Audio, Visual & Navigation System (Display Audio): Removal & Installation Nissan Note E12

Entertainment Systems 14 illustrations ~604 words

REMOVAL

  1. Remove the battery negative terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S20260849492014120500000) ".
  3. Remove the audio unit screws.
  4. Partially remove the audio unit to gain access to the harness connectors.
  5. Disconnect the harness connectors from the audio unit and remove.
  6. Remove the audio unit bracket screws from each side of the audio unit (if necessary).

INSTALLATION

Installation is in the reverse order of removal.

Scheme 56

Scheme 56: REMOVAL
Scheme 56: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S20019847622014120500000) ".
  2. Disconnect the harness connector from front door speaker.
  3. Remove the front door speaker screws (A).
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 57

Scheme 57: REMOVAL
Scheme 57: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00960128362014120500000) ".
  2. Disconnect the harness connector from the rear door speaker.
  3. Remove the rear door speaker screws (A).
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 58

Scheme 58: REMOVAL
Scheme 58: REMOVAL
  1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S31298837932014120500000) ".
  2. Release the pawls (A) from the back of the center console assembly (2) using a suitable tool and remove the USB interface (1).

Installation is in the reverse order of removal.

Scheme 59

Scheme 59: REMOVAL
Scheme 59: REMOVAL
  1. Remove the back door outer finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675580-S36269467122014120500000) ".
  2. Disconnect the harness connector from rear view camera.
  3. Remove the nuts (A) from the rear view camera and remove.

Installation is in the reverse order of removal.

Scheme 60

Scheme 60: REMOVAL
Scheme 60: REMOVAL

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. Remove the luggage side lower finisher (RH). Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S17810494292014120500000) ".
  2. Disconnect the harness connectors from the Bluetooth® control unit.
  3. Remove the Bluetooth® antenna screws (A) and the Bluetooth® antenna (1).
  4. Remove the Bluetooth® control unit bracket screws (A) and the Bluetooth® control unit (1).
  5. Remove the Bluetooth® control unit screws (A) and separate the Bluetooth® control unit (1) from the bracket (2).

Installation is in the reverse order of removal.

  1. Remove the luggage side lower finisher (RH). Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S17810494292014120500000) ".
  2. Disconnect the Bluetooth® antenna harness connector from the Bluetooth® control unit.
  3. Remove the Bluetooth® antenna screws (A) and the Bluetooth® antenna (1).

Installation is in the reverse order of removal.

Scheme 63

Scheme 63: REMOVAL
Scheme 63: REMOVAL

Scheme 64

Scheme 64
Scheme 64
  1. Remove the steering wheel. Refer to " «REMOVAL AND INSTALLATION»(ref-675600-S35361429072014120500000) ".
  2. Remove the steering wheel rear finisher (1) by releasing pawls (A).
  3. Remove the steering wheel audio control switch screws (A) from the back of the steering wheel.
  4. Remove the steering wheel audio control switches from the steering wheel.

Installation is in the reverse order of removal.

Scheme 65

Scheme 65: REMOVAL
Scheme 65: REMOVAL

Scheme 66

Scheme 66
Scheme 66
  1. Remove the microphone finisher from the headlining by releasing pawls (A) using a suitable tool.
  2. Disconnect the harness connector from microphone and remove.
  3. Separate the microphone from the finisher by releasing pawls (A) using a suitable tool.

Installation is in the reverse order of removal.

Note. Make sure to align the rib on the finisher with the slot in the microphone.

Make sure to install the microphone with the arrows pointing toward the RH side of the vehicle.

Scheme 67

Scheme 67: Exploded View
Scheme 67: Exploded View

Scheme 68

Scheme 68: REMOVAL
Scheme 68: REMOVAL
  1. Lower the rear portion of the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00678727602014120500000) ".
  2. Disconnect the harness connectors from the antenna (satellite radio model shown below).
  3. Remove the antenna nut (A) and remove the antenna.

Installation is in the reverse order of removal.

CAUTIONIf the antenna nut is tightened less than the specified torque this will lower the sensitivity of the antenna. If the antenna nut is tightened more than the specified torque this will deform the roof panel.

Scheme 69

Scheme 69: Feeder Layout
Scheme 69: Feeder Layout

Removal and Installation

The satellite radio antenna is part of the rod antenna. Refer to " REMOVAL AND INSTALLATION ".
