REMOVAL AND INSTALLATION
| CAUTION | Before removing the steering wheel assembly, refer to SERVICE PRECAUTIONS and Air Bag Module and Clock Spring P.52B-439 < Vehicles with WCM >. |
| CAUTION | After the installation, perform a calibration for the ASC-ECU to learn the steering wheel sensor neutral point (Refer to STEERING WHEEL SENSOR CALIBRATION ). < Vehicles with WCM and ASC > |
Scheme 5
Scheme 6
- Insert the key into the steering lock cylinder, and turn the ignition key to the ACC position.
- With using a cross-headed screw driver (small) or similar items to press in the lock pin, remove the ignition key, and then remove the steering lock cylinder.
>> A << WIRELESS CONTROL MODULE (WCM) < VEHICLES WITH WCM >/RECEIVER ANTENNA MODULE < VEHICLES WITH KOS > INSTALLATION
Check that the top claw of receiver antenna module is fixed securely to the boss of steering lock and the antenna is not floated on the key cylinder.
With the ignition switch mounted to the vehicle, disconnect and check the ignition switch connection connector.
| Ignition key position | Terminal number | Normal condition |
|---|---|---|
| LOCK | 1 - 2, 1 - 4, 1 - 5, 1 - 6 | No continuity |
| ACC | 1 - 6 | Continuity exists (2 ohms or less) |
| ON | 1 - 2 - 4 - 6 | Continuity exists (2 ohms or less) |
| START | 1 - 2 - 5 | Continuity exists (2 ohms or less) |
IGNITION SWITCH CONTINUITY CHECK
