ENGINE COMPARTMENT
For fuses and fusible link locations, refer to illustrations in COMPONENT LOCATION .
For engine compartment fuse locations, refer to illustrations below.
Scheme 3
Scheme 4
| No. | POWER SUPPLY CIRCUIT | FUSE TYPE | RATED CAPACITY | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Fusible link No.36 | Fuse | 15A | Blue | Fog light and fog light relay |
| 2 | 7.5A | Brown | Engine control module | ||
| 3 | 20A | Yellow | Primary pulley speed sensor CVT, secondary pulley speed sensor CVT and transaxle control module CVT | ||
| 4 | 10A | Red | Horn and horn relay | ||
| 5 | 7.5A | Browm | Generator | ||
| 6 | |||||
| 7 | 10A | Red | A/C compressor assembly and A/C compressor clutch relay | ||
| 8 | 15A | Blue | Engine control module | ||
| 9 | |||||
| 10 | |||||
| 11 | |||||
| 12 | |||||
| 13 | 10A | Red | Daytime running light and daytime running light relay | ||
| 14 | Headlight relay (High) | Fuse | 10A | Red | Headlight assembly (High: LH) |
| 15 | 10A | Red | Headlight assembly (High: RH) | ||
| 16 | Headlight relay (Low) | Fuse | 20A | Yellow | |
| 17 | 20A | Yellow | |||
| 18 | 10A | Red | Headlight assembly (Low: LH) | ||
| 19 | 10A | Red | Headlight assembly (Low: RH) | ||
| 20 | MFI Relay | Fuse | |||
| 21 | 10A | Red | Ignition coil No.1 to 4 | ||
| 22 | 20A | Yellow | Center exhaust pipe heated oxygen sensor, engine control module, engine oil control valve, evaporative emission purge solenoid, evaporative emission ventilation solenoid, injector No.1 to 4, mass airflow sensor, heated oxygen sensor and vehicle speed sensor M/T | ||
| 23 | 15A | Blue | Fuel pump module | ||
| 24 | Fusible link No.36 | Fusible link | 30A | Pink | Starter |
| 25 | |||||
| 26 | 40A | Green | ABS-ECU | ||
| 27 | 30A | Pink | ABS-ECU | ||
| 28 | 30A | Pink | Condenser fan motor, condenser fan relay and fan control relay | ||
| 29 | 40A | Green | Radiator fan motor and radiator fan relay | ||
| 30 | Fuse | 30A | Green | Fuse No.7 to 9 in passenger compartment | |
| 31 | 30A | Green | Audio amplifier | ||
| 32 | MFI relay | ||||
| 33 | Battery/Generator | Fusible Link | 120A | Fusible link No.37/ Fusible link No.34 to 36 | |
| 34 | Battery/Fusible link No.33 | 80A | Fuse Nos.2, 4, 5, 10, 11, 12, 14, 15, 17, 18, 20 and No.25 in passenger compartment | ||
| 35 | 80A | ||||
| 36 | 120A | Fuse No.1 to 32 in engine compartment, headlight relay (High), headlight relay (Low) and MFI relay | |||
| 37 | Fusible link No.33/ Generator | 80A | Fusible link No.1 and 21, Fuse No. 3, 6, 13, 16, 19, and 22 in passenger compartment and ETACS-ECU(ACC relay 2 and blower relay) |
IDENTIFYING FUSES (ENGINE COMPARTMENT)
Spare fuses are located on the fuse box cover.
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
The fuse box does not contain spare 7.5A 10A and 15A fuses. If a fuse of one of these capacities blows, replace it temporarily by borrowing a fuse of correct rating from
- 7.5A: Door mirror heater
- 10A: Dome light (Engine Compartment)
- 15A: Cigarette lighter (Power outlet)
Replace the borrowed fuse as soon as possible.
PASSENGER COMPARTMENT
For fuse location and values, refer to illustrations below.
Scheme 5
| NO. | POWER SUPPLY CIRCUIT | FUSE TYPE | RATED CAPACITY | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Fusible link No.37 | Fusible link | 30A | Pink | Blower motor |
| 2 | Fusible link No.34 | Fuse | 15A | Blue | ETACS-ECU, high-mounted stoplight, rear combination light and shift switch assembly |
| 3 | Fusible link No.37 | 10A | Red | A/T control relay, input shaft speed sensor, output shaft speed sensor, vehicle speed sensor, backup light switch, SRS-ECU and transmission range switch | |
| 4 | ETACS-ECU (ACC relay 3) | 30A | Green | ETACS-ECU, washer motor and windshield wiper motor | |
| 5 | Fusible link No.34 | 10A | Red | Data link connector | |
| 6 | Fusible link No.37 | 20A | Yellow | ETACS-ECU, front door lock actuator, trunk lid actuator and switch and rear door lock actuator | |
| 7 | Fusible link No.30 | 15A | Blue | Audio visual navigation unit, CAN box unit, center panel unit, hands free module, radio and CD player or CD changer, rear display unit and satellite radio tuner | |
| 8 | 7.5A | Brown | A/C-ECU, column switch, combination meter, ETACS-ECU, key reminder switch, KOS-ECU, power window relay, wireless control module and receiver antenna module (Vehicles without KOS) | ||
| 9 | 15A | Blue | Audio visual navigation unit, center panel unit, combination meter and key reminder switch | ||
| 10 | Fusible link No.34 | 15A | Blue | ETACS-ECU | |
| 11 | ETACS-ECU (ACC relay 3) | Fuse | |||
| 12 | ETACS-ECU (IG1 relay) | 7.5 | Brown | A/C control panel, A/C-ECU, CVT control relay, ABS-ECU, center panel unit, column switch, combination meter, heated seat relay, KOS-ECU, rear window defogger relay, shift switch assembly, SRS-ECU, sunroof motor assembly, wireless control module (vehicles without KOS) andreceiver antenna module (vehicles without KOS) | |
| 13 | ETACS-ECU (ACC relay 2) | 15A | Blue | Accessory socket (front floor console) and cigarette lighter | |
| 14 | Fusible link No.34 | 10A | Red | Ignition switch circuit | |
| 15 | 20A | Yellow | Sunroof motor assembly | ||
| 16 | ETACS-ECU (ACC relay 2) | 10A | Red | Audio visual navigation unit, CAN box unit, door mirror assembly, radio and CD player or CD changer, rear display unit and remote controlled mirror switch | |
| 17 | Fusible link No.34 | 10A | Red | Occupant classification-ECU | |
| 18 | ETACS-ECU (IG1 relay) | 7.5A | Brown | Audio visual navigation unit, backup light switch , transaxle control module , SRS-ECU and transmission range switch | |
| 19 | Fusible link No.37 | 15A | Blue | Accessory socket (rear floor console) | |
| 20 | Fusible link No.34 | Fusible link | 30A | Pink | Front power window motor (RH), power window main switch and rear power window motor |
| 21 | Fusible link No.37 | 30A | Pink | Rear window defogger | |
| 22 | Rear window defogger relay | Fuse | 7.5A | Brown | Door mirror assembly |
| 23 | Fusible link No.34 | ||||
| 24 | |||||
| 25 | 30A | Green | Heated seat |
IDENTIFYING FUSES (PASSENGER COMPARTMENT)
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
