Testing & Diagnostics 4 illustrations ~306 words

VACUUM HOSE CHECK

  1. Using the VACUUM HOSE ROUTING diagram as a guide, check that the vacuum hoses are correctly connected.
  2. Check the connection condition of the vacuum hoses which can be removed, loosened, clogged possibly. And then check whether there are no folded and damaged vacuum hoses.

< 2.4L Engine >

To inspect these parts, refer to DIAGNOSTIC TROUBLE CODE CHART .

< 3.0L Engine >

To inspect these parts, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

FUEL TANK DIFFERENTIAL PRESSURE SENSOR CHECK

To inspect the sensor, refer to FUEL TANK DIFFERENTIAL PRESSURE SENSOR CHECK .

EVAPORATIVE EMISSION VENTILATION SOLENOID CHECK

Refer to EVAPORATIVE EMISSION VENTILATION SOLENOID CHECK .

EGR VALVE (STEPPER MOTOR) CHECK

Required Special Tool

MB991658: Test Harness Set

To inspect these parts, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect these parts, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

To inspect the sensor, refer to DIAGNOSTIC TROUBLE CODE CHART .

Scheme 36

Scheme 36: REMOVAL AND INSTALLATION < 2.4L ENGINE >

Scheme 37

Scheme 37: >> A << EGR PIPE GASKET/EGR VALVE SUPPORT/EGR SUPPORT STAY B/EGR SUPPORT STAY A/EGR PIPE GASKET/EGR

Scheme 38

Scheme 38

Scheme 39

Scheme 39
  1. Temporarily tighten each part so that the protrusion of each gasket is positioned as illustrated
  2. Tighten mounting bolts to the specified torque in the order of number shown in the figure. Tightening torque: 20 ± 2 N.m (15 ± 1 ft-lb)
