CIRCUIT OPERATION

  1. The windshield wiper and washer switch sends a signal through the column-ECU (incorporated in the column switch) to the ETACS-ECU. If the column-ECU sends a windshield wiper and washer switch "ON" signal to the ETACS-ECU, the ETACS-ECU turns on the relay (incorporated in the ETACS-ECU), thus causing the windshield wiper and washer motor to be turned on.
  2. If the LIN communication line is defective, the ETACS-ECU operates windshield wiper motor by using the other communication lines (wiper backup circuit) instead of that line. In this case, the windshield wiper works at low speed regardless of the windshield wiper and washer switch positions ("LO" or "HIGH").

TECHNICAL DESCRIPTION (COMMENT)

If the windshield wiper does not work at all, the windshield wiper motor, column switch (windshield wiper and washer switch) or the ETACS-ECU may be defective.

This system may be at fail-safe mode if the LIN communication line is defective.

If the system cannot receive any signal from the column switch (windshield wiper and washer switch) due to a open circuit in the LIN communication line or other reasons, the system will enter the fail-safe mode when the ignition switch is at the "ACC" position.

If the windshield wipers do not stop at predetermined park position, the windshield wiper motor or the ETACS-ECU may be defective.

If either of the windshield wiper switch positions is defective, the windshield wiper motor, column switch (windshield wiper and washer switch) or the ETACS-ECU may be defective.

If the windshield intermittent wiper interval is not changed by operating the windshield intermittent wiper interval adjusting knob or according to the vehicle speed, the column switch or the ETACS-ECU may be defective.

If the intermittent wiper interval does not depend on the vehicle speed, the input circuit of the vehicle speed signal and the ETACS-ECU may be defective. Alternatively, the vehicle speed-dependent wiper may be set to "disabled" by using the configuration function.

When the column switch is in the AUTO position, this function automatically adjusts the wiping speed of windshield wiper by detecting the rain fall through lighting control sensor.

The windshield wiper motor, the column switch, the lighting control sensor, the harness connector, or the ETACS-ECU may be defective.

The lighting control sensor, the harness connector, or the ETACS-ECU may be defective.

The lighting control sensor may be defective or a failure in the lighting control sensor (rain sensor) adaptation is suspected.

The windshield washer switch sends a signal through the column-ECU (incorporated in the column switch) to the ETACS-ECU. If the column-ECU sends a windshield washer switch "ON" signal to the ETACS-ECU, the ETACS-ECU turns on the relay (incorporated in the ETACS-ECU), thus causing the washer motor to be turned on.

If the windshield washer does not work normally, the washer motor, the column switch (windshield wiper and washer switch) or the ETACS-ECU may be defective.

WINDSHIELD WIPER MOTOR AT LOW OR HIGH SPEED OPERATION

Connect the battery to the windshield wiper motor to inspect the operation of motor rotation at low or high speed.

WINDSHIELD WIPER MOTOR AT STOP POSITION OPERATION

  1. Connect the battery to the windshield wiper motor as shown in the illustration (A).
  2. Run the windshield wiper motor at low speed, then disconnect the battery in the middle of the motor rotation and check to see that the motor stops.
  3. Connect the battery to the windshield wiper motor as shown in the illustration (B).
  4. Connect the terminals of the windshield wiper motor connector as shown in the illustration (B).
  5. Check to see that the windshield wiper motor runs at low speed and then stops at the automatic stop position.

REMOTE CONTROLLED MIRROR OPERATION CHECK

Check that the mirror moves as described in the table when each terminal is connected to the battery.

Scheme 1

Scheme 1: REMOTE CONTROLLED MIRROR OPERATION CHECK
Battery connectionDirection operation
Connect terminal 8 to the negative battery terminal. Connect terminal 6 to the positive battery terminal.Up
Connect terminal 8 to the positive battery terminal. Connect terminal 6 to the negative battery terminal.Down
Connect terminal 8 to the negative battery terminal. Connect terminal 7 to the positive battery terminal.Right
Connect terminal 8 to the positive battery terminal. Connect terminal 7 to the negative battery terminal.Left

REMOTE CONTROLLED MIRROR CONNECTION CHART
