPTION
Refer to " SYSTEM DESCRIPTION ".
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
System Description
The TCM receives CVT indicator signals from the transmission range switch. The TCM then sends CVT position indicator signals to the combination meter via CAN communication lines. The combination meter indicates the received shift position.
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
- Buzzer for warning chime system is installed in the combination meter.
- The buzzer sounds when combination meter receives buzzer output signal with CAN communication line.
Refer to " SYSTEM DESCRIPTION ".
