Scheme 62

Scheme 63

Mist wiper control

When the windshield wiper mist switch on the column switch is turned ON while the ignition switch is in ACC or ON position, the column switch turns the windshield wiper relay ON. At the same time, the wiper speed switching relay turns ON (HI). When the windshield mist wiper switch is ON, the windshield wiper operates at high speed.

Scheme 64

Scheme 65

When the windshield low speed wiper switch on the column switch is turned ON while the ignition switch is in ACC or ON position, the column switch turns the windshield wiper relay ON. Also, the wiper speed switching relay turns OFF (LO), and the windshield wiper operates at low speed.

When the windshield high speed wiper switch is turned ON, the windshield wiper relay turns ON. Also, the wiper speed switching relay turns ON (HI), and the windshield wiper operates at high speed.

Scheme 66

WINDSHIELD WIPER WASHER FUNCTION CHART

When the windshield washer switch on the column switch is turned ON while the ignition switch is in ACC or ON position, ETACS turns the windshield washer relay ON.

When the windshield washer switch is kept ON for 0.3 seconds or longer, the windshield wiper relay (the wiper relay output time varies depending on the conditions. For details, see the table.) is turned ON, and the windshield wiper operates at high speed. The windshield wiper is turned OFF with 3 seconds delay after the windshield washer switch is turned OFF.

Even when the windshield washer switch is turned ON while the windshield wiper is operating intermittently, the intermittent action starts again after the linked operation is finished.

If the ignition switch is turned to ACC position while the windshield washer switch is ON, the windshield washer relay turns ON, but the windshield wiper does not perform the linked operation. When the windshield washer switch is turned OFF and then ON, the windshield wiper starts the linked operation.

Note. Using the configuration function, the washer linked windshield wiper function can be invalidated (Refer to CONFIGURATION FUNCTION ). Using the configuration function, when the washer linked windshield wiper function is invalidated, only the washer operates. It is useful to melt down the ices of the frozen windshield.

Scheme 67

1. Lighting control sensor (rain sensor) has been installed in the upper part of the windshield to sense the raindrops and windshield wiper can be operated when the ignition switch is at ON and wiper switch is at AUTO position.
2. The lighting control sensor detects the raindrops on the windshield surface using the optical element, and it automatically switches the windshield wiper operation, depending on the amount of rainfall, to the intermittent or LO/HI operation.
3. The lighting control sensor detects the raindrops using the reflections of infrared rays, and depending on the amount of rainfall, it automatically adjusts the wiping speed.
4. Dry windshield: All infrared rays emitted from the emitter diode are reflected by the windshield and directed to the receiver diode as they are.
5. Wet windshield: Part of the infrared rays emitted from the emitter diode are transmitted to outside of the windshield through the raindrops, and the infrared rays with reduced intensity are directed to the receiver diode.

Note. Using the configuration function, the rain sensitive wiper function can be invalidated (Refer to CONFIGURATION FUNCTION ).

LIN (LIGHTING CONTROL SENSOR)

DATA LIST REFERENCE CHART

WINDSHIELD INTERMITTENT WIPER INTERVAL CHECK

1. Check that the intermittent wiper interval is changed as the windshield intermittent wiper interval control is operated.
2. Turn the windshield intermittent wiper switch to the intermittent operation position. Use scan tool MB991958 to set a simulated vehicle speed with the wiper volume held. The intermittent wiper interval should be changed as the simulated vehicle speed is changed.
3. If either of above is defective, carry out the troubleshooting. (Refer to «INSPECTION PROCEDURE 5: THE WINDSHIELD INTERMITTENT WIPER INTERVAL CANNOT BE ADJUSTED BY OPERATING THE WINDSHIELD INTERMITTENT WIPER INTERVAL CONTROL SWITCH.»(ref-289387-S02341577462008063000000) )

CONFIGURATION FUNCTION

Using the ETACS system of scan tool MB991958, the following functions can be programmed. The programmed information is held even when the battery is disconnected.

FRONT WIPER OPERATION CHART

Scheme 68

Scheme 69

Required Special Tool

1. MB991958: M.U.T.-III sub-assembly
2. MB991223: Harness set
3. MB992006: Extra fine probe

Note. For removal and installation of the wiper and washer switch, refer to COLUMN SWITCH .

Scheme 70

1. Manually turn the link rod of the wiper link assembly forward to the position indicated in the figure. CAUTION: Another mechanic fully pushes up the hood so that the left side of link assembly is pulled out easily.
2. Pull out the attachment section of the left side of wiper link assembly forward until the link rod bumps against the front deck garnish retainer. CAUTION: When pulling out the link assembly forward, be careful not to make a contact with the windshield glass.
3. While turning the link assembly upward (A), pull out the entire link assembly diagonally forward left (B).

Scheme 71

1. To disconnect the wiper motor link plate from the wiper motor shaft, use an appropriate tool to counter-hold the plate to prevent it from turning.
2. Remove the wiper motor from the wiper link assembly.

WINDSHIELD WIPER MOTOR CHECK

The windshield wiper motor assembly should be installed to the vehicle body and the harness connector should be disconnected when checking the wiper motor.

WINDSHIELD WIPER SWITCH CHECK

Check continuity between the switch terminals.

TERMINALS REFERENCE CHART

Scheme 72

Scheme 73

Note. For removal and installation of the wiper and washer switch, refer to COLUMN SWITCH .

WINDSHIELD WASHER SWITCH CHECK

TERMINALS REFERENCE CHART

ADAPTATION

1. Clean the windshield in fine weather.
2. Wipe the surface of the windshield thoroughly, and check that the surface is dry.
3. Turn the ignition switch to the ON position.
4. Turn the ignition switch to the LOCK (OFF) position. CAUTION: Before connecting or disconnecting scan tool MB991958, always turn the ignition switch to the LOCK (OFF) position.
5. Connect the scan tool MB991958 to the data link connector.
6. Turn the ignition switch to the ON position.
7. Wipe the windshield surface of the lighting control sensor section thoroughly, and check that the surface is dry.
8. Select "LIN" on the "System Select" screen, and press the "OK" button.
9. Select "Rain light sensor" on the "System Select" screen, and press the "OK" button.
10. Select "Special Function" on the "Rain light sensor" screen.
11. Select "Rain Sensor Adaptation" on the "Special Function" screen.
12. Press the "OK" button, and execute the "Rain Sensor Adaptation".
13. Press the "OK" button after the execution screen is displayed.
14. Press the "OK" button after "Completed" is displayed.

Scheme 74

DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK

TERMINALS REFERENCE CHART

Scheme 75
