A/C SYSTEM SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| Application | Specification |
|---|
| Compressor Type | Calsonic V6 6-Cyl. |
| Compressor Belt Deflection (1) |
| New Belt | 5/32-11/64" (3.8-4.1 mm) |
| Used Belt | 11/64-3/16" (4.2-4.6 mm) |
| System Oil Capacity | (2) 8.5 ozs. |
| Refrigerant Capacity (R-134a) | 21.2-24.7 ozs. |
| System Operating Pressures (3) |
| High Side | 147-177 psi (10.3-12.4 kg/cm 2 ) |
| Low Side | 20-26 psi (1.4-1.8 kg/cm 2 ) |
| (1) Measure deflection with 22 lbs. (10 kg) pressure applied midway on belt longest run. (2) Use Type "S" Oil (Part No. KLH00-PAGS0). (3) Specification is with ambient temperature at 77°F (25°C), relative humidity at 50-70 percent, and engine speed at 1500 RPM. |
| (1) | Measure deflection with 22 lbs. (10 kg) pressure applied midway on belt longest run. |
| (2) | Use Type "S" Oil (Part No. KLH00-PAGS0). |
| (3) | Specification is with ambient temperature at 77°F (25°C), relative humidity at 50-70 percent, and engine speed at 1500 RPM. |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Bracket Bolt | 33-44 (45-60) |
| Compressor Mounting Bolt | 33-44 (45-60) |
| Refrigerant Line Fittings |
| At Evaporator (Union Nut) |
| Suction Hose | 22 (30) |
| Liquid Line | 10 (14) |
| At Expansion Valve |
| Large Union Nut | 16 (22) |
| Small Union Nut | 12 (16) |
| At Expansion Valve By-Pass Tube (Union Nut) | 10 (14) |
| Thermal Protector (At Compressor) | 12 (16) |
| INCH Lbs. (N.m) |
| Refrigerant Line Fittings |
| At Compressor (Bolt) | 70-96 (8-11) |
| At Receiver-Drier (Bolt) | 26-35 (3-4) |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
