HEIGHT DIFFERENCE ADJUSTMENT
If an excessive height difference between glass lid assembly and roof panel is found, adjust in the following manner
- Remove headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S34622778052011011400000) ".
- Loosen sunroof frame assembly nuts and sunroof bracket bolts.
- Add shims until gap is within specification "A-A". NOTE: Temporarily snug nuts and bolts to prevent movement between each adjustment.
- Tilt glass lid assembly up and down several times to check that it moves and seals properly.
- Tighten sunroof frame assembly nuts and sunroof bracket bolts. NOTE: First tighten left front then right rear sunroof frame assembly to prevent uneven torque while tightening remaining sunroof bracket bolts.
- Install headlining. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S34622778052011011400000) ".
Scheme 27
| CAUTION | Always work with a helper. Before removal, fully close the glass lid assembly. Then, after removal, do not move the motor assembly. After installing the sunroof and glass lid, check gap adjustment to ensure there is no malfunction. |
Note. After any adjustment, check sunroof operation and glass lid alignment. Handle glass lid with care so not to cause damage. For easier installation, mark each point before removal.
| CAUTION | Always work with a helper. When taking sunroof unit out, use shop cloths to protect the seats and trim from damage. After installing the sunroof unit and glass lid, be sure to check gap adjustment to ensure there is no malfunction. |
