CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment.
Note. This chart is used if CONSULT does not automatically recognize CAN system type. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 1
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
Scheme 2
CAN COMMUNICATION SYSTEM: CAN System Specification Chart
Determine CAN system type from the following specification chart.
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use CAN system specification chart.
| Body type | Hatch back | |||||
|---|---|---|---|---|---|---|
| Axle | 2WD | AWD | ||||
| Engine | MR16DDT | |||||
| Transmission | M/T | CVT | ||||
| Brake control | VDC | |||||
| Integrated Control system | X | X | X | |||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 |
| CAN communication unit | ||||||
| ECM | X | X | X | X | X | X |
| AWD control module | X | X | ||||
| ABS actuator and electric unit (control unit) | X | X | X | X | X | X |
| IPDM E/R | X | X | X | X | X | X |
| TCM | X | X | X | X | ||
| Data link connector | X | X | X | X | X | X |
| EPS control unit | X | X | X | X | X | X |
| Combination meter | X | X | X | X | X | X |
| Steering angle sensor | X | X | X | X | X | X |
| Air bag diagnosis sensor unit | X | X | X | X | X | X |
| A/C auto amp. | X | X | X | |||
| Multi display unit | X | X | X | |||
| BCM | X | X | X | X | X | X |
| X: Applicable | ||||||
VEHICLE EQUIPMENT IDENTIFICATION INFORMATION
Note. Check CAN system type from the vehicle shape and equipment.
Scheme 3
