Audio, Visual & Navigation System (Base Audio): Removal & Installation Nissan Note E12

Entertainment Systems 12 illustrations ~497 words

REMOVAL

  1. Remove the negative battery cable. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-675607-S20260849492014120500000) ".
  3. Remove the audio unit screws.
  4. Partially remove the audio unit to gain access to the harness connectors.
  5. Disconnect the harness connectors from the audio unit and remove.
  6. Remove the audio unit bracket screws from each side of the audio unit (if necessary).

INSTALLATION

Installation is in the reverse order of removal.

Scheme 8

Scheme 8: REMOVAL
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S20019847622014120500000) ".
  2. Disconnect the harness connector from front door speaker.
  3. Remove the front door speaker screws (A).
  4. Remove the front door speaker (1).

Installation is in the reverse order of removal.

Scheme 9

Scheme 9: REMOVAL
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00960128362014120500000) ".
  2. Disconnect the harness connector from the rear door speaker.
  3. Remove the rear door speaker screws (A).
  4. Remove the rear door speaker (1).

Installation is in the reverse order of removal.

Scheme 10

Scheme 10: REMOVAL

Scheme 11

Scheme 11

Scheme 12

Scheme 12
  1. Remove the luggage side lower finisher (RH). Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S17810494292014120500000) ".
  2. Disconnect the harness connectors from the Bluetooth® control unit.
  3. Remove the Bluetooth® antenna screws (A) and the Bluetooth® antenna (1).
  4. Remove the Bluetooth® control unit bracket screws (A) and the Bluetooth® control unit (1).
  5. Remove the Bluetooth® control unit screws (A) and separate the Bluetooth® control unit (1) from the bracket (2).

Installation is in the reverse order of removal.

  1. Remove the luggage side lower finisher (RH). Refer to " «LUGGAGE SIDE LOWER FINISHER: REMOVAL AND INSTALLATION»(ref-675611-S17810494292014120500000) ".
  2. Disconnect the Bluetooth® antenna harness connector from the Bluetooth® control unit.
  3. Remove the Bluetooth® antenna screws (A) and the Bluetooth® antenna (1).

Installation is in the reverse order of removal.

Scheme 13

Scheme 13: REMOVAL

Scheme 14

Scheme 14
  1. Remove the steering wheel. Refer to " «REMOVAL AND INSTALLATION»(ref-675600-S35361429072014120500000) ".
  2. Remove the steering wheel rear finisher (1) by releasing pawls (A).
  3. Remove the steering wheel audio control switch screws (A) from the back of the steering wheel.
  4. Remove the steering wheel audio control switches from the steering wheel.

Installation is in the reverse order of removal.

Scheme 15

Scheme 15: REMOVAL

Scheme 16

Scheme 16
  1. Remove the microphone finisher from the headlining by releasing pawls (A) using a suitable tool.
  2. Disconnect the harness connector from microphone and remove.
  3. Separate the microphone from the finisher by releasing pawls (A) using a suitable tool.

Installation is in the reverse order of removal.

Note. Make sure to align the rib on the finisher with the slot in the microphone. Make sure to install the microphone with the arrows pointing toward the RH side of the vehicle.

Scheme 17

Scheme 17: Exploded View

Scheme 18

Scheme 18: REMOVAL
  1. Lower the rear portion of the headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-675611-S00678727602014120500000) ".
  2. Disconnect the harness connectors from the antenna (satellite radio model shown below).
  3. Remove the antenna nut (A) and remove the antenna.

Installation is in the reverse order of removal.

CAUTIONIf the antenna nut is tightened less than the specified torque this will lower the sensitivity of the antenna. If the antenna nut is tightened more than the specified torque this will deform the roof panel.

Scheme 19

Scheme 19: Feeder Layout
