Chassis Electrical: Other Mitsubishi Outlander I

BATTERY CHECK

BATTERY CHARGING

Battery electrolyte temperature may temporarily be allowed to rise to 55°C (131°F). Increase of electrolyte temperature above 55 °C (131°F) is harmful to the battery, causing deformation of battery cell, decrease in life of battery, etc.

CHARGE RATE

If the test indicator is dark, the battery should be charged as outlined below. When the dot appears or when maximum charge shown below is reached, charging should be stopped.

Scheme 280

IGNITION KEY REMINDER TONE ALARM

The ignition key reminder tone alarm will sound under the following condition, and warn the driver to remove the ignition key.

1. The driver's door is opened when the ignition switch is at "LOCK" (OFF) or "ACC" position without removing the ignition key.

However, the light reminder tone alarm will take precedence over this function.

DOOR LOCK PREVENTION FUNCTION

If the key is left in the ignition switch while the driver's door opened or the assistant door opened, all door are automatically unlock to prevent locking the ignition key in the vehicle after door is locked.

IMMOBILIZER SYSTEM

The immobilizer system consists of the ignition key, the immobilizer-ECU, key ring antenna, and the ECM < M/T > or PCM < A/T >. The ignition key has a built-in transponder. Only the registered ignition key permits the engine to start, therefore, the engine can never be started by means of a forged key or by connecting the ignition wiring directly. The system is significantly safe and reliable against theft. In addition, the driver has only to turn the ignition switch to the "ON" position to activate the immobilizer system. If the requirements for starting the engine are not satisfied, the engine will be immobilized. If a registered ignition key is lost, all your ignition keys need to be registered again using scan tool MB991958 (MUT-III Sub Assembly) to ensure security (Refer to HOW TO REGISTER ENCRYPTED CODE ).

An additional ignition key can be registered as follows (only if no ignition keys are lost)

1. Using scan tool MB991958 (MUT-III Sub Assembly) (Refer to «HOW TO REGISTER ENCRYPTED CODE»(ref-236925-S32200938912006071100000) ).
2. By operating two ignition keys that have been already registered (Refer to «HOW TO REGISTER ENCRYPTED CODE»(ref-236925-S32200938912006071100000) ).

Scheme 281

1. When the ignition switch is turned to "ON" position, the ECM < M/T > or PCM < A/T > sends a requirement for the encrypted code to the immobilizer-ECU (at this time, the engine is remobilized).
2. When the immobilizer-ECU receives the requirement from the ECM < M/T > or PCM < A/T >, the immobilizer-ECU supplies power to the transponder inside the ignition key via the antenna. The energized transponder sends the encrypted code back to the immobilizer-ECU via the antenna.
3. The immobilizer-ECU judges the encrypted code with its code logic in itself. If they are identical, the immobilizer-ECU sends the encrypted code to the ECM < M/T > or PCM < A/T >.
4. If the ECM < M/T > or PCM < A/T > can not receive the encrypted code, the engine will be immobilized.

DISPOSITION WHEN REPLACING IMMOBILIZER SYSTEM RELATED PARTS

The replacing immobilizer system related parts is as follows. When the ignition key is re-registered with the MUT-III, the originally registered ignition key registration information will be lost.

IMMOBILIZER SYSTEM RELATED PARTS REFERENCE

HOW TO READ DATA LIST

Required Special Tool

MB991958: Scan Tool (MUT-III Sub Assembly)

1. MB991824: Vehicles Communication Interface (V.C.I.)
2. MB991827: MUT-III USB Cable
3. MB991910: Main Harness A

Scheme 282

1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to "ON" position.
3. Select "Interactive Diagnosis" from the start-up screen.
4. Select "System select."
5. Choose "IMMOBILIZER" from the "POWER TRAIN" tab.
6. Select "Data List."
7. Choose an appropriate item and select the "OK" button.

HOW TO REGISTER ENCRYPTED CODE

Required Special Tools

1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: MUT-III USB Cable MB991911: MUT-III Main Harness A

If the ignition key, immobilizer-ECU, ECM < M/T > or PCM < A/T > is replaced or an ignition key is added, encrypted codes of all the ignition keys must be registered (A maximum of eight different ignition key can be registered). Moreover, when the immobilizer-ECU has been replaced, you will need to use scan tool MB991958 to register the immobilizer-ECU and input the vehicle secret code and to register the password (secret code) that the owner specifies into the immobilizer-ECU. If an attempt is made to start the engine with an unregistered ignition key, cranking occurs, but fuel supply is cut off to disable the engine. In approx. 10 seconds, the theft-alarm indicator will blink for approx. 30 seconds.

Note. PCM has an encrypted code for immobilizer-ECU, and the encrypted code is registered in the immobilizer-ECU and ignition key.

Scheme 283

KEY ID REGISTRATION

All ignition keys can be registered with scan tool MB991958. Additional ignition keys can be registered with or without scan tool MB991958.

TRANSPONDER LOCK CHECK

Required Special Tools

1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: MUT-III USB Cable MB991911: MUT-III Main Harness A

Follow the procedure below to judge if the ignition key can be overwritten (i.e. the ignition key is correct) or not.

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

1. Connect the scan tool MB991958 to the data link connector.
2. Turn the ignition switch to "ON" position.
3. Select "Interactive Diagnosis" from the start-up screen.
4. Select "System select."
5. Choose "IMMOBILIZER" from the "POWER TRAIN" tab.
6. Select "Data List."
7. The multi-center display shows whether the ignition key, which has been inserted in the switch, can be rewritten and how many ignition keys have ever been registered. IGNITION KEY REFERENCE TP LOCK CHECK IGNITION KEY: JUDGMENT OF IGNITION KEY UNLOCK Can be overwritten Correct LOCK Can not be overwritten Incorrect

Scheme 289

Scheme 290

1. Using a small Phillips head screwdriver, pull the steering lock cylinder toward you.

IGNITION SWITCH CONTINUITY CHECK

Disconnect ignition switch connector C-303 without removing the ignition switch. Then check the continuity.

TESTER CONNECTION AND CONDITION

Scheme 291

KEY REMINDER SWITCH CONTINUITY CHECK

Disconnect key reminder switch connector C-304 without removing the ignition switch and key reminder switch. Then check the continuity.

Scheme 292

TESTER CONNECTION AND CONDITION

SPEEDOMETER CHECK

Adjust the pressure of tires to the specified level. (Refer to ON-VEHICLE SERVICE ).

Scheme 293

Scheme 294

Scheme 295

1. Set the vehicle onto a speedometer tester and use wheel chocks to hold the rear wheels.
2. To prevent the front wheel from moving from side to side, attach tension bars to the tie-down hook, and secure both ends to anchor plates.
3. To prevent the vehicle from moving, attach a chain or wire to the rear retraction hook, and make sure the end of the chain or wire is secured.
4. Check if the speedometer indicator range is within the standard values. Standard value: INDICATOR REFERENCE STANDARD INDICATION km/h (mph) ALLOWANCE RANGE km/h (mph) 32 (20) 31 - 35 (19 - 22) 64 (40) 61 - 71 (38 - 44) 97 (60) 92 - 106 (57 - 66) 129 (80) 122 - 142 (76 - 88) 161 (100) 151 - 177 (94 - 110)
5. If not to the standard value, inspect for proper tire size. If not correct, replace the tires with original size tires and retest. If correct, replace the speedometer. If still not to standard value, replace the vehicle speed sensor.

Scheme 296

1. Attach an external high quality tachometer to the engine speed detection connector on the harness side (such as with a paper clip). NOTE: For tachometer check, use an external high quality inductive tachometer.
2. Compare the readings of the vehicle tachometer and the external tachometer at every engine speed, and check if the variations are within the standard values. Standard values: < A/T > ENGINE SPEED REFERENCE ENGINE SPEED (r/min) INDICATION ALLOWANCE OF TACHOMETER (r/min) 700 +/-100 3000 +/-150 5000 +/-250 6250 +/-150 < M/T > ENGINE SPEED REFERENCE ENGINE SPEED (r/min) INDICATION ALLOWANCE OF TACHOMETER (r/min) 700 +/-100 3000 +/-150 5000 +/-250 6000 +/-300

FUEL LEVEL SENSOR CHECK < FWD >

Remove the fuel pump module and the remove the fuel level sensor (Refer to FUEL TANK ).

Scheme 297

1. Check that resistance value between the fuel gauge terminal and ground terminal is at the standard value when the fuel level sensor float is between point "F" (highest) and point "E" (lowest). Standard value: Point "F": 2.2 - 3.8 ohms Point "E": 107.5 - 112.5 ohms
2. Check that resistance value changes smoothly when the float moves slowly between point "F" (highest) and point "E" (lowest).
3. If all checks are correct, go to fuel level sensor float height check. If any check is not correct, replace the fuel level sensor.

Scheme 298

1. Move the float and measure height A at point "F" (highest) and B at point "E" (lowest) with the float arm touching stopper. Standard value: A: 35.4 mm (1.39 inches) B: 186.7 mm (7.35 inches)
2. Adjust the float arm to the standard value, then go to the thermistor check.

FUEL LEVEL SENSOR CHECK < AWD >

Remove the fuel pump module and the remove the fuel level sensor (Refer to FUEL TANK ).

Scheme 299

1. Check that resistance value between the fuel gauge terminal and ground terminal is at the standard value when the fuel level sensor float is between point "F" (highest) and point "E" (lowest). Standard value: Point "F": 1.0 - 2.0 ohms Point "E": 53.5 - 56.5 ohms
2. Check that resistance value changes smoothly when the float moves slowly between point "F" (highest) and point "E" (lowest).
3. If all checks are correct, go to fuel level sensor float height check. If any check is not correct, replace the fuel level sensor.

Scheme 300

1. Move the float and measure height A at point "F" (highest) and B at point "E" (lowest) with the float arm touching stopper. Standard value < FUEL PUMP MODULE & FUEL LEVEL SENSOR > : A: 36.7 mm (1.44 inches) B: 150 mm (5.91 inches) Standard value < FUEL LEVEL SENSOR > : A: 20.8 mm (0.82 inch) B: 193.8 mm (7.63 inches)
2. Adjust the float arm to the standard value, then go to the thermistor check.

Scheme 301

Scheme 302

1. Drain the engine coolant. (Refer to «ENGINE COOLANT»(ref-236914-S05503940672006071200000) .)
2. Remove the engine coolant temperature gauge unit.
3. Put water temperature gauge unit into the hot water in specified temperature, and ensure that basic resistance is within standard value. Standard value: 70C° (150°F) 104 +/- 13.5 ohm Reference value TEMPERATURE AND RESISTANCE REFERENCE Temperature °C (°F) Resistance ohms 50 (122) 230 60 (140) 155 80 (176) 73
4. After inspection, apply specified sealant at threads of water temperature gauge unit, and tighten to the specified torque. Semi-drying sealant: 3M™ ADD part No.8731 or equivalent
5. Add engine coolant. (Refer to «ENGINE COOLANT»(ref-236914-S05503940672006071200000) .)

Scheme 303

Scheme 304

Taillight control

The taillight lights up by turning on the taillight relay built-in the front-ECU, after receiving the taillight switch ON signal from the column switch. What's more, the lights automatically dim with the headlight automatic shutdown function.

The tail lights are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

Headlight control

The headlight lights up by turning on the headlight relay built-in the front-ECU, after receiving the headlight switch ON signal from the column switch.

What's more, the lights automatically dim with the headlight automatic shutdown function.

The headlights are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

HEADLIGHT AUTOMATIC SHUTDOWN FUNCTION

The headlight automatic shutdown function is activated with the following procedures. What's more, the user can switch the operations Yes/No mode and operation conditions from the adjustment function. Refer to ADJUSTMENT PROCEDURES OF SWS FUNCTION for adjustment methods and adjustment details (post-adjustment operations).

1. Ignition Switch: ON or ACC
2. Headlight switch: ON
3. Driver's door: Open (Driver's door switch: ON)
4. Ignition Switch: LOCK (OFF)

Note. The headlight automatic shutdown function is activated even if the order of Step 3 and 4 are reversed.

Restoration conditions from automatic light shutdown taking effect with the headlight automatic shutdown function.

1. Turn OFF the headlight switch and then turn ON the headlight switch again. NOTE: The lights may dim again 3 minutes after the lights are restored with the headlight switch depending on the settings (adjustment functions).
2. Turn the ignition switch from the "LOCK" (OFF) position to the ON position.

The headlight automatic shutdown function are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

TURN-SIGNAL LIGHT FUNCTION

The turn-signal light function takes effect according to the following conditions.

1. Ignition Switch: ON or ACC
2. TURN-SIGNAL LIGHT SWITCH (RH or LH): ON

The turn-signal lights are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

HAZARD WARNING LIGHT FUNCTION

The hazard warning light function takes effect by turning on the hazard warning light switch.

The hazard warning lights are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

LUMINOUS INTENSITY MEASUREMENT

1. Set the headlights to high-beam.
2. Using a photometer, and following its manufacturer's instruction manual, measure the headlight center intensity and check to be sure that the limit value is satisfied. Limit: 40,000 cd or more [When a screen is set 18.3 m (60.0 feet) ahead of the vehicle] NOTE: When measuring the intensity, maintain an engine speed of 2,000 r/min, with the battery fully charged. There may be special local regulations pertaining to headlight intensity. Be sure to make any adjustments necessary to satisfy such regulations. If an illuminometer is used to make the measurements, convert its values to photometer values by using the following formula. I =2Er: I = intensity (cd) E = illumination (lux) r = distance (m) from headlights to illuminometer

Scheme 305

Scheme 306

Scheme 307

1. Disconnect the connector.
2. Remove the socket cover. CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may pop after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
3. Release the bulb securing spring, and remove the bulb.
4. Replace the bulb, and connect the connector securely.

Scheme 308

1. Disconnect the connector. CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may pop after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
2. Twist the socket to withdraw the bulb.
3. Replace the bulb, and connect the connector securely.

Front Side-marker Light Bulb

Scheme 309

1. Twist the socket to withdraw the bulb.
2. Replace the bulb, and connect the connector securely.

Scheme 310

Scheme 311

1. Lift up the reserve tank assembly, remove it from the holder, and place it in the space. (Left-side headlight only) CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may pop after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
2. Twist the socket to withdraw the bulb.
3. Replace the bulb, and connect the connector securely.

Scheme 312

Scheme 313

1. Lift up the reserve tank assembly, remove it from the holder, and place it in the space. (Left-side headlight only) CAUTION: Do not touch the surface of the bulb with hands or dirty gloves as the bulb may pop after a short time. If the surface does become dirty, clean it with alcohol or thinner, and let it dry thoroughly before installing.
2. Twist the socket to withdraw the bulb.
3. Replace the bulb, and connect the connector securely.

Scheme 314

FOG LIGHT SWITCH CONTINUITY CHECK

FOG LIGHT SWITCH CONTINUITY CHECK

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Room light delay shutdown function

The room light off is delayed by ETACS-ECU. The lights off delay time vary according to the conditions. The control details are as follows. The light delay off Yes/NO and delay time can be set with the settings (adjustment function). Refer to ADJUSTMENT PROCEDURES OF SWS FUNCTION for adjustment methods and adjustment details (post-adjustment operations).

1. The room light lights up if the ignition switch is at the "LOCK" (OFF) position and either of the doors are opened (either of the door switches: ON). At this time, if all doors are closed (all door switches: OFF) then the light will gradually dim down to lights off in about 30 seconds. NOTE: When the lights are dimmed and the ignition switch is turned ON or if the door is locked, then the dimming operations stop and the lights are turned OFF.
2. When the ignition switch is at the ON position and one of the doors are opened (one of the door switches: ON) then the room light will light up. At this time, if all doors are closed (all door switches: OFF) then the lights will dim out.
3. When the ignition key is pulled out the room light lights up and then will dim out in 30 seconds. The light will dim out if the ignition key is inserted again and the door is locked while the timer is activated.

The dome light is controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

Interior light automatic cut function

The interior light automatic cut function, dims out the room light and other interior lights by activating the keep relay built-in the ETACS-ECU when the ignition switch is OFF and the multi-purpose fuse loaded signals built-in the ETACS-ECU is ON and 30 second passes. The lights light back up if the ignition switch is turned to the ON position or either of the doors is opened (either of the door switches: ON). The function Yes/No feature can be changed with the settings (adjustment function). Refer to ADJUSTMENT PROCEDURES OF SWS FUNCTION for adjustment methods and adjustment details (post-adjustment operations).

The headlights are controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .

Scheme 320

Scheme 321

Scheme 322

Scheme 323

1. Connect the battery and the test bulb (40 W) as shown in the illumination.
2. Operate the rheostat, and if brightness changes smoothly without switching off, rheostat function is normal.

Scheme 324

HAZARD WARNING LIGHT SWITCH CONTINUITY CHECK

HAZARD WARNING LIGHT SWITCH CONTINUITY CHECK

Scheme 325

Scheme 326

Scheme 327

TURN-SIGNAL AND LIGHTING SWITCH CHECK

TURN-SIGNAL AND LIGHTING SWITCH CHECK

Scheme 328

< HEADLIGHT >

HEADLIGHT VALUE REFERENCE

< FOG LIGHT >

FOG LIGHT VALUE REFERENCE

< COMBINATION METER >

SEALANTS AND ADHESIVE SPECIFICATION
