Refilling Engine Coolant
Changing the engine coolant is part of the required maintenance of the engine. Refer to CHANGING ENGINE COOLANT .
Scheme 36
| WARNING | Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure coolant escaping from the radiator. |
Scheme 37
- Drain the coolant from the radiator. Refer to «DRAINING ENGINE COOLANT»(ref-233644-S13037486022006052600000) . CAUTION: Perform when engine is cold.
- Remove fresh air duct. Refer to «REMOVAL»(ref-233643-S31143878602006052600000) .
- Remove IPDM E/R bolts and position aside. Refer to «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-233661-S42132645482006052600000) .
- Disconnect radiator upper and lower hoses.
- Remove the A/T fluid cooler hoses, if equipped. Plug hoses to avoid leakage of A/T fluid.
- Disconnect the reservoir tank hose.
- Remove the radiator upper clips by pulling the tabs outside to release the lock, as shown. CAUTION: To prevent damage, do not pull lock tabs excessively.
- Disconnect fan electrical connectors.
- Remove the radiator and radiator fan assembly. CAUTION: Do not damage or scratch air conditioner condenser and radiator core when removing.
