How to Handle Battery
| CAUTION | If it becomes necessary to start the engine with a booster battery and jumper cables, use a 12-volt booster battery. After connecting battery cables, ensure that they are tightly clamped to battery terminals for good contact. Never add distilled water through the hole used to check specific gravity. |
METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging a battery.
Scheme 22
Scheme 23
Scheme 24
- The battery surface (particularly its top) should always be kept clean and dry.
- The terminal connections should be clean and tight.
- At every routine maintenance, check the electrolyte level. This also applies to batteries designated as "low maintenance" and "maintenance-free".
- When the vehicle is not going to be used over a long period of time, disconnect the battery cable from the negative terminal. (If the vehicle has an extended storage switch, turn it off.)
- Check the charge condition of the battery. Periodically check the specific gravity of the electrolyte. Keep a close check on charge condition to prevent over-discharge.
CHECKING ELECTROLYTE LEVEL
| WARNING | Never allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touching a battery, never touch or rub your eyes until you have thoroughly washed your hands. If acid contacts eyes, skin or clothing, immediately flush with water for 15 minutes and seek medical attention. |
Scheme 25
- Remove the cell plug using a suitable tool.
- Add distilled water up to the MAX level.
Sulphation
A battery will be completely discharged if it is left unattended for a long time and the specific gravity will become less than 1.100. This may result in sulphation on the cell plates.
To determine if a battery has been "sulphated", note its voltage and current when charging it. As shown in the figure, less current and higher voltage are observed in the initial stage of charging sulphated batteries.
A sulphated battery may sometimes be brought back into service by means of a long, slow charge, 12 hours or more, followed by a battery capacity test.
Scheme 26
Scheme 27
- Read hydrometer and thermometer indications at eye level.
- Use the chart below to correct your hydrometer reading according to electrolyte temperature. Hydrometer Temperature Correction ELECTROLYTE SPECIFIC GRAVITY REFERENCE Battery electrolyte temperature [°C (°F)] Add to specific gravity reading 71 (160) 0.032 66 (150) 0.028 60 (140) 0.024 54 (130) 0.020 49 (120) 0.016 43 (110) 0.012 38 (100) 0.008 32 (90) 0.004 27 (80) 0 21 (70) -0.004 16 (60) -0.008 10 (50) -0.012 4 (40) -0.016 -1 (30) -0.020 -7 (20) -0.024 -12 (10) -0.028 -18 (0) -0.032 SPECIFIC GRAVITY REFERENCE Corrected specific gravity Approximate charge condition 1.260 - 1.280 Fully charged 1.230 - 1.250 3/4 charged 1.200 - 1.220 1/2 charged 1.170 - 1.190 1/4 charged 1.140 - 1.160 Almost discharged 1.110 - 1.130 Completely discharged
CHARGING THE BATTERY
| CAUTION | Never "quick charge" a fully discharged battery. Keep the battery away from open flame while it is being charged. When connecting the charger, connect the leads first, then turn on the charger. Never turn on the charger first, as this may cause a spark. If battery electrolyte temperature rises above 55°C (131°F), stop charging. Always charge battery at a temperature below 55°C (131°F). |
Charging Rates
| Amps | Time |
|---|---|
| 50 | 1 hour |
| 25 | 2 hours |
| 10 | 5 hours |
| 5 | 10 hours |
CHARGING RATES REFERENCE
Do not charge at more than 50 ampere rate.
Note. The ammeter reading on your battery charger will automatically decrease as the battery charges. This indicates that the voltage of the battery is increasing normally as the state of charge improves. The charging amps indicated above refer to CHARGING RATES REFERENCE . If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be replaced.
ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Repair Requirement
Required Procedure After Battery Disconnection
| System | Item | Reference |
|---|---|---|
| Engine Control System | Idle Air Volume Learning | IDLE AIR VOLUME LEARNING |
| Power Window Control System | Power Window System Initialization | INSPECTION AND ADJUSTMENT (LH & RH Front Window Anti-pinch) INSPECTION AND ADJUSTMENT (Front & Rear Window Anti-pinch) |
| Roof | Sunroof Memory Reset/Initialization | INSPECTION AND ADJUSTMENT (Single Panel Sunroof) INSPECTION AND ADJUSTMENT (Dual Panel Sunroof) |
| Automatic Drive Positioner | Automatic Drive Positioner System Initialization | Refer to Owner's information. |
| Heater & Air Conditioning Control System | Temperature Setting Trimmer | TEMPERATURE SETTING TRIMMER (Color Display) TEMPERATURE SETTING TRIMMER (Monochrome Display) |
| Foot Position Setting Trimmer | FOOT POSITION SETTING TRIMMER (Color Display) FOOT POSITION SETTING TRIMMER (Monochrome Display) | |
| Inlet Port Memory Function (FRE) | INLET PORT MEMORY FUNCTION (FRE) (Color Display) INLET PORT MEMORY FUNCTION (FRE) (Monochrome Display) | |
| Inlet Port Memory Function (REC) | INLET PORT MEMORY FUNCTION (REC) (Color Display) INLET PORT MEMORY FUNCTION (REC) (Monochrome Display) | |
| Audio, Visual & Navigation System | Audio (Radio Preset) | Refer to Owner's information. |
| Navigation System | Refer to Owner's information. |
BATTERY NEGATIVE TERMINAL ITEM REFERENCE
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
Scheme 46
- If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
- Use fuse of specified rating. Never use fuse of more than specified rating.
- Do not partially install fuse; always insert it into fuse holder properly.
- Remove fuse for "ELECTRICAL PARTS (BAT)" if vehicle is not used for a long period of time.
Fusible Link
A melted fusible link can be detected either by visual inspection or by feeling with finger tip. If its condition is questionable, use circuit tester or test lamp.
Scheme 47
| CAUTION | If fusible link should melt, it is possible that critical circuit (power supply or large current carrying circuit) is shorted. In such a case, carefully check and eliminate cause of malfunction. Never wrap outside of fusible link with vinyl tape. Important: Never let fusible link touch any other wiring harness, vinyl or rubber parts. |
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
NORMAL OPEN, NORMAL CLOSED AND MIXED TYPE RELAYS
Relays can mainly be divided into three types: normal open, normal closed and mixed type relays.
Scheme 57
TYPE OF STANDARDIZED RELAYS
| 1M | 1 Make |
|---|---|
| 1T | 1 Transfer |
| 2M | 2 Make |
| 1M.1B | 1 Make 1 Break |
TYPE OF STANDARDIZED RELAYS
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or un-belted.
Information necessary to service the system safely is included in the " SRS AIRBAG and SEAT BELTS " articles.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Special Service Tool
SPECIAL SERVICE TOOL REFERENCE Tool number (Kent-Moore No.) Tool name Description - (-) Model GR-8 Multitasking battery diagnostic station Tests batteries, starting and charging systems. For operating instructions, refer to diagnostic station instruction information
Scheme 63
Commercial Service Tool
COMMERCIAL SERVICE TOOL REFERENCE Tool name Description Power tool Loosening bolts and nuts
Scheme 64
Battery
| Type (1) | GR35 |
|---|---|
| Capacity (20HR) minimum V-AH | 12-63 |
| Cold cranking current A (For reference value) | 550 |
| (1) Always check with the Parts Department for the latest parts information | |
| (1) | Always check with the Parts Department for the latest parts information |
BATTERY SERVICE DATA AND SPECIFICATIONS
