Engine Cooling System - Lancer: Removal & Installation Mitsubishi Lancer X рестайлинг

>> A << THERMOSTAT INSTALLATION

Install the thermostat so that the jiggle valve is facing straight up. Be careful not to fold or scratch the rubber ring.

Scheme 7

Scheme 8

1. Insert the radiator lower hose as far as the projection of the cooling water inlet hose fitting.
2. Align the mating marks on the radiator lower hose and hose clamp, and then connect the radiator lower hose.

Scheme 9

Install the thermostat so that the jiggle valve is facing straight up. Be careful not to fold or scratch the rubber ring.

Scheme 10

<< B >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

Use special tool MB992042 to remove the engine coolant temperature sensor.

Scheme 11

>> A << O-RING INSTALLATION

Fit the O-ring in the water pump inlet pipe groove, wet the O-ring circumference or the pipe mounting area inner wall, and then insert the O-ring.

Scheme 12

Scheme 13

1. Apply the specified sealant to the engine coolant temperature sensor thread. Specified sealant: Three bond 1324N or equivalent NOTE: Install the engine coolant temperature sensor immediately after applying sealant. CAUTION: After the installation, until a sufficient period of time (one hour or more) elapses, do not apply the oil or water to the sealant application area or start the engine.
2. Use special tool MB992042 to tighten the engine coolant temperature sensor to the specified torque.

Tightening torque: 30 ± 9 N.m (22 ± 7 ft-lb)

<< C >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

Use special tool MB992042 to remove the engine coolant temperature sensor.

Scheme 14

>> A << ENGINE COOLANT TEMPERATURE SENSOR INSTALLATION

1. Apply the specified sealant to the engine coolant temperature sensor thread. Specified sealant: Three bond 1324N or equivalent NOTE: Install the engine coolant temperature sensor immediately after applying sealant. CAUTION: After the installation, until a sufficient period of time (one hour or more) elapses, do not apply the oil or water to the sealant application area or start the engine.
2. Use special tool MB992042 to tighten the engine coolant temperature sensor to the specified torque.

Tightening torque: 30 ± 9 N.m (22 ± 7 ft-lb)

Scheme 15

Scheme 16

1. Pull up the retainer of fuel high-pressure hose to unlock before installing.
2. Securely insert the fuel rail stopper into the fuel high-pressure hose connector groove to install the fuel high-pressure hose to the fuel rail. CAUTION: When pushing in the retainer of the fuel high-pressure hose connector, pay attention to avoid damage to the retainer. After the installation of the fuel high-pressure hose, slightly pull the fuel high-pressure hose to check that it is connected securely. At this time, also check that there is approximately 1 mm (0.04 inch) play.
3. Push in the retainer of the fuel high-pressure hose connector to lock the fuel high-pressure hose and fuel rail.

>> C << O-RING INSTALLATION

Fit the O-ring in the water pump inlet pipe groove, wet the O-ring circumference or the pipe mounting area inner wall, and then insert the O-ring.

<< A >> RADIATOR UPPER HOSE/RADIATOR LOWER HOSE REMOVAL

Make mating marks on the radiator hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 17

<< B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL

Remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly according to the following procedure.

Scheme 18

1. Release the upper locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly.
2. Slightly raise the fan, fan motor and cooling fan shroud assembly.
3. Release the lower locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly, and remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly.

>> A << RADIATOR LOWER HOSE/RADIATOR UPPER HOSE INSTALLATION

1. Insert radiator hose as far as the projection of the cooling water inlet hose fitting, cooling water outlet hose fitting or radiator.
2. Align the mating marks on the radiator hose and hose clamp, and then connect the radiator hose.

Scheme 19

Make mating marks on the radiator hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 20

Remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly according to the following procedure.

Scheme 21

1. Release the upper locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly.
2. Slightly raise the fan, fan motor and cooling fan shroud assembly.
3. Release the lower locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly, and remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly.

1. Insert radiator hose as far as the projection of the cooling water inlet hose fitting, cooling water outlet hose fitting or radiator.
2. Align the mating marks on the radiator hose and hose clamp, and then connect the radiator hose.
