Interior: Removal & Installation Nissan Armada I рестайлинг

Installation

Installation is in the reverse order of removal.

Scheme 72

Removal

1. Remove the power window switch assembly. Disconnect the harness connector.
2. Remove the pull handle cover. Remove the screws behind the pull handle cover.
3. Remove the cap from the inside door handle escutcheon and the remove screw.
4. Remove the inside door handle escutcheon. Remove the screw behind inside door handle escutcheon.
5. Remove step lamp. Disconnect the step lamp harness connector.
6. Remove the door finisher and disconnect lock cable and handle cable from inside door handle assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".
7. Remove the inside door handle assembly.
8. Remove door lock knob.
9. Remove the rear door tweeter.
10. Remove the armrest screws (A), then remove the armrest (1).

Installation is in the reverse order of removal.

Scheme 73

1. Remove push pin from lower dash side finisher.
2. Remove front kicking plate from center pillar lower finisher.
3. Remove lower dash side finisher and front kicking plate together.
4. Remove lower dash side finisher from front kicking plate.

Installation is in the reverse order of removal.

1. Disconnect the battery negative terminal.
2. Remove seat belt anchor. Refer to " «REMOVAL AND INSTALLATION»(ref-382155-S12795378772011011400000) ". On RH side, disconnect seat belt tension sensor.
3. Remove front and rear kicking plates.
4. Remove center pillar lower finisher.

Installation is in the reverse order of removal.

1. Remove front and rear door welts.
2. Disconnect the battery negative terminal.
3. Remove seat belt shoulder anchor and D-ring. Refer to " «REMOVAL AND INSTALLATION OF FRONT SEAT BELT»(ref-382155-S15062218762011011400000) ".
4. Remove front and rear kicking plates.
5. Remove center pillar lower finisher.
6. Remove center pillar assist grip.
7. Remove center pillar upper finisher.

Installation is in the reverse order of removal.

1. Remove front pillar assist grip.
2. Remove front pillar finisher.

Installation is in the reverse order of removal.

Release pawls and remove front and/or rear kicking plates.

Installation is in the reverse order of removal.

1. Open front and/or rear doors fully.
2. Release clips and remove parting seals.

Installation is in the reverse order of removal.

Scheme 74

1. Remove the front seats. Refer to " «REMOVAL AND INSTALLATION»(ref-382174-S15588275752011011400000) ". Remove the subwoofer. Refer to " «REMOVAL AND INSTALLATION»(ref-382170-S08489151712011011400000) ". Remove the navigation display control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-382170-S39381789172011011400000) ".
2. Remove the second row seats. Refer to " «SECOND ROW OUTBOARD»(ref-382174-S24687821402011011400000) ", " «SECOND ROW CENTER»(ref-382174-S17804886032011011400000) " and " «EXPLODED VIEW»(ref-382174-S42076532932011011400000) ", if equipped.
3. Remove the third row rear seats. Refer to " «EXPLODED VIEW»(ref-382174-S09286286382011011400000) ".
4. Remove the lower seat belt anchors. Refer to " «REMOVAL AND INSTALLATION»(ref-382155-S12795378772011011400000) ".
5. Remove the lower body side trim. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S27884325092011011400000) ".
6. Remove the luggage lower side finishers (left/right). Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
7. Remove the kicking plates. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S27884325092011011400000) ".
8. Remove the center console. Refer to " «REMOVAL AND INSTALLATION»(ref-382164-S42816082002011011400000) ".
9. Remove the rear console, if equipped. Refer to " «REMOVAL AND INSTALLATION»(ref-382164-S14734180902011011400000) ".
10. Remove the rear lower finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
11. Remove the carpet.
12. Remove the floor mat hooks from the front carpet.

Installation is in the reverse order of removal.

Scheme 75

Scheme 76

1. Remove the body side trim. Refer to «BODY SIDE TRIM»(ref-382173-S09160421252011011400000) .
2. Remove the luggage floor trim. Refer to «LUGGAGE FLOOR TRIM»(ref-382173-S17822882702011011400000) .
3. Remove the sunvisor assemblies.
4. Insert a suitable thin tool (A) at approximately a 30 degree angle into the sunvisor holder notch on the front of the sunvisor holder (1) and press in the locking tab (B) to release it. While holding in lock tab (B), turn the sunvisor holder (1) 90 degrees to release it from the headliner. If the sunvisor holder (1) does not fully rotate, make sure that the suitable thin tool (A) is pressing in on the locking tab (B) and is not positioned under locking tab (B). Reinsert the suitable thin tool (A) as necessary to release the locking tab (B). <--: Front CAUTION: Do not force the sunvisor holder when removing as the locking tab may be damaged if the suitable thin tool is not positioned correctly.
5. Remove the sunroof welt (if equipped).
6. Remove the front roof console. Disconnect the harnesses.
7. Remove the rear roof console. Disconnect the harnesses.
8. Remove the assist grips.
9. Remove the lamp assembly from the rear roof finisher. Disconnect the harness.
10. Remove the rear roof finisher.
11. Remove the headlining. Remove the clips from rear of headlining. Disconnect the harnesses.
12. Remove the rear air control. Disconnect the harness.
13. Remove the rear audio control assembly. Disconnect the harness.
14. Remove the lamp assemblies. Disconnect the harnesses.
15. Remove the air vents.
16. Remove the front roof console bracket.
17. Remove the rear roof console front bracket.
18. Remove the assist grip brackets from roof.

Installation is in the reverse order of removal.

Scheme 77

1. Remove 2nd and 3rd row seat belts. Refer to " «REMOVAL AND INSTALLATION OF FRONT SEAT BELT»(ref-382155-S15062218762011011400000) ", and " «REMOVAL AND INSTALLATION OF THIRD ROW SEAT BELT»(ref-382155-S42390988582011011400000) ".
2. Remove third row seat belt buckles.
3. Remove third row seat assembly. Refer to " «EXPLODED VIEW»(ref-382174-S09286286382011011400000) ".
4. Remove back door weatherstrip. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02178084482011011400000) ".
5. Remove rear luggage room lamp. Refer to «HEADLINING»(ref-382173-S35421619952011011400000) . Disconnect harness from lamp.
6. Remove rear upper finisher. Refer to «HEADLINING»(ref-382173-S35421619952011011400000) .
7. Remove rear door kicking plates. Refer to «LOWER DASH SIDE FINISHER»(ref-382173-S36779212712011011400000) .
8. Remove rear lower finisher.
9. Disconnect door open/close link. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02178084482011011400000) ".
10. Remove cargo net hooks.
11. Remove luggage side lower finishers LH/RH. Disconnect power point and the third row seat switch harness connectors RH side, if equipped.
12. Remove coat hooks.
13. Remove luggage side upper finishers LH/RH. Disconnect harness to door open/close switch, LH side.
14. Remove tie down hooks LH/RH.
15. Remove floor side finishers LH/RH.
16. Remove luggage floor board.
17. Remove storage box.
18. Remove front luggage floor bracket.
19. Remove rear luggage box bracket.

Installation is in the reverse order of removal.

Scheme 78

1. Disconnect door open/close link. Refer to " «DOOR LOCK ASSEMBLY»(ref-382182-S16403296852011011400000) ".
2. Open back door glass.
3. Remove inside weatherstrip around back door glass.
4. Remove assist handle.
5. Release clips and remove back door lower finisher.
6. Release clips and remove back door upper finisher.
7. Release clips and remove back door side finisher LH and RH.

Installation is in the reverse order of removal.
