Automatic Transaxle - RE4F03B: Specifications Nissan Sentra B15

Automatic Trans 49 illustrations ~446 words

TORQUE CONVERTER SERVICE

The torque converter should be replaced under any of the following conditions

  1. External leaks in the hub weld area.
  2. Converter hub is scored or damaged.
  3. Converter pilot is broken, damaged or fits poorly into crankshaft.
  4. Steel particles are found after flushing the cooler and cooler lines.
  5. Pump is damaged or steel particles are found in the converter.
  6. Vehicle has TCC shudder and/or no TCC apply. Replace only after all hydraulic and electrical diagnoses have been made. (Converter clutch material may be glazed.)
  7. Converter is contaminated with engine coolant containing antifreeze.
  8. Internal failure of stator roller clutch.
  9. Heavy clutch debris due to overheating (blue converter).
  10. Steel particles or clutch lining material found in fluid filter or on magnet when no internal parts in unit are worn or damaged - indicates that lining material came from converter.

The torque converter should not be replaced if

  1. The fluid has an odor, is discolored, and there is no evidence of metal or clutch facing particles.
  2. The threads in one or more of the converter bolt holes are damaged.
  3. Transaxle failure did not display evidence of damaged or worn internal parts, steel particles or clutch plate lining material in unit and inside the fluid filter.
  4. Vehicle has been exposed to high mileage (only). The exception may be where the torque converter clutch dampener plate lining has seen excess wear by vehicles operated in heavy and/or constant traffic, such as taxi, delivery or police use.

Torque Converter Clutch Solenoid Valve Control

The torque converter clutch solenoid valve is controlled by the TCM. The plunger closes the drain circuit during the "OFF" period, and opens the circuit during the "ON" period. If the percentage of OFF-time increases in one cycle, the pilot pressure drain time is reduced and pilot pressure remains high.

Scheme 14

Scheme 14: Torque Converter Clutch Solenoid Valve Control

The torque converter clutch piston is designed to slip to adjust the ratio of ON-OFF, thereby reducing lock-up shock.

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17: Torque Converter Clutch Control Valve Operation

TORQUE CONVERTER CLUTCH SOLENOID VALVE

  1. Refer to " «REMOVAL»(ref-214136-S12951281622005123100000) ".

General Specifications

EngineQG18DE
Automatic transaxle modelRE4F03B
Automatic transaxle assemblyModel code number3AX60
Transaxle gear ratio1st2.861
2nd1.562
3rd1.000
4th0.698
Reverse2.230
Final drive3.827
Recommended fluidNissan Matic "D" (Continental U.S. and Alaska) or Genuine Nissan Automatic Transmission Fluid (Canada) (1)
Fluid capacity7.0I (7-3/8 US qt, 6-1/8 Imp qt)
(1) Refer to MA-13. "Fluids and Lubricants" .
(1)Refer to MA-13. "Fluids and Lubricants" .

General Specifications

Scheme 18

Scheme 18: QG18DE (Calif. CA Model)

Scheme 19

Scheme 19: QG18DE (Except Calif. CA Model)

Scheme 20

Scheme 20: QG18DE (Calif. CA Model)

Scheme 21

Scheme 21: QG18DE (Except Calif. CA Model)

Scheme 22

Scheme 22: Stall Revolution

Scheme 23

Scheme 23: Line Pressure

Scheme 24

Scheme 24: CONTROL VALVE AND PLUG RETURN SPRINGS

Scheme 25

Scheme 25: REVERSE CLUTCH

Scheme 26

Scheme 26: HIGH CLUTCH

Scheme 27

Scheme 27: FORWARD CLUTCH

Scheme 28

Scheme 28: OVERRUN CLUTCH

Scheme 29

Scheme 29: LOW & REVERSE BRAKE

Scheme 30

Scheme 30

Scheme 31

Scheme 31: BRAKE BAND

Scheme 32

Scheme 32: Clutch and Brake Return Springs

Scheme 33

Scheme 33: Oil Pump

Scheme 34

Scheme 34: Input Shaft

Scheme 35

Scheme 35: Planetary Carrier

Scheme 36

Scheme 36: DIFFERENTIAL SIDE GEAR CLEARANCE

Scheme 37

Scheme 37: DIFFERENTIAL SIDE GEAR THRUST WASHERS

Scheme 38

Scheme 38: BEARING PRELOAD

Scheme 39

Scheme 39: TURNING TORQUE

Scheme 40

Scheme 40: DIFFERENTIAL SIDE BEARING ADJUSTING SHIMS

Scheme 41

Scheme 41: TABLE FOR SELECTING DIFFERENTIAL SIDE BEARING ADJUSTING SHIMS

Scheme 42

Scheme 42: BEARING PRELOAD

Scheme 43

Scheme 43: TURNING TORQUE

Scheme 44

Scheme 44: REDUCTION PINION GEAR BEARING ADJUSTING SHIMS

Scheme 45

Scheme 45: TABLE FOR SELECTING REDUCTION PINION GEAR BEARING ADJUSTING SHIM

Scheme 46

Scheme 46: SEAL RING CLEARANCE

Scheme 47

Scheme 47: END PLAY

Scheme 48

Scheme 48: OUTPUT SHAFT END PLAY ADJUSTING SHIMS

Scheme 49

Scheme 49: SEAL RING CLEARANCE

Scheme 50

Scheme 50: Total End Play

Scheme 51

Scheme 51: BEARING RACE FOR ADJUSTING TOTAL END PLAY

Scheme 52

Scheme 52: Reverse Clutch End Play

Scheme 53

Scheme 53: THRUST WASHERS FOR ADJUSTING REVERSE CLUTCH END PLAY

Scheme 54

Scheme 54: O-RING

Scheme 55

Scheme 55: RETURN SPRING

Scheme 56

Scheme 56: RETURN SPRING

Scheme 57

Scheme 57: Removal and Installation

Scheme 58

Scheme 58: Shift Solenoid Valves

Scheme 59

Scheme 59: Solenoid Valve

Scheme 60

Scheme 60: A/T Fluid Temperature Sensor

Scheme 61

Scheme 61: Revolution Sensor

Scheme 62

Scheme 62: Dropping Resistor
