Sonar System: Removal & Installation Nissan Armada I рестайлинг

Removal

1. Remove the front fascia assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-382167-S28250454322011011400000) ".
2. Remove the front sonar sensor from the front fascia assembly.
3. Disconnect the front sonar sensor connector.
4. Remove the front sonar sensor housing from the front fascia assembly.

Installation

Installation is in the reverse order of removal.

1. Remove the rear fascia assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-382167-S40580766642011011400000) ".
2. Remove the rear sonar sensor from the rear fascia assembly.
3. Disconnect the rear sonar sensor connector.
4. Remove the rear sonar sensor housing from the rear fascia assembly.

Installation is in the reverse order of removal.

Scheme 118

Scheme 119

1. Remove the luggage side finisher lower LH. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
2. Disconnect the sonar control unit electrical connectors.
3. Remove the bolt, then remove the sonar control unit. Models with front and rear sonar. Front and rear sonar control unit (1) Models with rear sonar only. Rear sonar control unit (1)

Installation is in the reverse order of removal.

Scheme 120

1. Remove the instrument panel upper cover. Refer to " «REMOVAL AND INSTALLATION»(ref-382164-S01662027112011011400000) ".
2. Remove the two bolts (1), disconnect the connector (2) and remove the front buzzer.

Installation is in the reverse order of removal.

1. Partially remove the rear headliner. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S34622778052011011400000) ".
2. Release the buzzer from the bracket, disconnect the connector and remove the buzzer.

Installation is in the reverse order of removal.
