Audio, Visual & Navigation System (Base Audio Without Separate Display): Removal & Installation Nissan Quest IV

Entertainment Systems 1 illustration ~169 words

REMOVAL

  1. Remove cluster lid D. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
  2. Remove audio unit mounting screws.
  3. Pull out audio unit, and then disconnect antenna feeder and harness connectors.
  4. Remove audio unit and brackets as a single unit.
  5. Remove brackets from audio unit.

INSTALLATION

Install in the reverse order of removal.

  1. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S07016970752014112400000) ".
  2. Remove front door speaker screws and disconnect front door speaker connector.

Install in the reverse order of removal.

  1. Remove slide door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S21571296292014112400000) ".
  2. Remove screws and disconnect connector, and remove slide door speaker.

Install in the reverse order of removal.

  1. Remove rear pillar garnish RH. Refer to " «REAR PILLAR GARNISH: REMOVAL AND INSTALLATION»(ref-672656-S12526951132014112400000) ".
  2. Remove screw and disconnect connector, and remove antenna amp.

Install in the reverse order of removal.

Scheme 376

Scheme 376: Feeder Layout
Scheme 376: Feeder Layout

"tringle": Indicates that the part is connected at points with same symbol in actual vehicle.
