Audio, Visual & Navigation System (Bose Audio Without Navigation): Specifications Nissan Quest IV

Entertainment Systems 11 illustrations ~490 words

Specification

Manufacturer namePanasonic corporation
Audio amplifierExternal amplifier
CD/DVD driveUsed discØ 12 cm (4.7 in)
Playable discCDCD-ROM (CD-DA)
CD-R (1)
CD-RW (1)
DVDDVD-ROM
DVD-R (1)
DVD-RW (1)
Playable formatMusicMP3
WMA
ImageDVD-VIDEO
VIDEO-CD
Text display functionID3/WMA tagArtist name
Album title
Song title
USBHigh communication standardUSB1.1
Playable formatMusicMP3
WMA
Text display functionID3/WMA tagArtist name
Album title
Song title
IPod®Action (2)IPod Classic® 1st generation
IPod Classic® 2nd generation
IPod nano® 3rd generation
IPod nano® 2nd generation
IPod nano® 1st generation
IPod® 5th generation
IPod touch® 1st generation
IPod touch® 2nd generation
IPhone 3rd generation
Flash memoryTotal capacity2 GB
Camera controllerGuideline display functionWidth/distance display
Predictive course lines display/non-display switch
Steering angle signal input methodCAN communication
Other functionsSpeed sensitive volume function
Steering switch compliant
(1) If the reflectance of the surface of the media is low, the data may not be read. (2) It may not be used if it is not updated to the latest firmware or partial functions may not work if it is used.
(1)If the reflectance of the surface of the media is low, the data may not be read.
(2)It may not be used if it is not updated to the latest firmware or partial functions may not work if it is used.

Scheme 120

Scheme 120: Front Display Unit
  1. The front display unit has an 7-inch QVGA liquid-crystal display.
  2. It receives the power (signal VCC and inverter VCC) from the AV control unit and operates.
  3. Composite image signals (DVD, USB memory-stored video data, auxiliary input, and camera) are input from AV control unit.
  4. RGB image signal is input from AV control unit (RGB, RGB area and RGB synchronizing).
  5. Synchronizing signal (HP, VP) is output to AV control unit.
  6. This unit is connected to the AV control unit via serial communication. Images shown on the front display unit are controlled by the AV control unit.
Manufacturer namePanasonic corporation
Screen size7-inch QVGA [154.08 x 86.58 mm (6.1 x 3.4 in)]
Number of pixels480 x 234 pixels

Scheme 121

Scheme 121: Rear Display Unit
  1. The rear display unit has an 11-inch WVGA* liquid-crystal display and a remote-control automatic folding function.
  2. Composite image signal [USB (video data), DVD and auxiliary input] and headphone sound signal are input from AV control unit.
  3. A remote control operation signal is received through the built-in light-receptive spot (1).
  4. The display brightness is adjusted automatically, according to ambient brightness. *: WVGA (Wide VGA) is a standard of the resolution of the display. It extended width of VGA.
Manufacturer nameClarion Co., Ltd.
Screen size11-inch WVGA [243.6 mm x 137.52mm (9.6 in x 5.4 in)]
Number of pixels800 x 480 pixels

Scheme 122

Scheme 122: Multifunction Switch
  1. The multifunction switch is an integrated switch that combines the audio operation and other operations switches. This integrated switch is located in the lower part of the front display unit.
  2. Connected with preset switch via hardwire and operation signal is transmitted to AV control unit via AV communication.

Scheme 123

Scheme 123: PRESET SWITCH
  1. The preset switch is separated from the multifunction switch and capable of audio operation.
  2. Operation signals of the multifunction switch and the preset switch are transmitted to the AV control unit via AV communication.

Scheme 124

Scheme 124: Disk Eject Switch
  1. The disk eject switch is used for removing CD/DVD from the AV control unit.
  2. When the disk eject switch is pressed, a disk eject signal is transmitted to the AV control unit, and the AV control unit ejects CD/DVD.

Scheme 125

Scheme 125: Steering Switch
  1. Operations for audio and hands-free phone, etc. are possible.
  2. This switch is connected to the AV control unit, and the switch operation signal is transmitted to the AV control unit via voltage multiplex communication.

Scheme 126

Scheme 126: BOSE Amp.
  1. Installed to the luggage floor box.
  2. Receives sound signal from AV control unit, and outputs sound signal to each speaker and woofer.
Manufacturer namePanasonic corporation
Image pickup element1/4-inch interline CCD color
Effective number of pixelsApprox. 250, 000 pixels (510 x 492)
Minimum brightness2 lx
Angle of viewH: 137° V: 92°
ImageWith mirror processing function

Scheme 127

Scheme 127: Steering Angle Sensor
  1. Steering sensor is installed to the spiral cable.
  2. Steering angle sends the steering signal necessary for predictive course line of the rear view monitor function to the AV control unit via CAN communication.

Scheme 128

Scheme 128: RADIO ANTENNA
  1. AM/FM radio main antenna is located on the right rear side window glass and FM radio sub antenna on the left rear side window glass.
  2. The AM/FM radio main antenna path has an antenna amp. to obtain sufficient reception power.
CAUTIONAffixing any mirror-type window films or metallic items (e.g. commercial antenna) on the rear side window glass causes a reduction in the radio receiver sensitivity.

Scheme 129

Scheme 129: ANTENNA FEEDER LAYOUT

Scheme 130

Scheme 130: Satellite Radio Tuner
  1. Inputs the satellite radio signal from satellite radio antenna and outputs the sound signal to the AV control unit.
  2. It is controlled with the AV control unit and serial communication (communication signal and request signal).
