Emission Control Mfi: Removal & Installation Mitsubishi Outlander II рестайлинг

VACUUM HOSE INSTALLATION

1. When connecting the vacuum hoses, they should be securely inserted onto the nipples.
2. Connect the hoses correctly, using the VACUUM HOSE ROUTING diagram as a guide.

>> B << EGR VALVE GASKET INSTALLATION

Install the EGR valve gasket so that its shaded portion is set as shown in the figure.

Scheme 23

Scheme 24

>> A << EGR VALVE GASKET INSTALLATION

Install the EGR valve gasket as shown in the illustration.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Connect a hand vacuum pump to nipple (A) of the evaporative emission canister and evaporative emission ventilation solenoid assembly.
2. Connect a plug to nipple (B) of the evaporative emission canister and evaporative emission ventilation solenoid assembly.
3. Check air tightness by applying a vacuum with voltage applied directly from the battery to the evaporative emission ventilation solenoid and without applying voltage. BATTERY POSITIVE VOLTAGE APPLICATION REFERENCE CHART Battery voltage Normal condition Applied Vacuum maintained Not applied Vacuum leaks
4. Measure the resistance between the terminals of the solenoid. Standard value: 17 - 21 ohms (at 20°C (68°F))

REMOVAL AND INSTALLATION

1. The catalytic converter is integrated with the center exhaust pipe. The removal and installation is the same as the center exhaust pipe (Refer to «EXHAUST PIPE AND MAIN MUFFLER»(ref-394959-S01312106612011040900000) ) < 2.4L Engine >.
2. The catalytic converter is integrated with the exhaust manifold and center exhaust pipe. The removal and installation is the same as the exhaust manifold and center exhaust pipe (Refer to «EXHAUST MANIFOLD»(ref-394959-S16382669822011040900000) ) and (Refer to «EXHAUST PIPE AND MAIN MUFFLER»(ref-394959-S01312106612011040900000) ) < 3.0L Engine >.
