Automatic Transaxle - RE4F03B: Maintenance Nissan Sentra B15

FLUID LEVEL CHECK

see scheme 426

Scheme 482

1. Check A/T fluid and engine oil levels. If necessary, add.
2. Drive vehicle for approx. 10 minutes or until fluid and oil reach operating temperature. ATF operating temperature: 50 - 80°C (122 - 176°F)
3. Set parking brake and block wheels.
4. Install a tachometer where it can be seen by driver during test. It is good practice to mark the point of specified engine RPM on indicator.
5. Start engine, apply foot brake, and place selector lever in "D" position.
6. Accelerate to wide open throttle gradually while applying foot brake.
7. Quickly note the engine stall revolution and immediately release throttle. During test, never hold throttle wide open for more than 5 seconds. Stall revolution QG18DE: 2,350 - 2,800 RPM
8. Move selector lever to "N" position.
9. Cool off ATF. Run engine at idle for at least one minute.
10. Repeat steps 5 through 9 with selector lever in "2""1" and "R" positions.

Scheme 483

A/T FLUID TEMPERATURE SENSOR

1. For removal, refer to " «CONTROL VALVE ASSEMBLY AND ACCUMULATORS»(ref-214136-S18301516902005123100000) ".
2. Check resistance between two terminals while changing temperature as shown at left.

Scheme 484

Scheme 485
