FLUSHING COOLING SYSTEM

1. Drain the water from the engine cooling system. Refer to " «ENGINE COOLANT: CHANGING ENGINE COOLANT»(ref-519787-S11916793722012122900000) ".
2. Fill the radiator and the reservoir tank (to the "MAX" line), with water. Reinstall the radiator cap and leave the vented reservoir cap off.
3. Run the engine until it reaches normal operating temperature.
4. Press the engine accelerator two or three times under no-load.
5. Stop the engine and wait until it cools down.
6. Drain the water from the engine cooling system. Refer to " «ENGINE COOLANT: CHANGING ENGINE COOLANT»(ref-519787-S11916793722012122900000) ".
7. Repeat steps 2 through 6 until clear water begins to drain from the radiator.

REFILLING ENGINE COOLANT

1. Close the radiator drain plug. Install the reservoir tank, cylinder block drain plug, and the oil cooler hose if removed for a total system drain or for engine removal or repair. The radiator must be completely empty of coolant and water. Apply sealant to the threads of the cylinder block drain plug. Use Genuine High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-519769-S26436216272012122900000) ". Radiator drain plug: Refer to " «ENGINE COOLANT: CHANGING ENGINE COOLANT»(ref-519787-S19756130972012122900000) ". RH cylinder block drain plug: Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519778-S07904921452012122900000) ".
2. Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with the engine OFF as necessary to activate the heater mode.
3. Remove the vented reservoir cap and replace it with a non-vented reservoir cap before filling the cooling system.
4. Install the Tool by installing the radiator cap adapter onto the radiator neck opening. Then attach the gauge body assembly with the refill tube and the venturi assembly to the radiator cap adapter. Tool number: KV991J0070 (J-45695)
5. Insert the refill hose into the coolant mixture container that is placed at floor level. Make sure the ball valve is in the closed position. Use recommended coolant or equivalent. Refer to " «FOR USA AND CANADA: FLUIDS AND LUBRICANTS»(ref-519787-S11601431122012122900000) ". Cooling system capacity (with reservoir): Refer to " «FOR USA AND CANADA: FLUIDS AND LUBRICANTS»(ref-519787-S11601431122012122900000) ".
6. Install an air hose to the venturi assembly, the air pressure must be within specification. Compressed air supply pressure: 549 - 824 kPa (5.6 - 8.4 kg/cm 2 , 80 - 119 psi) CAUTION: The compressed air supply must be equipped with an air dryer.
7. The vacuum gauge will begin to rise and there will be an audible hissing noise. During this process open the ball valve on the refill hose slightly. Rising coolant will be visible in the refill hose. After the refill hose is full of coolant, close the ball valve. This will purge air trapped in the refill hose.
8. Continue to draw the vacuum until the gauge reaches 28 inches of vacuum. The gauge may not reach 28 inches in high altitude locations. Refer to the following table for expected vacuum readings. Altitude above sea level Vacuum gauge reading 0 - 100 m (328 ft): 28 inches of vacuum 300 m (984 ft): 27 inches of vacuum 500 m (1, 641 ft): 26 inches of vacuum 1, 000 m (3, 281 ft): 24 - 25 inches of vacuum
9. When the vacuum gauge has reached the specified amount, disconnect the air hose and wait 20 seconds to see if the system loses vacuum. If the vacuum level drops, perform necessary repairs to the system and repeat steps 6 - 8 to bring the vacuum to the specified amount. Recheck for leaks.
10. Place the coolant container (with the refill hose inserted) at the same level as the top of the radiator. Then open the ball valve on the refill hose so the coolant will be drawn up to fill the cooling system. The cooling system is full when the vacuum gauge reads zero. CAUTION: Do not allow the coolant container to get too low when filling, to avoid air from being drawn into the cooling system.
11. Remove the Tool from the radiator neck opening and install the radiator cap.
12. Remove the non-vented reservoir cap.
13. Fill the cooling system reservoir tank to the specified level. Run the engine to warm up the cooling system and top up the system as necessary before installing the vented reservoir cap.

1. Drain the water from the engine cooling system. Refer to " «CHANGING ENGINE COOLANT»(ref-519776-S40250594332012122900000) ".
2. Fill the radiator and the reservoir tank (to the "MAX" line), with water. Reinstall the radiator cap and leave the vented reservoir cap off.
3. Run the engine until it reaches normal operating temperature.
4. Press the engine accelerator two or three times under no-load.
5. Stop the engine and wait until it cools down.
6. Drain the water from the engine cooling system. Refer to " «CHANGING ENGINE COOLANT»(ref-519776-S40250594332012122900000) ".
7. Repeat steps 2 through 6 until clear water begins to drain from the radiator.

A/T FLUID: Checking the A/T Fluid (ATF)

Scheme 14

Scheme 15

Scheme 16

1. Before driving, the A/T fluid level can be checked at A/T fluid temperatures of 30° to 50°C (86° to 122°F) using the "COLD" range on the A/T fluid level gauge as follows: Park the vehicle on a level surface and set the parking brake. Start the engine and move the selector lever through each gear position. Shift the selector lever into the "P" position. Check the A/T fluid level with the engine idling. Remove the A/T fluid level gauge and wipe it clean with a lint-free paper. CAUTION: When wiping the A/T fluid from the A/T fluid level gauge, always use a lint-free paper, not a cloth. Re-insert the A/T fluid level gauge into the A/T fluid charging pipe until the cap contacts the top of the A/T fluid charging pipe as shown. CAUTION: To check A/T fluid level, insert the A/T fluid level gauge until the cap contacts the top of the A/T fluid charging pipe, with the gauge reversed from the normal inserted position. Remove the A/T fluid level gauge and note the A/T fluid level. If the A/T fluid level is at low side of range, add A/T fluid to the transmission through the A/T fluid charging pipe. CAUTION: Do not overfill the transmission with A/T fluid. Install the A/T fluid level gauge and the A/T fluid level gauge bolt. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD) .
2. Warm up the engine and transmission.
3. Check for any A/T fluid leaks.
4. Drive the vehicle to increase the A/T fluid temperature to 80°C (176°F).
5. Allow the A/T fluid temperature to fall to approximately 65°C (149°F). Use the CONSULT to monitor the A/T fluid temperature as follows: NOTE: The A/T fluid level will be significantly affected by the A/T fluid temperature as shown in illustration above. Therefore monitor the A/T fluid temperature data using the CONSULT. Connect CONSULT to data link connector. Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT. Read out the value of "ATF TEMP 1".
6. Re-check the A/T fluid level at A/T fluid temperatures of approximately 65°C (149°F) using the "HOT" range on the A/T fluid level gauge as shown. The HOT range is between 50° - 80°C (122° - 176°F). CAUTION: When wiping the A/T fluid from the A/T fluid level gauge, always use lint-free paper, not a cloth. To check the A/T fluid level, insert the A/T fluid level gauge until the cap contacts the top of the A/T fluid charging pipe, with the gauge reversed from the normal inserted position as shown.
7. Check the A/T fluid condition. If the A/T fluid is very dark or has some burned smell, there may be an internal problem with the transmission. Refer to «WIRING DIAGRAM»(ref-519782-S13494545242012122900000) . Flush the transmission cooling system after repairing the transmission. If the A/T fluid contains frictional material (clutches, bands, etc.), replace the radiator and flush the transmission cooler lines using cleaning solvent and compressed air after repairing the transmission.
8. Install the A/T fluid level gauge in the A/T fluid charging pipe.
9. Tighten the A/T fluid level gauge bolt to specification.

A/T fluid level gauge bolt: Refer to " 2WD: EXPLODED VIEW " (2WD) or " 4WD: EXPLODED VIEW " (4WD).

A/T FLUID: Changing the A/T Fluid (ATF)

1. Drive the vehicle to warm up the A/T fluid to approximately 80°C (176°F).
2. Stop the engine.
3. Remove the A/T fluid level gauge.
4. Drain the A/T fluid from the drain plug hole, then install the drain plug with a new gasket. Refill the transmission with new A/T fluid. Always refill with the same volume as the drained A/T fluid. Use the A/T fluid level gauge to check the A/T fluid level as shown in illustration below. Add A/T fluid as necessary. Drain plug: Refer to " «REMOVAL AND INSTALLATION»(ref-519782-S27780927392012122900000) ". To flush out the old A/T fluid from the transmission oil coolers, pour new A/T fluid into the A/T fluid charging pipe with the engine idling and at the same time drain the old A/T fluid from the auxiliary transmission oil cooler hose return line. When the color of the A/T fluid coming out of the auxiliary transmission oil cooler hose return line is about the same as the color of the new A/T fluid, flushing out the old A/T fluid is complete. The amount of new A/T fluid used for flushing should be 30% to 50% increase of the specified capacity. A/T fluid grade and capacity: Refer to " «FOR USA AND CANADA: FLUIDS AND LUBRICANTS»(ref-519787-S11601431122012122900000) " (United States and Canada or " «FOR MEXICO: PERIODIC MAINTENANCE SCHEDULE»(ref-519787-S15489281182012122900000) " (Mexico). CAUTION: If Genuine NISSAN Matic S ATF is not available, Genuine NISSAN Matic J ATF may also be used. Using automatic transmission fluid other than Genuine NISSAN Matic S or Matic J will cause deterioration in driveability. and may damage automatic transmission, which is not covered by the NISSAN new vehicle limited warranty. When filling the transmission with A/T fluid, do not spill the A/T fluid on any heat generating parts such as the exhaust manifold. Do not reuse the drain plug gasket.
5. Install the A/T fluid level gauge and tighten the A/T fluid level gauge bolt to specification. A/T fluid level gauge bolt: Refer to " «2WD: EXPLODED VIEW»(ref-519782-S12129575412012122900000) " (2WD) or " «4WD: EXPLODED VIEW»(ref-519782-S15494186702012122900000) " (4WD).
6. Drive the vehicle to warm up the A/T fluid to approximately 80°C (176°F).
7. Check the fluid level and condition. If the A/T fluid is still dirty, repeat steps 2 through 6.
8. Install the A/T fluid level gauge in the A/T fluid charging pipe and install the A/T fluid level gauge bolt.
9. Tighten the A/T fluid level gauge bolt to specification.

A/T fluid level gauge bolt: Refer to " 2WD: EXPLODED VIEW " (2WD) or " 4WD: EXPLODED VIEW " (4WD).

DRAINING

1. Stop engine.
2. Remove the drain plug and gasket and drain the fluid.
3. Install the drain plug with a new gasket to the transfer. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519796-S10368058972012122900000) ".

Scheme 17

1. Stop the engine.
2. Remove the drain plug and gasket from the front final drive assembly to drain the differential gear oil.
3. Install the drain plug with a new gasket to the front final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519784-S23003312432012122900000) ".

Scheme 18

1. Stop the engine.
2. Remove the drain plug from the front final drive assembly to drain the differential gear oil.
3. Install the drain plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519789-S31222193232012122900000) ".

1. Use High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-519769-S26436216272012122900000) ".

FILLING

1. Remove the filler plug from the front final drive assembly.
2. Fill the front final drive assembly with new differential gear oil until the level reaches the specified level near the filler plug hole. Differential gear oil grade and capacity: Refer to " «FOR USA AND CANADA: FLUIDS AND LUBRICANTS»(ref-519787-S11601431122012122900000) " (United States and Canada) or " «FOR MEXICO: FLUIDS AND LUBRICANTS»(ref-519787-S16078382952012122900000) " (Mexico).
3. Install the filler plug with sealant applied on the threads to the front final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519789-S31222193232012122900000) ".

1. Use High Performance Thread Sealant or equivalent. Refer to " «RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS»(ref-519769-S26436216272012122900000) ".

1. Stop the engine.
2. Remove the drain plug and gasket from the rear final drive assembly to drain the differential gear oil.
3. Install the drain plug with a new gasket to the rear final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519816-S18492826882012122900000) ".

Scheme 19

1. Stop the engine.
2. Remove the drain plug and gasket from the rear final drive assembly to drain the differential gear oil.
3. Install the drain plug with a new gasket to the rear final drive assembly. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-519818-S36233440872012122900000) ".

BRAKE FLUID LEVEL AND LEAKS: Checking Brake Fluid Level and Leaks

1. Check the brake fluid level in the reservoir tank. It should be between the "MAX" and "MIN" lines on the reservoir tank.
2. Visually check around reservoir tank for fluid leaks.
3. If the fluid level is extremely low, check the brake system.
4. If the brake warning lamp comes on when the fluid is at the correct level, check the brake fluid level switch and the parking brake switch.

Scheme 20

BRAKE FLUID LEVEL AND LEAKS: Drain and Refill

Scheme 21

1. Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector or battery negative terminal.
2. Connect a vinyl tube to each bleed valve.
3. Depress brake pedal, loosen each bleed valve, and gradually remove brake fluid.
4. Make sure there is no foreign material in reservoir tank, and refill with new brake fluid.
5. Rest foot on brake pedal. Loosen bleed valve. Slowly depress brake pedal until it stops. Tighten bleed valve. Release brake pedal. Repeat the process a few times, then pause to add new brake fluid to master cylinder. Continue until the new brake fluid flows out of the bleed valve.

Bleed the air out of the brake hydraulic system. Refer to " BLEEDING BRAKE SYSTEM ".

Scheme 22

POWER STEERING FLUID AND LINES: Checking Fluid Level

Check fluid level, referring to the scale on the reservoir tank.

Use HOT range for fluid temperatures of 50°- 80°C (122°- 176°F). Use COLD range for fluid temperatures of 0°- 30°C (32°- 86°F).

Scheme 23

POWER STEERING FLUID AND LINES: Checking Fluid Leakage

Check the hydraulic piping lines for improper attachment, leaks, cracks, damage, loose connections, chafing and deterioration.

1. Run the engine until the fluid temperature reaches 50° - 80°C (122° - 176°F) in the reservoir tank. Keep engine speed idle. CAUTION: Do not allow steering fluid reservoir tank to go below the MIN level line. Check tank frequently and add fluid as needed.
2. Turn the steering wheel to the right and left several times.
3. Hold the steering wheel at each "locked" position for five seconds to check for fluid leakage. CAUTION: Do not hold steering wheel in the locked position for more than 10 seconds. (There is the possibility that the oil pump may be damaged.)
4. If fluid leakage at a connection is noticed, loosen the connection and then retighten. Do not over-tighten connector as this can damage O-ring, washer and connector. Refer to «POWER STEERING OIL PUMP»(ref-519785-S40565999822012122900000) and «HYDRAULIC LINE»(ref-519785-S26584635002012122900000) .
5. If fluid leakage from the oil pump is noticed, check the oil pump. Refer to «POWER STEERING OIL PUMP»(ref-519785-S40565999822012122900000) .
6. Check steering gear boots for accumulation of fluid, indicating a leak from the steering gear.
