TORQUE CONVERTER SERVICE

The torque converter should be replaced under any of the following conditions

  1. External leaks in the hub weld area.
  2. Converter hub is scored or damaged.
  3. Converter pilot is broken, damaged or fits poorly into crankshaft.
  4. Steel particles are found after flushing the cooler and cooler lines.
  5. Pump is damaged or steel particles are found in the converter.
  6. Vehicle has TCC shudder and/or no TCC apply. Replace only after all hydraulic and electrical diagnoses have been made. (Converter clutch material may be glazed.)
  7. Converter is contaminated with engine coolant containing antifreeze.
  8. Internal failure of stator roller clutch.
  9. Heavy clutch debris due to overheating (blue converter).
  10. Steel particles or clutch lining material found in fluid filter or on magnet when no internal parts in unit are worn or damaged - indicates that lining material came from converter. The torque converter should not be replaced if
  11. The fluid has an odor, is discolored, and there is no evidence of metal or clutch facing particles.
  12. The threads in one or more of the converter bolt holes are damaged.
  13. Transaxle failure did not display evidence of damaged or worn internal parts, steel particles or clutch plate lining material in unit and inside the fluid filter.
  14. Vehicle has been exposed to high mileage (only). The exception may be where the torque converter clutch dampener plate lining has seen excess wear by vehicles operated in heavy and/or constant traffic, such as taxi, delivery or police use.

Torque Converter Clutch Solenoid Valve Control

The torque converter clutch solenoid valve is controlled by the TCM. The plunger closes the drain circuit during the OFF period, and opens the circuit during the ON period. If the percentage of OFF-time increases in one cycle, the pilot pressure drain time is reduced and pilot pressure remains high.

Scheme 980

Scheme 980: Torque Converter Clutch Solenoid Valve Control

The torque converter clutch piston is designed to slip to adjust the ratio of ON-OFF, thereby reducing lock-up shock.

OFF-time INCREASING --> Amount of drain DECREASING --> Pilot pressure HIGH --> Lock-up RELEASING

Scheme 981

Scheme 981

Scheme 982

Scheme 982: Torque Converter Clutch Control Valve Operation

General Specifications

EngineQR25DE
Automatic transaxle modelRE4F04B
Automatic transaxle assemblyModel code number85X63
Transaxle gear ratio1st2.785
2nd1.545
3rd1.000
4th0.694
Reverse2.272
Final drive4.087
Recommended fluidNissan Matic "D" (Continental U.S. and Alaska) or Canada Nissan Automatic Transmission Fluid (1)
Fluid capacity l (US qt, Imp qt)8.5 (9, 7.5)
(1) Refer to MA-13. "RECOMMENDED FLUIDS AND LUBRICANTS" .
(1)Refer to MA-13. "RECOMMENDED FLUIDS AND LUBRICANTS" .

General Specifications

Scheme 983

Scheme 983: VEHICLE SPEED WHEN SHIFTING GEARS THROTTLE POSITION

Scheme 984

Scheme 984: VEHICLE SPEED WHEN PERFORMING AND RELEASING LOCK-UP

Note. Lock-up vehicle speed indicates the speed in D4 (O/D ON) position. Perform Lock-up inspection after warming up engine. Lock-up vehicle speed may vary depending on the driving conditions and circumstances.

Scheme 985

Scheme 985: Stall Revolution

Scheme 986

Scheme 986: Line Pressure

Scheme 987

Scheme 987: CONTROL VALVE AND PLUG RETURN SPRINGS

Scheme 988

Scheme 988: O-RING

Scheme 989

Scheme 989: RETURN SPRING

Scheme 990

Scheme 990: REVERSE CLUTCH

Scheme 991

Scheme 991: HIGH CLUTCH

Scheme 992

Scheme 992: FORWARD CLUTCH

Scheme 993

Scheme 993

Scheme 994

Scheme 994: OVERRUN CLUTCH

Scheme 995

Scheme 995: LOW & REVERSE BRAKE

Scheme 996

Scheme 996: CLUTCH AND BRAKE RETURN SPRINGS

Scheme 997

Scheme 997: BRAKE BAND

Scheme 998

Scheme 998: DIFFERENTIAL SIDE GEAR CLEARANCE

Scheme 999

Scheme 999: DIFFERENTIAL SIDE GEAR THRUST WASHERS

Scheme 1000

Scheme 1000: DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTING SHIMS

Scheme 1001

Scheme 1001: BEARING PRELOAD

Scheme 1002

Scheme 1002: TURNING TORQUE

Scheme 1003

Scheme 1003: PLANETARY CARRIER

Scheme 1004

Scheme 1004: OIL PUMP

Scheme 1005

Scheme 1005: SEAL RING CLEARANCE

Scheme 1006

Scheme 1006: SEAL RING

Scheme 1007

Scheme 1007: TURNING TORQUE

Scheme 1008

Scheme 1008: REDUCTION PINION GEAR BEARING ADJUSTING SHIMS

Scheme 1009

Scheme 1009

Scheme 1010

Scheme 1010: RETURN SPRING

Scheme 1011

Scheme 1011: SEAL RING CLEARANCE

Scheme 1012

Scheme 1012: SEAL RING

Scheme 1013

Scheme 1013: END PLAY

Scheme 1014

Scheme 1014: OUTPUT SHAFT ADJUSTING SHIMS

Scheme 1015

Scheme 1015: SEAL RING CLEARANCE

Scheme 1016

Scheme 1016: Total End Play

Scheme 1017

Scheme 1017: BEARING RACE FOR ADJUSTING TOTAL END PLAY

Scheme 1018

Scheme 1018: Reverse Clutch End Play

Scheme 1019

Scheme 1019: THRUST WASHERS FOR ADJUSTING REVERSE CLUTCH DRUM END PLAY

Scheme 1020

Scheme 1020: Removal and Installation

Scheme 1021

Scheme 1021: Shift Solenoid Valves

Scheme 1022

Scheme 1022: Solenoid Valves

Scheme 1023

Scheme 1023: A/T Fluid Temperature Sensor

Scheme 1024

Scheme 1024: Revolution Sensor

Scheme 1025

Scheme 1025: Dropping Resistor

Scheme 1026

Scheme 1026: Turbine Revolution Sensor
