Audio, Visual & Navigation System (Bose Audio with Navigation): Specifications Nissan Quest IV

Entertainment Systems 12 illustrations ~488 words

Specification

Manufacturer nameClarion Co., Ltd.
HDDTotal capacity40 GB
Map data capacityApplox. 20 GB
Audio amplifierExternal amplifier
CD/DVD driveUsed discØ 12 cm (4.7 in)
Playable discCDCD-ROM (CD-DA)
CD-R (1)
CD-RW (1)
DVDDVD-ROM
DVD±R (1)
DVD±RW (1)
DVD±R DL (1)
Playable formatMusicMP3
WMA
AAC
ImageDVD-VIDEO
VIDEO-CD
DVD-VR
MPEG4-ASF
DivX®
Text display functionID3/WMA/AAC tagArtist name
Album title
Song title
USBHigh communication standardUSB2.0
Playable formatMusicMP3
WMA
AAC
ImageMPEG4-ASF
DivX®
Image viewerJPEG
Text display functionID3/WMA/AAC tagArtist name
Album title
Song title
IPod®Action (2)IPod Classic®
IPod nano® 4th generation
IPod nano® 3rd generation
IPod nano® 2nd generation
IPod nano® 1st generation
IPod® 5th generation
IPod touch® 1st generation
IPod touch® 2nd generation
Bluetooth® audioCompliant communication typeWireless connectionBluetooth® communication
Compliant profileA2DP 1.2
AVRCP 1.3
Hands-free phoneCompliant communication typeWireless connectionBluetooth® communication compliant type
Compliant profileHFP 1.0, 1.5
DUN 1.1
OPP 1.1
Other functionsSpeed sensitive volume function
Steering switch compliant
Voice recognition function
(1) If the reflectance of the surface of the media is low, the data may not be read. (2) It may not be used if it is not updated to the latest firmware or partial functions may not work if it is used.
(1)If the reflectance of the surface of the media is low, the data may not be read.
(2)It may not be used if it is not updated to the latest firmware or partial functions may not work if it is used.

Scheme 1

Scheme 1: Front Display Unit
  1. The front display unit has a high-resolution 8-inch WVGA* display and a touch panel function.
  2. RGB digital image signal and composite image signal [USB (video data), DVD and auxiliary input] are input from AV control unit.
  3. Camera image signal is input from rear view camera.
  4. This unit is connected to the AV control unit via serial communication. Images shown on the front display unit are controlled by the AV control unit.
  5. Touch panel operation signal is output to the AV control unit by serial communication.

*: WVGA (Wide VGA) is a standard of the resolution of the display. It extended width of VGA.

Manufacturer nameJohnson controls KK
Touch panel detection4 wires analogue resistive film type
Screen size8-inch WVGA [174 mm x 104.4 mm (6.9 in x 4.1 in)]
Number of pixels800 x 480 pixels
Manufacturer nameClarion Co., Ltd.
Screen size11-inch WVGA [243.6 mm x 137.52mm (9.6 in x 5.4 in)]
Number of pixels800 x 480 pixels

Scheme 2

Scheme 2: Multifunction Switch
  1. The multifunction switch is an integrated switch that combines the navigation operation, audio operation, and other operations switches. This integrated switch is located in the lower part of the front display unit to facilitate the use in combination with the touch panel.
  2. Connected with preset switch via hardwire and operation signal is transmitted to AV control unit via AV communication.

Scheme 3

Scheme 3: PRESET SWITCH
  1. The preset switch is separated from the multifunction switch and capable of audio operation.
  2. Operation signals of the multifunction switch and the preset switch are transmitted to the AV control unit via AV communication.

Scheme 4

Scheme 4: Disk Eject Switch
  1. The disk eject switch is used for removing CD/DVD from the AV control unit.
  2. When the disk eject switch is pressed, a disk eject signal is transmitted to the AV control unit, and the AV control unit ejects CD/DVD.

Scheme 5

Scheme 5: Steering Switch
  1. Operations for navigation, audio, and hands-free phone, etc. are possible.
  2. This switch is connected to the AV control unit, and the switch operation signal is transmitted to the AV control unit via voltage multiplex communication.

Scheme 6

Scheme 6: BOSE Amp.
  1. Installed to the luggage floor box.
  2. Receives sound signal from AV control unit, and outputs sound signal to each speaker and woofer.
Manufacturer nameSONY Corp.
Image pickup element1/4-inch CMOS image sensor
Effective number of pixelsApprox. 300, 000 pixels (632 x 480)
Minimum brightness1 lx
Angle of viewH: 190.4° V: 141.8°
ImageWith mirror processing function
Manufacturer nameSONY Corp.
Image pickup element1/4-inch CMOS image sensor
Effective number of pixelsApprox. 300, 000 pixels (632 x 480)
Minimum brightness1 lx
Angle of viewH: 190.4° V: 141.8°
Manufacturer nameSONY Corp.
Image pickup element1/4-inch CMOS image sensor
Effective number of pixelsApprox. 300, 000 pixels (632 x 480)
Minimum brightness1 lx
Angle of viewH: 190.4° V: 141.8°

Scheme 7

Scheme 7: Steering Angle Sensor
  1. Steering sensor is installed to the spiral cable.
  2. Steering angle sends the steering signal necessary for predictive course line of the rear view monitor function to the AV control unit via CAN communication.

Scheme 8

Scheme 8: Microphone
  1. The voice control/TEL microphone is installed on the left side of the map lamp assembly.
  2. The power is supplied from the AV control unit to the microphone, transmitting sound signals to the AV control unit at the voice control or during hands-free phone communication.

Scheme 9

Scheme 9: USB Connector
  1. USB connector is installed to the console box.
  2. iPod® and USB memory can be connected to the AV control unit.

Scheme 10

Scheme 10: Auxiliary Input Jacks
  1. Installed to the rear of center console.
  2. Sound signals and image signals from the external equipment are transmitted to the AV control unit.

Scheme 11

Scheme 11: RADIO ANTENNA
  1. AM/FM radio main antenna is located on the right rear side window glass and FM radio sub antenna on the left rear side window glass.
  2. The AM/FM radio main antenna path has an antenna amp. to obtain sufficient reception power.
CAUTIONAffixing any mirror-type window films or metallic items (e.g. commercial antenna) on the rear side window glass causes a reduction in the radio receiver sensitivity.

Scheme 12

Scheme 12: ANTENNA FEEDER LAYOUT
