Audio Visual, Navigation & Telephone System: Wiring Nissan Maxima A34

Satellite Radio Tuner (Pre-wiring)

The satellite radio tuner pre-wiring allows connection of a satellite radio tuner.

Power is supplied at all times

1. Through 20A fuse [No. 31, located in the fuse and fusible link box]
2. To satellite radio tuner pre-wiring terminal 32.

With the ignition switch in the ACC or ON position, power is supplied

1. Through 10A fuse [No. 6, located in the fuse block (J/B)]
2. To satellite radio tuner pre-wiring terminal 36.

Ground is supplied through the case of the satellite radio tuner.

Then audio signals are supplied

1. Through satellite radio tuner pre-wiring terminals 21, 22, 23 and 24
2. To audio unit terminals 41, 42, 43 and 44.

The satellite radio tuner pre-wiring allows connection of a satellite radio tuner.

Power is supplied at all times

1. Through 20A fuse [No. 31, located in the fuse and fusible link box]
2. To satellite radio tuner pre-wiring terminal 32.

With the ignition switch in the ACC or ON position, power is supplied

1. Through 10A fuse [No. 6, located in the fuse block (J/B)]
2. To satellite radio tuner pre-wiring terminal 36.

Ground is supplied through the case of the satellite radio tuner.

Then audio signals are supplied

1. Through satellite radio tuner pre-wiring terminals 21, 22, 23 and 24
2. To audio unit terminals 41, 42, 43 and 44.

Wiring Diagram - AUDIO

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Wiring Diagram - W/ANT

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continuity, wrap tin foil around the top of probe. Then, press the foil against the wire with your finger.
2. If an element is broken, no continuity will exist.
3. To locate a break, move probe along element. Tester indication will change abruptly when probe passes the broken point.

Wiring Diagram - INF/D

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Wiring Diagram - COMM

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Wiring Diagram - NAVI

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

For references to PG-POWER, see POWER SUPPLY, GROUND & CIRCUIT ELEMENTS .

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219
