DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION | |
|---|---|---|---|
| OFF | 9 - 2, 9 - 3, 9 - 6, 9 - 10, 9 - 11, 1 - 2, 1 - 3, 1 - 6, 1 -10, 1 - 11 | Open circuit | |
| Left side | OFF | 9 - 6, 9 - 10, 9 - 11, 1 - 6, 1 - 10, 1 - 11 | Open circuit |
| Up | 1 - 6, 9 - 11 | Continuity (Less than 2 ohms) | |
| Down | 1 - 11, 6 - 9 | ||
| Right | 1 - 6, 9 - 10 | ||
| Left | 1 - 10, 6 - 9 | ||
| Right side | OFF | 9 - 2, 9 - 3, 9 - 6, 1 - 2, 1 - 3, 1 - 6 | Open circuit |
| Up | 1 - 6, 3 - 9 | Continuity (Less than 2 ohms) | |
| Down | 1 - 3, 6 - 9 | ||
| Right | 1 - 6, 2 - 9 | ||
| Left | 1 - 2, 6 - 9 | ||
DOOR MIRROR CONTROL SWITCH CONTINUITY CONDITIONS
Scheme 13
HEATED DOOR MIRROR CHECK
| CAUTION | When relocating the car between locations with extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. |
Check that the resistance value between the connector terminals is at the standard value.
Standard value: 8.4 ± 1.2 ohms at 25°C (77°F)
