CAN COMMUNICATION SYSTEM: System Description
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.
DIAG ON CAN: Description
"Diag on CAN" is a diagnosis method which uses the CAN communication line for the communication between the control unit and the diagnostic tool.
Scheme 4
| Name | Harness | Description |
|---|---|---|
| DDL1 | Tx Rx | For communications with the diagnostic tool. (CAN-H and CAN-L are used for controlling) |
| DDL2 | K-LINE | For communications with the diagnostic tool. (CAN-H and CAN-L are used for controlling) |
| Diag on CAN | CAN-H CAN-L | For communications with the diagnostic tool. (CAN-H and CAN-L are also used for control and diagnoses.) |
Scheme 5
| Component | Description |
|---|---|
| Main line | CAN communication line between splices |
| Branch line | CAN communication line between splice and a control unit |
| Splice | A point connecting a branch line with a main line |
| Termination circuit | Circuit connected across the CAN communication system. (Resistor) |
Abbreviation List
Unit name abbreviations in CONSULT CAN diagnosis and in this section are as per the following list.
| Abbreviation | Unit name |
|---|---|
| 4WD | AWD control module |
| A-BAG | Air bag diagnosis sensor unit |
| ABS | ABS actuator and electric unit (control unit) |
| BCM | BCM |
| DLC | Data link connector |
| ECM | ECM |
| EPS | EPS control unit |
| HVAC | A/C auto amp. |
| IPDM-E | IPDM E/R |
| M&A | Combination meter |
| MDU | Multi display unit |
| STRG | Steering angle sensor |
| TCM | TCM |
Description
Scheme 6
- CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Many electronic control units are equipped onto a vehicle, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads required data only.
- Termination circuits (resistors) are connected across the CAN communication system. When transmitting a CAN communication signal, each control unit passes a current to the CAN-H line and the current returns to the CAN-L line. The current flows separately into the termination circuits connected across the CAN communication system and the termination circuits drop voltage to generate a potential difference between the CAN-H line and the CAN-L line. The system produces digital signals for signal communications, by using the potential difference.
CAN Communication Line
The CAN communication line is a twisted pair wire consisting of strands of CAN-L (1) and CAN-L (2) and has noise immunity.
Scheme 7
Note. The CAN communication system has the characteristics of noise-resistant because this system produces digital signals by using the potential difference between the CAN-H line and the CAN-L line and has the twisted pair wire structure. Since the CAN-H line and the CAN-L line are always adjacent to each other, the same degree of noise occurs, respectively, when a noise (1) occurs. Although the noise changes the voltage, the potential difference (2) between the CAN-H line and the CAN-L line is insensitive to noise. Therefore, noise-resistant signals can be obtained.
Scheme 8
CAN Signal Communications
Each control unit of the CAN communication system transmits signals through the CAN communication control circuit included in the control unit and receives only necessary signals from each control unit to perform various kinds of control.
Scheme 9
Scheme 10
- Example: Transmitted signals
- Example: Received signals NOTE: The above signal names and signal communications are provided for reference purposes. For CAN communications signals of this vehicle, refer to " «CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART»(ref-516393-S27254564172012120600000) ".
