Scheme 24
POWER WINDOW LOCK
Ground circuit inside power window main switch shuts off when power window lock switch is ON. This inhibits each power window switch operation except the power window main switch.
ANTI-PINCH SYSTEM (FRONT DRIVER SIDE)
- Pinch foreign material in the door glass during AUTO-UP operation, and it is the anti-pinch function that lowers the door glass 150 mm (5.9 in) when detected.
- Encoder continues detecting the movement of front power window motor (driver side) and transmits to power window main switch as the encoder pulse signal while front power window motor (driver side) is operating.
- Resistance is applied to the front power window motor (driver side) rotation that changes the frequency of encoder pulse signal if foreign material is trapped in the door glass.
- Power window main switch controls to lower the window glass for 150 mm (5.9 in) after it detects encoder pulse signal frequency change.
Operation Condition
When front door glass (driver side) AUTO-UP operation is performed (anti-pinch function does not operate just before the door glass closes and is fully closed).
Note. Depending on environment and driving conditions, if a similar impact or load is applied to the door glass, it may lower.
FAIL-SAFE CONTROL
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
It changes to condition before initialization and the following functions do not operate when switched to failsafe control.
- Auto-up operation
- Anti-pinch function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window main switch or front power window motor (driver side).
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on CONSULT.
| CONSULT screen item | Indication/Unit | Description | |
|---|---|---|---|
| Vehicle Speed | Km/h | Vehicle speed of the moment a particular DTC is detected | |
| Odo/Trip Meter | Km | Total mileage (Odometer value) of the moment a particular DTC is detected | |
| Vehicle Condition | SLEEP>LOCK | Power position status of the moment a particular DTC is detected | While turning BCM status from low power consumption mode to normal mode (Power position is "LOCK" (1) .) |
| SLEEP>OFF | While turning BCM status from low power consumption mode to normal mode (Power position is "OFF".) | ||
| LOCK>ACC | While turning power position from "LOCK" (1) to "ACC" | ||
| ACC>ON | While turning power position from "ACC" to "IGN" | ||
| RUN>ACC | While turning power position from "RUN" to "ACC" (Vehicle is stopping and selector lever is except P position.) | ||
| CRANK>RUN | While turning power position from "CRANKING" to "RUN" (From cranking up the engine to run it) | ||
| RUN>URGENT | While turning power position from "RUN" to "ACC" (Emergency stop operation) | ||
| ACC>OFF | While turning power position from "ACC" to "OFF" | ||
| OFF>LOCK | While turning power position from "OFF" to "LOCK" (1) | ||
| OFF>ACC | While turning power position from "OFF" to "ACC" | ||
| ON>CRANK | While turning power position from "IGN" to "CRANKING" | ||
| OFF>SLEEP | While turning BCM status from normal mode (Power position is "OFF".) to low power consumption mode | ||
| LOCK>SLEEP | While turning BCM status from normal mode (Power position is "LOCK" (1) .) to low power consumption mode | ||
| LOCK | Power position is "LOCK" (1) | ||
| OFF | Power position is "OFF" (Ignition switch OFF) | ||
| ACC | Power position is "ACC" (Ignition switch ACC) | ||
| ON | Power position is "IGN" (Ignition switch ON with engine stopped) | ||
| ENGINE RUN | Power position is "RUN" (Ignition switch ON with engine running) | ||
| CRANKING | Power position is "CRANKING" (At engine cranking) | ||
| IGN Counter | 0 - 39 | The number of times that ignition switch is turned ON after DTC is detected The number is 0 when a malfunction is detected now. The number increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The number is fixed to 39 until the self-diagnosis results are erased if it is over 39. | |
| NOTE: (1) Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. | |||
| NOTE |
|---|
| (1) Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. |
| (1) | Power position shifts to "LOCK" from "OFF", when ignition switch is in the OFF position, selector lever is in the P position (A/T models and CVT models), and any of the following conditions are met. |
- Closing door
- Opening door
- Door is locked using door request switch
- Door is locked using Intelligent Key
The power position shifts to "ACC" when the push-button ignition switch (push switch) is pushed at "LOCK".
DATA MONITOR
| Monitor Item | Description |
|---|---|
| DOOR SW-DR | Indicates [ON/OFF] condition of driver side door switch. |
| DOOR SW-AS | Indicates [ON/OFF] condition of passenger side door switch. |
| Monitor Item | Description |
|---|---|
| DOOR SW-DR | Indicates [ON/OFF] condition of driver side door switch. |
| DOOR SW-AS | Indicates [ON/OFF] condition of passenger side door switch. |
List of ECU Reference
| ECU | Reference | |
|---|---|---|
| BCM | With Intelligent Key | " REFERENCE VALUE " |
| " FAIL-SAFE " | ||
| " DTC INSPECTION PRIORITY CHART " | ||
| " DTC INDEX " | ||
| Without Intelligent Key | " REFERENCE VALUE " | |
| " FAIL-SAFE " | ||
| " DTC INSPECTION PRIORITY CHART " | ||
| " DTC INDEX " | ||
Scheme 25
PHYSICAL VALUES
Terminal No. (Wire color) Description Condition Voltage (V) + - Signal name Input/Output 1 (B) Ground Ground - - 0 - 1 2 (SB) Ground Front power window motor (passenger side) DOWN signal Output When front RH switch in power window main switch is in DOWN operation. 9 - 16 4 (P) Ground Encoder pulse signal 2 Input When front power window motor (driver side) operates. 5 (W) Ground Encoder pulse signal 1 Input When front power window motor (driver side) operates. 6 (BR) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is in DOWN operation. 9 - 16 7 (LG) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is in UP operation. 9 - 16 8 (BG) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is in DOWN operation. 9 - 16 9 (G) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is in UP operation. 9 - 16 10 (L) Ground Ignition switch power supply Input Ignition switch ON 9 - 16 Other than above 0 - 1 12 (LG) Ground Encoder ground - - 0 - 1 14 (G) Ground Encoder power supply Output Ignition switch ON 9 - 16 16 (W) Ground Front power window motor (passenger side) UP signal Output When front RH switch in power window main switch is in UP operation. 9 - 16 17 (R) Ground Front power window motor (driver side) UP signal Output When front LH switch in power window main switch is in UP operation. 9 - 16 18 (P) Ground Battery power supply Input Ignition switch OFF 9 - 16 19 (GR) Ground Front power window motor (driver side) DOWN signal Output When front LH switch in power window main switch is in DOWN operation. 9 - 16
Scheme 26
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
It changes to condition before initialization and the following functions do not operate when switched to failsafe control.
- Auto-up operation
- Anti-pinch function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window main switch or front power window motor (driver side).
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred) as much as possible when the customer brings the vehicle in. GO TO 2.
- REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. GO TO 3.
- IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. GO TO 4.
- IDENTIFY THE MALFUNCTIONING PARTS WITH "DTC/CIRCUIT DIAGNOSIS" Perform the diagnosis with "DTC/CIRCUIT DIAGNOSIS" of the applicable system. GO TO 5.
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. GO TO 6.
- FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Are the malfunctions corrected? YES: INSPECTION END NO: GO TO 3 .
Work Procedure
- SYSTEM INITIALIZATION Perform system initialization. Refer to " «WORK PROCEDURE»(ref-516443-S21525874012012120600000) ". GO TO 2.
- CHECK ANTI-PINCH FUNCTION Check anti-pinch function. Refer to " «WORK PROCEDURE»(ref-516443-S10422692582012120600000) ". END
- SYSTEM INITIALIZATION Perform system initialization. Refer to " «WORK PROCEDURE»(ref-516443-S21525874012012120600000) ". GO TO 2.
- CHECK ANTI-PINCH FUNCTION Check anti-pinch function. Refer to " «WORK PROCEDURE»(ref-516443-S10422692582012120600000) ". END
- STEP 1 Turn ignition switch ON. Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open) Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at fully closed position, keep pulling the switch for 2 seconds or more. Check that AUTO-UP function operates normally. GO TO 2.
- STEP 2 Check anti-pinch function. Refer to " «WORK PROCEDURE»(ref-516443-S10422692582012120600000) ". END
- CHECK ANTI-PINCH FUNCTION Fully open the door window. Place a piece of wood near fully closed position. Close door glass completely with AUTO-UP. Check the following conditions. Check that glass lowers for approximately 150 mm (5.9 in) without pinching piece of wood and stops. Check that glass does not rise not when operating the power window main switch while lowering. CAUTION: Perform initial setting when AUTO-UP operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when system initialization is performed. Do not check with hands and other body parts because they may be pinched. Do not get pinched. END
Component Function Check
- CHECK FUNCTION
Check front power window motor (passenger side) operation with front power window switch (passenger side).
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " DIAGNOSIS PROCEDURE ".
- CHECK FUNCTION
Check rear power window motor operation with rear power window switch.
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " DIAGNOSIS PROCEDURE ".
DRIVER SIDE: Component Function Check
- CHECK FUNCTION
Check front power window motor (driver side) operation with power window main switch.
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " DRIVER SIDE: DIAGNOSIS PROCEDURE ".
PASSENGER SIDE: Component Function Check
- CHECK FUNCTION
Check front power window motor (passenger side) operation with power window main switch or front power window switch (passenger side).
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " PASSENGER SIDE: DIAGNOSIS PROCEDURE ".
REAR LH: Component Function Check
- CHECK FUNCTION
Check rear power window motor LH operation with power window main switch or rear power window switch LH.
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " REAR LH: DIAGNOSIS PROCEDURE ".
REAR RH: Component Function Check
- CHECK FUNCTION
Check rear power window motor RH operation with power window main switch or rear power window switch RH.
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " REAR RH: DIAGNOSIS PROCEDURE ".
- CHECK FUNCTION
Check that front driver side door glass perform AUTO UP/DOWN operation normally when power window main switch is operated.
Is the inspection result normal?
YES: INSPECTION END
NO: Refer to " DIAGNOSIS PROCEDURE ".
Scheme 27
- CHECK ENCODER PULSE SIGNAL Turn ignition switch ON. Check signal between power window main switch harness connector and ground with oscilloscope. (+) (-) Signal (Reference value) Power window main switch Connector Terminal D35 4 Ground Refer to the following signal 5 Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-516443-S39838716082012120600000) ". NO: GO TO 2.
- CHECK ENCODER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector and front power window motor (driver side) connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D35 4 D37 5 Existed 5 4 Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D35 4 Not existed 5 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCODER POWER SUPPLY Connect power window main switch connector. Turn ignition switch ON. Check voltage between front power window motor (driver side) harness connector and ground. (+) (-) Voltage (V) Front power window motor (driver side) Connector Terminal D37 1 Ground 9 - 16 Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK ENCODER POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D35 14 D37 1 Existed Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D35 14 Not existed Is the inspection result normal? YES: Replace power window main switch. Refer to " «REMOVAL AND INSTALLATION»(ref-516443-S39838716082012120600000) ". NO: Repair or replace harness.
- CHECK ENCODER GROUND CIRCUIT 1 Turn ignition switch OFF. Disconnect power window main switch connector. Check continuity between power window main switch harness connector and front power window motor (driver side) harness connector. Power window main switch Front power window motor (driver side) Continuity Connector Terminal Connector Terminal D35 12 D37 6 Existed Check continuity between power window main switch harness connector and ground. Power window main switch Ground Continuity Connector Terminal D35 12 Not existed Is the inspection result normal? YES: GO TO 6. NO: Repair or replace harness.
- CHECK ENCODER GROUND CIRCUIT 2
- Connect power window main switch connector.
- Check continuity between power window main switch harness connector and ground.
| Power window main switch | Ground | Continuity | |
|---|---|---|---|
| Connector | Terminal | ||
| D35 | 12 | Existed | |
Is the inspection result normal?
YES: Replace front power window motor (driver side).
NO: Replace power window main switch. Refer to " REMOVAL AND INSTALLATION ".
