FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Amplifier bracket mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
| Amplifier bracket mounting bolt | 5.0 ± 1.0 N.m (44 ± 9 in-lb) |
| Antenna base mounting nut | 3.0 ± 1.0 N.m (27 ± 9 in-lb) |
| Combination meter mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
| Clock mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
| Engine coolant temperature gauge unit | 16 ± 2 N.m (11 ± 1 ft-lb) |
| Fog light assembly mounting bolt | 2.5 ± 0.3 N.m (22 ± 3 in-lb) |
| Hazard warning light switch mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
| Headlight mounting bolt | 4.9 ± 0.7 N.m (44 ± 6 in-lb) |
| 2.5 ± 0.3 N.m (22 ± 3 in-lb) | |
| High-mounted stop light mounting bolt | 2.5 ± 0.3 N.m (22 ± 3 in-lb) |
| Horn mounting bolt | 21 ± 4 N.m (16 ± 2 ft-lb) |
| Meter bezel mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
| Radio bracket mounting screw | 1.5 ± 0.4 N.m (14 ± 4 in-lb) |
| Rear combination light mounting screw | 4.9 ± 0.7 N.m (44 ± 6 in-lb) |
| Speaker mounting screw | 1.5 ± 0.5 N.m (14 ± 4 in-lb) |
Fastener Tightening Specifications
Scheme 1
Scheme 2
