COOLANT

COOLANT CAPACITY TABLE

SEALANT

COOLING SYSTEM SEALANT TABLE

ENGINE COOLANT LEAK CHECK

Scheme 24

1. Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections.
2. If there is leakage, repair or replace the appropriate part.

RADIATOR CAP OPENING PRESSURE CHECK

Note. Be sure that the radiator cap is clean before testing. Rust or other foreign material on the radiator cap seal will cause an improper reading.

Scheme 25

1. Use a cap adapter to attach the radiator cap to the tester.
2. Increase the pressure until the indicator of the gauge stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi)
3. Replace the radiator cap if the reading does not remain at or above the limit.

ENGINE COOLANT CHANGE - 2.0L ENGINE NON-TURBO, 2.4L ENGINE

Required Special Tool

1. MB991871: LLC changer

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Remove the engine room under cover front A (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
3. Remove the engine room under cover front B (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .)
4. Disconnect the cooling water line hose and drain the engine coolant in the water jacket.
5. Drain the water in the water jacket by unplugging the drain plug of the cylinder block.
6. Remove the radiator condenser tank and drain the engine coolant.
7. Connect the cooling water line hose.
8. Replace the cylinder block drain plug gasket, and tighten the drain plug to the specified torque. Tightening torque: 39 ± 3 N.m
9. Securely tighten the radiator drain plug.
10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.0 dm 3 (7.4 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
12. Tighten the radiator cap securely.
13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
19. Reinstall the engine room under cover front A, B (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .)

ENGINE COOLANT CHANGE - 2.0L ENGINE TURBO

Required Special Tool

1. MB991871: LLC changer

Scheme 30

Scheme 31

1. Remove the engine room under cover front A (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
3. Remove the engine room under cover front B. (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .)
4. Remove the air cleaner intake hose (Refer to «AIR CLEANER»(ref-592640-S40921057122014011000000) .)
5. Disconnect the turbocharger water return hose and drain the engine coolant in the water jacket.
6. Remove the radiator condenser tank and drain the engine coolant.
7. Connect the turbocharger water return hose.
8. Reinstall the air cleaner intake hose (Refer to «AIR CLEANER»(ref-592640-S40921057122014011000000) .)
9. Securely tighten the radiator drain plug.
10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.5 dm 3 (7.9 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
12. Tighten the radiator cap securely.
13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
19. Reinstall the engine room under cover front A, B (Refer to «REMOVAL AND INSTALLATION»(ref-592725-S30060864712014011000000) .)

WATER PUMP COOLANT LEAK CHECK

If a residue of the coolant draining is found on the drain hole, the vapor hole and the installation surface, check the water pump leakage by following method.

Scheme 32

1. Wipe off the residue of the coolant draining on the water pump. WARNING: Make sure that the coolant is cold when removing the radiator cap.
2. Remove the radiator cap. CAUTION: Do not pressures 100 kPa (15 psi) or more.
3. Install the radiator tester and pressures at 100 kPa (15 psi.)
4. Hold the pressurized state for 20 minutes, and check that the water leakage from the drain hole, the vapor hole or the installation surface of the water pump.
5. Remove the radiator tester, and install the radiator cap.
6. Warm up the engine, let it idle for 20 minutes and stop it.
7. After stopping the engine, and check that the water leakage from the drain hole, the vapor hole or the installation surface of the water pump.
8. If the water leakage is found in step 4 or 7 , replace the water pump (Refer to «WATER PUMP»(ref-592635-S37630926742014011000000) ) < 2.0L ENGINE Non-turbo, 2.4L ENGINE > or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(ref-592635-S39791324262014011000000) ) < 2.0L ENGINE Turbo >.

RADIATOR FAN RELAY CHECK

COOLING FAN RELAY FUNCTION TABLE

Scheme 33

CONDENSER FAN RELAY CHECK

CONDENSER FAN RELAY FUNCTION TABLE

Scheme 34

FAN CONTROL RELAY CHECK

FAN CONTROL RELAY FUNCTION TABLE

Scheme 35

COOLING FAN RELAY FUNCTION TABLE

Scheme 36

CONDENSER FAN RELAY FUNCTION TABLE

Scheme 37

FAN CONTROL RELAY FUNCTION TABLE

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Disconnect the fan motor connector.
2. Check that the fan motor runs when a positive battery terminal is connected to the fan motor-side connector terminal number 1, and terminal number 2 is grounded. Also check to see that there is no abnormal sound emitted from the fan motor at this time.
3. If the fan motor is defective, replace it (Refer to «<< B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL»(ref-592635-S33669268952014011000000) .)
4. Connect the fan motor connector.

Scheme 42

Scheme 43

Scheme 44

1. Disconnect the fan motor connector.
2. Check that the fan motor runs when a positive battery terminal is connected to the fan motor-side connector terminal number 1, and terminal number 2 is grounded. Also check to see that there is no abnormal sound emitted from the fan motor at this time.
3. If the fan motor is defective, replace it (Refer to «<< B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL»(ref-592635-S33992760362014011000000) .)
4. Connect the fan motor connector.

Scheme 45

<< A >> RADIATOR LOWER HOSE DISCONNECTION

Make mating marks on the radiator lower hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 46

Make mating marks on the radiator lower hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 47

>> B << RADIATOR LOWER HOSE CONNECTION

1. Insert the radiator lower hose as far as the projection of the cooling water inlet hose fitting.
2. Align the mating marks on the radiator lower hose and hose clamp, and then connect the radiator lower hose.

Scheme 48

Scheme 49

1. Immerse the thermostat in water, and heat the water while stirring. Check the thermostat valve opening temperature. Standard value: 87 ± 1.5°C (189 ± 3°F) < 2.0L ENGINE Non-turbo, 2.4L ENGINE > 76.5 ± 1.5°C (170 ± 3°F) < 2.0L ENGINE Turbo >
2. Check that the amount of valve lift is at the standard value when the water is at the full-opening temperature. NOTE: Measure the valve height when the thermostat is fully closed, and use this measurement to compare the valve height when the thermostat is fully open. Standard value: Full-opening temperature: 95°C (203°F) < 2.0L ENGINE Non-turbo, 2.4L ENGINE > 90°C (194°F) < 2.0L ENGINE Turbo > Amount of valve lift: 8.5 mm (0.33 inch) or more

Scheme 50

Scheme 51

Scheme 52

Required Special Tool

1. MB992042: Water Temp Sensor Wrench

<< A >> RADIATOR UPPER HOSE DISCONNECTION

Make mating marks on the radiator upper hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 53

>> C << RADIATOR UPPER HOSE CONNECTION

1. Insert radiator upper hose as far as the projection of the cooling water outlet hose fitting.
2. Align the mating marks on the radiator upper hose and hose clamp, and then connect the radiator upper hose.

Scheme 54

Required Special Tool

1. MB992042: Water Temp Sensor Wrench

Make mating marks on the radiator upper hose and the hose clamp as shown in the illustration to install them in the original position. Then, remove them.

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. Follow the steps below to unlock the fuel high-pressure hose connector. Insert a flat-tipped screwdriver [6 mm (0.24 inch) wide and 1 mm (0.04 inch) thick] into the retainer of the fuel high-pressure hose connector. CAUTION: When pushing up the retainer of the fuel high-pressure hose connector, pay attention to avoid damage to the retainer. Turn the flat-tipped screwdriver inserted into the retainer by 90 degrees angle to push up the retainer and unlock the fuel high-pressure hose connector.
2. Disconnect the fuel high-pressure hose.

>> D << RADIATOR UPPER HOSE CONNECTION

1. Insert radiator upper hose as far as the projection of the cooling water outlet hose fitting.
2. Align the mating marks on the radiator upper hose and hose clamp, and then connect the radiator upper hose.

Water Pipe And Hose Check

Check the water pipe and hose for cracks, damage and clogs. Replace them if necessary.

Scheme 59
