Power Control System: Removal & Installation Nissan Maxima A35

Body Electrical 4 illustrations ~118 words

Removal and Installation

CAUTIONNever remove the relays from the IPDM E/R. Tampering with the relays may cause additional incidents with the vehicle.

Scheme 117

Scheme 117: REMOVAL
Scheme 117: REMOVAL

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119
  1. Disconnect battery negative terminal.
  2. Remove the IPDM E/R cover (1) while pressing the pawl (A) at the rear end of the IPDM E/R cover (1).
  3. Disconnect the harness connectors from the IPDM E/R.
  4. While depressing the tabs (A) remove the IPDM E/R (1) from the vehicle.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 120

Scheme 120: OVERALL SEQUENCE
Scheme 120: OVERALL SEQUENCE

For removal and installation of the BCM, refer to " REMOVAL AND INSTALLATION ".

REMOVAL

  1. Remove push-button ignition switch from cluster lid A using Tool. Tool number : - (J-46534)
  2. Disconnect electrical harness connector from push-button ignition switch.

Installation is in the reverse order of removal.
