SELF DIAGNOSTIC PROCEDURE

CONSULT-III can be used to read and clear DTCs. Refer to " DESCRIPTION ".

SELF DIAGNOSTIC RESULTS

Refer to " DTC INDEX ".

Scheme 113

Scheme 113: INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT

Scheme 114

Scheme 114
  1. CHECK FUSES Check for blown rear sonar system fuses. FUSES REFERENCE Unit Power Source Fuse Location Sonar control unit ON or START 12 Fuse block (J/B) 51 IPDM E/R Are any fuses blown? YES: If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to " «CIRCUIT INSPECTION»(ref-382152-S11957156732011011400000) ". NO: GO TO 2 .
  2. CHECK POWER SUPPLY CIRCUIT Disconnect sonar control unit connector. Turn ignition switch ON. Check voltage between sonar control unit connector B24 terminal 8 and ground. VOLTAGE SPECIFICATION Terminals Ignition switch position (+) (-) ON or START Connector Terminal B24 8 Ground Battery voltage Is there battery voltage? YES: GO TO 3 . NO: Check harness for open between sonar control unit and fuse.
  3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between sonar control unit B24 terminal 6 and ground. CONTINUITY SPECIFICATION Terminals Continuity (+) (-) Connector Terminal B24 6 Ground Yes Is there continuity? YES: Inspection End. NO: Check harness ground circuit.

Scheme 115

Scheme 115: INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT

Scheme 116

Scheme 116
  1. CHECK FUSES Check for blown sonar system fuses. FUSES REFERENCE Unit Power Source Fuse Location Sonar control unit ON or START 12 Fuse block (J/B) 51 IPDM E/R Are any fuses blown? YES: If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to " «CIRCUIT INSPECTION»(ref-382152-S11957156732011011400000) ". NO: GO TO 2 .
  2. CHECK POWER SUPPLY CIRCUIT Disconnect sonar control unit connector B56. Turn ignition switch ON. Check voltage between sonar control unit connector B56 terminal 1 and ground. VOLTAGE SPECIFICATION Terminals Voltage (+) (-) Connector Terminal B56 1 Ground Battery voltage Is there battery voltage? YES: GO TO 3 . NO: Check harness for open between sonar control unit and fuse.
  3. CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between sonar control unit B56 terminal 4 and ground. CONTINUITY SPECIFICATION Terminals Continuity (+) (-) Connector Terminal B56 4 Ground Yes Is there continuity? YES: Inspection End. NO: Check harness ground circuit.

DTC Index

Fault CodeMalfunctionService Procedure
11Rear sonar sensor LH outerCheck harness for open or short. Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
12Rear sonar sensor LH inner
13Rear sonar sensor RH inner
14Rear sonar sensor RH outer
21Sonar buzzerRefer to " COMPONENT INSPECTION ". Check harness for open or short. Refer to " SYMPTOM TABLE ".
22Sonar system OFF indicatorRefer to " COMPONENT INSPECTION ". Check harness for open or short. Refer to SYMPTOM TABLE .
23Sonar system OFF switch
24Sonar control unitReplace sonar control unit. Refer to " REMOVAL AND INSTALLATION ".

DIAGNOSTIC TROUBLE CODE INDEX

Scheme 117

Scheme 117: SONAR CONTROL UNIT HARNESS TERMINAL LAYOUT
DTCMalfunctionService Procedure
B2700Front sonar sensor LH outerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2701Front sonar sensor LH outer harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2702Front sonar sensor RH outerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2703Front sonar sensor RH outer harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2704Rear sonar sensor LH outerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2705Rear sonar sensor LH outer harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2706Rear sonar sensor RH outerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2707Rear sonar sensor RH outer harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2708Rear sonar sensor LH innerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B2709Rear sonar sensor LH inner harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270ARear sonar sensor RH innerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270BRear sonar sensor RH inner harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270CFront sonar sensor LH innerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270DFront sonar sensor LH inner harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270EFront sonar sensor RH innerReplace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".
B270FFront sonar sensor RH inner harnessCheck harness for open or short. Refer to " DIAGNOSIS PROCEDURE (WITH FRONT AND REAR SONAR SYSTEM) ". Replace sonar sensor. Refer to " REMOVAL AND INSTALLATION ".

DIAGNOSTIC TROUBLE CODE INDEX

Symptom Table

SymptomRepair order
When the sonar system is OFF, the OFF indicator does not light and the sonar buzzer does not sound.Check sonar system OFF switch. Refer to " COMPONENT INSPECTION ". Check harness and connections for sonar system OFF switch. Replace sonar control unit. Refer to " REMOVAL AND INSTALLATION ".
When the sonar system is OFF, the OFF indicator lamp does not light but the sonar buzzer does sound.Check sonar system OFF indicator lamp. Refer to " COMPONENT INSPECTION ". Check harness and connections for sonar system OFF indicator lamp. Replace sonar control unit.
When the sonar system is OFF, the sonar buzzer does not sound but the OFF indicator lamp lights.Check sonar buzzer. Refer to " COMPONENT INSPECTION ". Check harness and connections between sonar buzzer and sonar control unit. Replace sonar control unit.
When sonar system is ON, the sonar system OFF indicator lamp lights up and the sonar buzzer sounds intermittently (for about 4 seconds). (Rear sonar system only)Check harnesses between sonar sensors and sonar control unit for an open condition. Check sonar sensors. Refer to " PRELIMINARY CHECK ". Replace sonar control unit.
The sonar system still operates when the sonar system is OFF.Replace sonar control unit.
When the transmission gear selector lever is in the R position and the sonar system is ON, the rear sonar system does not operate.Check transmission range switch. Refer to " DIAGNOSIS PROCEDURE ". Check back up lamp relay. Check related harness and connections for back up lamp relay. Replace sonar control unit.
When the transmission gear selector lever is in a forward drive gear and the sonar system is ON, the front sonar system does not operate. (With front and rear sonar system only)Check harness and connections between sonar control unit and combination meter. Replace sonar control unit.
Sonar system OFF indicator lamp lights up and buzzer sounds although there are no obstacles within the detection range.Check sonar sensors. Check harness and connections between sonar sensors and sonar control unit. Replace sonar control unit.
The sonar sensors do not detect objects in the detectable range.Check sonar sensors. Replace sonar control unit.

SYMPTOM CHART
