HEADLIGHT BULB (LOW-BEAM) REPLACEMENT - VEHICLES WITHOUT DISCHARGE HEADLIGHT
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Disconnect the connector, and twist the headlight bulb (low-beam) to remove.
Scheme 44
HEADLIGHT BULB (HIGH-BEAM) REPLACEMENT - VEHICLES WITHOUT DISCHARGE HEADLIGHT
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Scheme 45
- Twist the socket cover to remove.
- Disconnect the connector, and twist the headlight bulb (high-beam) to remove.
Scheme 46
- Twist the socket cover to remove.
- Twist the daytime running light socket to remove it.
POSITION LIGHT BULB REPLACEMENT
Disconnect the connector, and twist the position light socket to remove it.
Scheme 47
FRONT TURN-SIGNAL LIGHT BULB REPLACEMENT
Disconnect the connector, and twist the front turn-signal light socket to remove it.
Scheme 48
<< B >> HEADLIGHT BULB REMOVAL - VEHICLES WITH DISCHARGE HEADLIGHT
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Scheme 49
Scheme 50
Scheme 51
- Twist the socket cover to remove.
- Disconnect the igniter.
- Release the bulb securing spring, and remove the bulb.
Scheme 52
- As shown in the illustration, doubly wrap the portion in the vinyl tape, from the headlight control unit connector root to the point where the harness separation is hidden.
- Install the harness to the headlight assembly. At that time, fitting the harness into the resin washer is unnecessary.
Scheme 53
Scheme 54
<< A >> LIGHTING CONTROL SENSOR REMOVAL
While pushing the clamp to the windshield side, pry up the clamp to disengage the right and left claws using the screwdriver (-), and then remove the lighting control sensor.
Scheme 55
>> A << LIGHTING CONTROL SENSOR INSTALLATION
| CAUTION | After executing the lighting control sensor (rain sensor) adaptation, do not touch the lighting control sensor (or do not move it from the fixed position). |
- Mount the lighting control sensor onto the optical coupler, and then connect the connector.
- When reusing the lighting control sensor or when the lighting control sensor is pushed to check the installation condition, install the connector and the lighting control sensor cover and wipe the windshield thoroughly. When the windshield is dry, execute the lighting control sensor (rain sensor) adaptation. < Refer to «LIGHTING CONTROL SENSOR (RAIN SENSOR) ADAPTATION»(ref-592630-S39518528672014011000000) >.
Note. Be careful not to touch the lighting control sensor receiver. (The lighting control sensor receiver has limited resistance to oil.)
