WINDOW GLASS INSTALLATION

Scheme 23

>>A<< WINDSHIELD SPACER/GLASS STOPPER/WINDSHIELD UPPER MOLDING/WINDSHIELD SIDE MOLDING INSTALLATION

Scheme 24

Scheme 25

1. Use 3M™ AAD Part number 8906 or equivalent to degrease the inside and outside of the windshield and the body flanges.
2. Install the windshield spacer and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the windshield glass.
3. Install the adhesive tape to the windshield glass.
4. Install the windshield molding and front deck garnish retainer to the windshield glass.

Scheme 26

Scheme 27

1. When replacing the windshield, temporarily set the windshield against the body, and place a mating mark on the windshield and body. CAUTION: The primer strengthens the adhesive, so be sure to apply it evenly around the entire circumference. However, a too thick application will weaken the adhesive. Do not touch the coated surface. Do not apply the primer on the remaining adhesive because of weakening the adhesive.
2. Soak a sponge in the primer, and apply evenly to the windshield and the body in the specified places.
3. Allow the windshield to dry for at least three minutes after applying primer.
4. Fill a sealant gun with adhesive. Then apply the adhesive evenly around the windshield within 30 minutes after applying the primer. NOTE: Cut the tip of the sealant gun nozzle into a V shape to simplify adhesive application.
5. Align the mating marks on the windshield and the body, and lightly press the windshield evenly so that it adheres completely.
6. Use a spatula or similar tool to remove any excessive adhesive. Clean the surface with 3M™ AAD Part number 8906 or equivalent. Avoid moving the vehicle until the adhesive sets. CAUTION: Do not move the vehicle unless absolutely necessary. When testing for water leakage, do not apply strong water pressure.
7. Wait 30 minutes or more, and then test for water leakage.

Scheme 28

< > REAR WINDOW GLASS REMOVAL

Remove the rear window glass using the same procedure as for the windshield (Refer to WINDSHIELD ).

Note. Use a piano wire to remove the rear window glass.

>>A<< FASTENER/REAR WINDOW SPACER/GLASS STOPPER/REAR WINDOW UPPER DAM/REAR WINDOW SIDE DAM INSTALLATION

Scheme 29

Scheme 30

Scheme 31

1. Use 3M™ AAD Part number 8906 or equivalent. to degrease the inside and outside edges of the rear window glass and the surface of the body flange.
2. Install the fastener, rear window spacers, and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the rear window glass.
3. Install the fasteners to the specified positions on the body flange.
4. Install the rear window upper dam and side dam to the rear window glass.

>>B<< REAR WINDOW GLASS INSTALLATION

1. Apply the primer and adhesive.
2. Install the rear window glass in the same way as for the windshield glass installation (Refer to «WINDSHIELD»(ref-592716-S00710258532014011000000) ).
