DETAILED FLOW

1. GET INFORMATION FOR SYMPTOM Get the detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred). GO TO 2
2. CHECK DTC Check DTC. Perform the following procedure if DTC is displayed. Record DTC and freeze frame data. Erase DTC. Study the relationship between the cause detected by DTC and the symptom described by the customer. Check related service bulletins for information. Is any symptom described and any DTC detected? Symptom is described, DTC is displayed >> GO TO 3 Symptom is described, DTC is not displayed >> GO TO 4 Symptom is not described, DTC is displayed >> GO TO 5
3. CONFIRM THE SYMPTOM Confirm the symptom described by the customer. Connect CONSULT-III to the vehicle in "DATA MONITOR" mode and check real time diagnosis results. Verify relation between the symptom and the condition when the symptom is detected. GO TO 5
4. CONFIRM THE SYMPTOM Confirm the symptom described by the customer. Connect CONSULT-III to the vehicle in "DATA MONITOR" mode and check real time diagnosis results. Verify relation between the symptom and the condition when the symptom is detected. GO TO 6
5. PERFORM DTC CONFIRMATION PROCEDURE Perform DTC Confirmation Procedure for the displayed DTC, and then check that DTC is detected again. At this time, always connect CONSULT-III to the vehicle, and check diagnostic results in real time. If two or more DTCs are detected, refer to " «DTC INSPECTION PRIORITY CHART»(ref-388072-S27711966702011022800000) " and determine trouble diagnosis order. NOTE: Freeze frame data is useful if the DTC is not detected. Perform Component Function Check if DTC Confirmation Procedure is not included in Service Article. This simplified check procedure is an effective alternative though DTC cannot be detected during this check. If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC Confirmation Procedure. Is DTC detected? YES >> GO TO 8 NO >> Refer to " «DTC INDEX»(ref-388072-S17908498842011022800000) ".
6. PERFORM BASIC INSPECTION Perform " «WORK FLOW»(ref-388072-S06506294182011022800000) ". Inspection End >> GO TO 7
7. DETECT MALFUNCTIONING SYSTEM BY SYMPTOM TABLE Detect malfunctioning system according to " «SYSTEM DESCRIPTION»(ref-388072-S16494754922011022800000) " based on the confirmed symptom in step 4 , and determine the trouble diagnosis order based on possible causes and symptom. GO TO 8
8. DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE Inspect according to Diagnostic Procedure of the system. NOTE: The Diagnostic Procedure described based on open circuit inspection. A short circuit inspection is also required for the circuit check in the Diagnostic Procedure. Is malfunctioning part detected? YES >> GO TO 9 NO >> Check voltage of related BCM terminals using CONSULT-III.
9. REPAIR OR REPLACE THE MALFUNCTIONING PART Repair or replace the malfunctioning part. Reconnect parts or connectors disconnected during Diagnostic Procedure again after repair and replacement. Check DTC. If DTC is displayed, erase it. GO TO 10
10. FINAL CHECK When DTC was detected in step 2 , perform DTC Confirmation Procedure or Component Function Check again, and then check that the malfunction have been repaired securely. When symptom was described from the customer, refer to confirmed symptom in step 3 or 4 , and check that the symptom is not detected. Does the symptom reappear? YES (DTC is detected) >> GO TO 8 YES (Symptom remains) >> GO TO 6 NO >> Inspection End.

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Requirement

1. SAVING VEHICLE SPECIFICATION CONSULT-III Configuration Perform "READ CONFIGURATION" to save or print current vehicle specification. Refer to " «CONFIGURATION (BCM) : DESCRIPTION»(ref-388072-S15601569222011022800000) ". NOTE: If "READ CONFIGURATION" cannot be used, use the "WRITE CONFIGURATION - Manual setting" after replacing BCM. GO TO 2
2. REPLACE BCM Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-388072-S03584481162011022800000) ". GO TO 3
3. WRITING VEHICLE SPECIFICATION CONSULT-III Configuration Perform "WRITE CONFIGURATION - Config file" or "WRITE CONFIGURATION - Manual setting" to write vehicle specification. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". GO TO 4
4. INITIALIZE BCM (NATS) Perform BCM initialization (NATS). Refer to CONSULT-III Operation Manual NATS-IVIS/NVIS. Inspection End.

CONFIGURATION (BCM) : Special Repair Requirement

1. WRITING MODE SELECTION CONSULT-III Configuration Select "CONFIGURATION" of BCM. When writing saved data >> GO TO 2 When writing manually >> GO TO 3
2. PERFORM "WRITE CONFIGURATION - CONFIG FILE" CONSULT-III Configuration Perform "WRITE CONFIGURATION - Config File". Inspection End.
3. PERFORM "WRITE CONFIGURATION - MANUAL SETTING" CONSULT-III Configuration Select "WRITE CONFIGURATION - Manual setting". Identify the correct model and configuration list. Refer to " «CONFIGURATION (BCM) : CONFIGURATION LIST»(ref-388072-S33668045522011022800000) ". Confirm and/or change setting value for each item. Select "Setting change". CAUTION: Make sure to select "Setting change" even if the indicated configuration of brand new BCM is same as the desirable configuration. If not, configuration which is set automatically by selecting vehicle model cannot be memorized. When "COMMAND FINISHED", select "END". GO TO 4
4. OPERATION CHECK Confirm that each function controlled by BCM operates normally. Inspection End.

CONFIGURATION (BCM) : Configuration list

BCM DESCRIPTION CHART

OUTLINE

1. BCM (body control module) controls the various electrical components. It inputs the information required to the control from CAN communication and the signal received from each switch and sensor.
2. BCM has combination switch reading function for reading the operation status of combination switches (light, turn signal, wiper and washer) in addition to a function for controlling the operation of various electrical components. It also has the signal transmission function as the passed point of signal and the power saving control function that reduces the power consumption with the ignition switch OFF.
3. BCM is equipped with the diagnosis function that performs the diagnosis with CONSULT-III and various settings.

CAN communication control

In CAN communication, control units are connected with 2 communication lines (CAN-L, CAN-H) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives the data but selectively reads required information only.

CAN communication signal

Refer to the " CAN COMMUNICATION SIGNAL CHART ".

BCM control function list

BCM CONTROL FUNCTION LIST

Scheme 55

Scheme 56

1. BCM reads the status of the combination switch (light, turn signal, wiper and washer) and recognizes the status of each switch.
2. BCM is a combination of 5 output terminals (OUTPUT 1 - 5) and 5 input terminals (INPUT 1 - 5). It reads a maximum of 20 switch status.

Scheme 57

Combination switch INPUT-OUTPUT system list

COMBINATION SWITCH INPUT-OUTPUT SYSTEM LIST

Note. Headlamp has a dual system switch.

Scheme 58

Scheme 59

1. BCM reads the status of the combination switch at 10ms interval normally. NOTE: BCM reads the status of the combination switch at 60ms interval when BCM is controlled at low power consumption mode.
2. BCM operates as follows and judges the status of the combination switch. INPUT 1 - 5 outputs the voltage waveforms of 5 systems simultaneously. It operates the transistor on OUTPUT side in the following order: OUTPUT 5 --> 4 --> 3 --> 2 --> 1. The voltage waveform of INPUT corresponding to the formed circuit changes according to the operation of the transistor on OUTPUT side if any (1 or more) switches are ON. It reads this change of the voltage as the status signal of the combination switch.

Operation Example

In the following operation example, the combination of the status signals of the combination switch is replaced as follows: INPUT 1 - 5 to "1 - 5" and OUTPUT 1 - 5 to "A - E".

Example 1: When a switch (TURN RH switch) is turned ON

Scheme 60

1. The circuit between INPUT 1 and OUTPUT 5 is formed when the TURN RH switch is turned ON.
2. BCM detects the combination switch status signal "1E" when the signal of OUTPUT 5 is input to INPUT 1.
3. BCM judges that the TURN RH switch is ON when the signal "1E" is detected.
4. Example 2: When some switches (TURN RH switch, FR WIPER LOW switch) are turned ON

Example 2: When some switches (turn RH switch, front wiper LO switch) are turned ON

Scheme 61

1. The circuits between INPUT 1 and OUTPUT 5 and between INPUT 1 and OUTPUT 3 are formed when the TURN RH switch and FR WIPER LOW switch are turned ON.
2. BCM detects the combination switch status signal "1CE" when the signals of OUTPUT 3 and OUTPUT 5 are input to INPUT 1.
3. BCM judges that the TURN RH switch and FR WIPER LOW switch are ON when the signal "1CE" is detected.

BCM has the signal transmission function that outputs/transmits each input/received signal to each unit.

Signal transmission function list

SIGNAL TRANSMISSION FUNCTION LIST

Scheme 62

1. BCM incorporates a power saving control function that reduces the power consumption according to the vehicle status.
2. BCM switches the status (control mode) by itself with the power saving control function. It performs the sleep request to each unit (IPDM E/R and combination meter) that operates with the ignition switch OFF.

Normal mode (wake-up)

1. CAN communication is normally performed with other units
2. Each control with BCM is operating properly

CAN communication sleep mode (CAN sleep)

1. CAN transmission is stopped
2. Control with BCM only is operating

Low power consumption mode (BCM sleep)

1. Low power consumption control is active
2. CAN transmission is stopped

LOW POWER CONSUMPTION CONTROL WITH BCM

BCM reduces the power consumption with the following operation in the low power consumption mode.

1. The reading interval of the each switches changes from 10 ms interval to 60 ms interval.

Sleep mode activation

1. BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communication.
2. BCM transmits the sleep wake up signal (sleep) to each unit when all of the CAN sleep conditions are fulfilled.
3. Each unit stops the transmission of CAN communication with the sleep wake up signal. BCM is in CAN communication sleep mode.
4. BCM is in the low power consumption mode and perform the low power consumption control when all of the BCM sleep conditions are fulfilled with CAN sleep condition.

Sleep condition

SLEEP CONDITION CHART

DATA MONITOR

DATA MONITOR CHART

WORK SUPPORT

WORK SUPPORT CHART

DATA MONITOR CHART

DATA MONITOR CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

WORK SUPPORT CHART

CONFIGURATION

Refer to " CONFIGURATION (BCM) : DESCRIPTION ".

CAN DIAG SUPPORT MNTR

Refer to " CAN DIAGNOSTIC SUPPORT MONITOR ".

DATA MONITOR CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

DATA MONITOR CHART

WORK SUPPORT CHART

DATA MONITOR CHART

DATA MONITOR CHART

DATA MONITOR CHART

WORK SUPPORT CHART

Special Repair Requirement

1. REQUIRED WORK WHEN REPLACING BCM Initialize control unit. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". Work End.

1. REQUIRED WORK WHEN REPLACING BCM Initialize control unit. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". Work End.

1. REQUIRED WORK WHEN REPLACING BCM Initialize control unit. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". Work end.

1. REQUIRED WORK WHEN REPLACING BCM Initialize control unit. Refer to " «CONFIGURATION (BCM) : SPECIAL REPAIR REQUIREMENT»(ref-388072-S30068493832011022800000) ". Work end.

Physical Values

ECU DIAGNOSIS INFORMATION CHART Terminal No. (Wire color) Description Condition Value (Approx.) (+) (-) Signal name Input/Output 1 (W/B) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (R/Y) Ground Battery power supply output Output Ignition switch OFF Battery voltage 3 (L/W) Ground Ignition power supply output Output Ignition switch ON Battery voltage 4 (P/W) Ground Interior room lamp power supply Output After passing the interior room lamp battery saver operation time 0V Any other time after passing the interior room lamp battery saver operation time Battery voltage 5 (G) Ground Front door RH UNLOCK Output Front door RH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 7 (R/W) Ground Step lamp Output Step lamp ON 0V OFF Battery voltage 8 (V) Ground All doors LOCK Output All doors LOCK (actuator is activated) Battery voltage Other than LOCK (actuator is not activated) 0V 9 (L) Ground Front door LH UNLOCK Output Front door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 10 (G) Ground Rear door RH and rear door LH UNLOCK Output Rear door RH and rear door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 11 (Y/R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0V 14 (GR/W) Ground Engine switch (push switch) illumination ground Input Tail lamp OFF 0V ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (Y/L) Ground ACC indicator lamp Output Ignition switch OFF Battery voltage ACC or ON 0V 17 (G/B) Ground Turn signal (RH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch RH 6.5 V 18 (G/Y) Ground Turn signal (LH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch LH 6.5 V 19 (Y) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON 0V 21 (P/B) Ground Optical sensor signal Input Ignition switch ON When outside of the vehicle is bright Close to 5V When outside of the vehicle is dark Close to 0V 24 (R/W) Ground Stop lamp switch 1 Input - Battery voltage 26 (O/L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (brake pedal is released) 0V ON (brake pedal is depressed) Battery voltage 27 (O) Ground Front door lock assembly LH (unlock sensor) Input Front door LH LOCK status 11.8V UNLOCK status 0V 29 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0V 31 (G) Ground Rear window defogger feedback signal Input Rear window defogger switch OFF 0V ON Battery voltage 32 (R/B) Ground Front door RH switch Input Front door RH switch OFF (when front door RH closes) 11.8 V ON (when front door RH opens) 0V 37 (O) Ground Trunk lid opener cancel switch Input Trunk lid opener cancel switch CANCEL 1.1V ON 0V 38 (GR/W) Ground Rear window defogger ON signal Input Rear window defogger switch OFF 5V ON 0V 40 (Y/G) Ground Power window serial link Input/Output Ignition switch ON 10.2V Ignition switch OFF or ACC 0V 41 (W) Ground Engine switch (push switch) illumination Output Engine switch (push switch) illumination ON 5.5V OFF 0V 42 (R) Ground LOCK indicator lamp Output LOCK indicator lamp ON 0V OFF Battery voltage 45 (P) Ground Receiver & sensor ground Input Ignition switch ON 0V 46 (V/W) Ground Receiver & sensor power supply output Output Ignition switch OFF 0V ACC or ON 5.0V 47 (1) (G/O) Ground Tire pressure receiver signal Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 48 (R/G) Ground Selector lever transmission range switch signal Input Selector lever P or N position 12.0V Except P and N positions 0V 49 (L/O) Ground Security indicator signal Output Security indicator ON 0V Blinking 11.3V OFF Battery voltage 50 (LG/B) Ground Combination switch INPUT 5 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Lighting switch 1ST 10.7V Lighting switch high-beam Lighting switch 2ND Turn signal switch RH 51 (L/W) Ground Combination switch INPUT 1 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front wiper switch HI (Wiper intermittent dial 4) 10.7V Any of the conditions below with all switch OFF Wiper intermittent dial 1 WIper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 52 (G/B) Ground Combination switch INPUT 2 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front washer switch ON (Wiper intermittent dial 4) 10.7V Any of the conditions below with all switch OFF Wiper intermittent dial 1 WIper intermittent dial 5 Wiper intermittent dial 6 53 (LG/R) Ground Combination switch INPUT 3 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front wiper switch INT 10.7V Front wiper switch LO Lighting switch AUTO 54 (G/Y) Ground Combination switch INPUT 4 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front fog lamp switch ON 10.7V Lighting switch 2ND Lighting switch flash-to-pass Turn signal switch LH 57 (1) (W) Ground Tire pressure warning check switch Input - 5V 58 (SB) Ground Front door LH switch Input Front door LH switch OFF (front door LH CLOSE) 11.8V ON (front door LH OPEN) 0V 59 (G/R) Ground Rear window defogger relay Output Rear window defogger Active Battery voltage Not activated 0V 60 (B/R) Ground Front console antenna 2 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 61 (W/R) Ground Center console antenna 2 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 62 (V) Ground Front outside handle RH antenna (-) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 63 (P) Ground Front outside handle RH antenna (+) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 64 (V) Ground Front outside handle LH antenna (-) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 65 (P) Ground Front outside handle LH antenna (+) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 68 (G/O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 69 (O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 70 (R/B) Ground Ignition relay-2 control Output Ignition switch OFF or ACC 0V ON Battery voltage 71 (L/O) Ground Remote keyless entry receiver signal Input/Output During waiting When operating either button on Intelligent Key 75 (R/Y) Ground Combination switch OUTPUT 5 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Front fog lamp switch ON (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 1.3V 76 (R/G) Ground Combination switch OUTPUT 3 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch high-beam (Wiper intermittent dial 4) 1.3V Lighting switch 2ND (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 1.3V 78 (P) Ground CAN-L Input/Output - - 79 (L) Ground CAN-H Input/Output - - 80 (R/L) Ground Key slot illumination Output Key slot illumination OFF 0V Blinking 6.5V ON Battery voltage 81 (LG) Ground ON indicator lamp Output Ignition switch OFF or ACC 0V ON Battery voltage 83 (L) Ground ACC relay control Output Ignition switch OFF 0V ACC or ON Battery voltage 84 (Y/R) Ground CVT shift selector Output - Battery voltage 87 (G/B) Ground Selector lever P position switch Input Selector lever P position 0V Any position other than P Battery voltage 88 (R) Ground Front door RH request switch Input Front door RH request switch ON (pressed) 0V OFF (not pressed) 1.0V 89 (R) Ground Front door LH request switch Input Front door LH request switch ON (pressed) 0V OFF (not pressed) 1.0V 90 (Y) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0V ON Battery voltage 91 (L/R) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 95 (R/W) Ground Combination switch OUTPUT 1 Input Combination switch (Wiper intermittent dial 4) All switch OFF 1.4V Turn signal switch LH 1.3V Turn signal switch RH 1.3V Front wiper switch LO 1.3V Front washer switch ON 1.3V 96 (P/B) Ground Combination switch OUTPUT 4 Input Combination switch All switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch AUTO (Wiper intermittent dial 4) 1.3V Lighting switch 1ST (Wiper intermittent dial 4) 1.3V Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 1.3V 97 (R/B) Ground Combination switch OUTPUT 2 Input Combination switch (Wiper intermittent dial 4) All switch OFF 1.4V Lighting switch flash-to-pass 1.3V Lighting switch 2ND 1.3V Front wiper switch INT 1.3V Front wiper switch HI 1.3V 98 (G/O) Ground Hazard switch Input Hazard switch Pressed 0 V Not pressed 1.1V 103 (V) Ground Trunk lid opening. Output Trunk lid Open (trunk lid opener actuator is activated) Battery voltage Close (trunk lid opener actuator is not activated) 0V 110 (V/W) Ground Trunk room lamp Output Trunk room lamp ON 0V OFF Battery voltage 114 (B) Ground Trunk room antenna 1 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 115 (W) Ground Trunk room antenna 1 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 118 (L/O) Ground Rear bumper antenna (-) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 119 (BR/W) Ground Rear bumper antenna (+) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 127 (BR/W) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON 0V 130 (W) Ground Trunk room lamp switch Input Trunk room lamp switch OFF (trunk is closed) 11.8V ON (trunk is open) 0V 132 (R) Ground Starter motor relay control Output Ignition switch ON When selector lever is in P or N position and the brake is depressed Battery voltage When selector lever is in P or N position and the brake is not depressed 0V 140 (BR) Ground Engine switch (push switch) Input Engine switch (push switch) Pressed 0V Not pressed Battery voltage 141 (BR) Ground Trunk request switch Input Trunk request switch ON (pressed) 0V OFF (not pressed) 1.0V 144 (GR) Ground Request switch buzzer Output Request switch buzzer Sounding 0V Not sounding Battery voltage 147 (L/R) Ground Trunk lid opener switch Input Trunk lid opener switch Pressed 0V Not pressed Battery voltage 148 (R/W) Ground Rear door RH switch Input Rear door RH switch OFF (when rear door RH closes) 11.8V ON (when rear door RH opens) 0V 149 (R/B) Ground Rear door LH switch Input Rear door LH switch OFF (when rear door LH closes) 11.8V ON (when rear door LH opens) 0V (1) With low tire pressure monitoring system

Scheme 63
