Audio Visual, Navigation & Telephone System: Removal & Installation Nissan Maxima A34

Entertainment Systems 13 illustrations ~437 words

Removal and Installation of Audio Unit

Refer to CENTER STACK ASSEMBLY .

Scheme 163

Scheme 163: REMOVAL
  1. Remove cluster lid D. Refer to «CLUSTER LID D»(ref-233659-S16700258672006052600000) .
  2. Remove screws.
  3. Carefully release tabs and remove AV switch.

INSTALLATION

Install in the reverse order of removal.

Scheme 164

Scheme 164: REMOVAL
  1. Remove door finisher. Refer to «FRONT DOOR»(ref-233645-S10413610252006052600000) .
  2. Remove screws and remove speaker.
  3. Disconnect connector.

Install in the reverse order of removal.

Scheme 165

Scheme 165: REMOVAL
  1. Remove door finisher. Refer to «REAR DOOR»(ref-233645-S02919106042006052600000) .
  2. Remove screws and remove speaker.
  3. Disconnect connector.

Install in the reverse order of removal.

Scheme 166

Scheme 166: REMOVAL
  1. Remove door finisher. Refer to «FRONT DOOR»(ref-233645-S10413610252006052600000) .
  2. Remove screws and remove tweeter.
  3. Disconnect connector.

Install in the reverse order of removal.

Scheme 167

Scheme 167: REMOVAL
  1. Remove rear parcel shelf finisher. Refer to «REAR PARCEL SHELF FINISHER»(ref-233645-S01487947742006052600000) .
  2. Remove screws.
  3. Lift subwoofer out and disconnect connector.

Install in the reverse order of removal.

Scheme 168

Scheme 168: REMOVAL
  1. Lower upper trunk finisher. Refer to «TRUNK ROOM TRIM & TRUNK LID FINISHER»(ref-233645-S18452263062006052600000) .
  2. Disconnect connector.
  3. Remove screws.

Install in the reverse order of removal.

Scheme 169

Scheme 169: REMOVAL
  1. Remove rear parcel shelf finisher. Refer to «REAR PARCEL SHELF FINISHER»(ref-233645-S01487947742006052600000) .
  2. Lower upper trunk finisher. Refer to «TRUNK ROOM TRIM & TRUNK LID FINISHER»(ref-233645-S18452263062006052600000) .
  3. Disconnect connector.
  4. Remove screws. CAUTION: Carefully support the amp. when removing screws.

Install in the reverse order of removal.

Scheme 170

Scheme 170: REMOVAL
  1. Lower upper trunk finisher. Refer to «TRUNK ROOM TRIM & TRUNK LID FINISHER»(ref-233645-S18452263062006052600000) .
  2. Remove screws and disconnect connectors to remove BOSE speaker amp. from underside of rear parcel shelf.

Install in the reverse order of removal.

Scheme 171

Scheme 171: Removal and Installation of Steering Wheel Audio Control Switches

Scheme 172

Scheme 172

Scheme 173

Scheme 173
  1. Remove steering wheel. Refer to «REMOVAL AND INSTALLATION»(ref-233655-S27118854372006052600000) .
  2. Remove horn switch screws and remove horn switch.
  3. Remove steering wheel rear cover screws and remove steering wheel rear cover.
  4. Remove steering wheel switch assembly screws and steering wheel switches.
  5. Installation is in the reverse order of removal.

Removal and Installation of Display Unit

Refer to CENTER STACK ASSEMBLY .

Removal and Installation of AV Switch

Refer to REMOVAL AND INSTALLATION FOR AV SWITCH .

REMOVAL

CAUTIONTo avoid damage, eject map DVD-ROM before removing the NAVI control unit.

Scheme 174

Scheme 174
  1. Remove center stack. Refer to «Center Stack Assembly»(ref-233659-S23449832072006052600000) .
  2. Remove screws and remove remaining bracket.

Install in the reverse order of removal.

Scheme 175

Scheme 175: REMOVAL
  1. Remove security indicator lamp.
  2. Remove screw.
  3. Disconnect connector and remove GPS antenna.

Install in the reverse order of removal.

Removal and Installation of Steering Wheel Switch

Refer to REMOVAL AND INSTALLATION OF STEERING WHEEL AUDIO CONTROL SWITCHES .

Refer to REMOVAL AND INSTALLATION FOR AV SWITCH .

Refer to CENTER STACK ASSEMBLY .

Removal and Installation of Display Control Unit

Refer to CENTER STACK ASSEMBLY .
